StarTech.com EC1394B2 Manuel utilisateur

FireWire 800 ExpressCard Adapter

EC1394B2 Instruction Manual

Actual product may vary from photo

2 Port FireWire 800 / 1394b ExpressCard Adapter

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aannddootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other protected names

and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur

these references are for illustrative purposes only and do not represent an endorsement of a

product or service by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks,

registered trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Instruction Manual

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Verifying Successful Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting Peripheral Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Instruction Manual

Thank you for purchasing a StarTech.com 2 Port FireWire 800 / 1394b ExpressCard

Adapter. Now, you’ll be able to connect FireWire devices to a host computer for data

transfer rates of up to 800Mbps, in order to provide seamless operation of a broad range

of peripherals including printers, MP3 players, digital cameras and more.

IInnttrroodduuccttiioonn

•Supports data transfer rates of up to 100, 200, 400 and 800 Mbps

Features

System requirements:

•

A host computer with an available ExpressCard Slot. Please note that EC1394B2 can

be used on a desktop computer, using a PEX2EC PCI-Express to ExpressCard

Adapter Card. For more information, please see Accessory Products from

StarTech.com.

Package contents:

•ExpressCard Adapter

This package should contain:

•Supports various types of FireWire 800 (1394B) and 1394A standards

•A host computer running Windows 2000/XP/2003/VISTA

•Instruction Manual

•Driver CD

Instruction Manual

IInnssttaallllaattiioonn

To Verify Driver Installation:

1. Right click My Computer, then click Manage. Select Device Manager.

2. Double-click on 1394 Bus Controller or IEEE 1394 Bus host Controller. If the card

has successfully been installed, Texas Instruments OHCI Compliant IEEE 1394

Host Controller should be displayed.

Please Note: The ExpressCard must be installed prior to peripheral device

connection. Failing this, the peripheral device and/or notebook computer may

not function properly.

1. Locate an unused ExpressCard slot on the host computer.

2. Insert EC1394B2 into the available ExpressCard slot. Since this card is hot-

pluggable, this can be performed while the computer is on or off. Once the card has

been inserted, ensure the computer is powered, to proceed with installation.

3. Windows will detect that the card has been inserted, and will prompt for driver

installation. Follow the on-screen instructions. Once the driver has been installed,

the operating system will notify you that your new hardware is ready for use.

Warning! Please remove possible static discharge potential from any objects

that the ExpressCard may come in contact with, before installation. This can be

accomplished by touching a large, grounded metal surface for several seconds.

Verifying Successful Installation

Connecting Peripheral Devices

Once EC1394B2 has been installed according to the preceding instructions, FireWire

800 peripherals can be connected to the port provided.

Please note: FireWire devices that have their own power supply do not require

the optional power adapter to be connected in order to work. However, non-

powered FireWire devices require this optional power adapter to work. If you

need to connect a power adapter, please ensure that it meets the following

criteria:

Switching power adapter DC 12V, 1A

Polarity: Outside negative voltage(-) & Inside positive voltage(+)

3.5mm power jack.

Instruction Manual

AAcccceessssoorryyPPrroodduuccttssffrroommSSttaarrTTeecchh..ccoomm

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

PEX2EC

PCI-Express to ExpressCard Adapter

1394_94_6

6 ft 1394b Firewire Cable 9-4 Pin M-M

1394_94_10

10 ft 1394b Firewire Cable 9-4 Pin M-M

1394_96_6

6 ft 1394b Firewire Cable 9-6 Pin M-M

1394_99_6

6 ft 1394b Firewire Cable 9-9 Pin M-M

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a lifetime warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

LLiimmiittaattiioonnooffLLiiaabbiilliittyy

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

SSppeecciiffiiccaattiioonnss

Certifications ROHS, FCC, CE

Maximum Data Transfer Rate 800 Mbps

Operating Systems supported Windows 2000/XP/2003/VISTA

19 November 2007 (Rev. A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer Parts”.

Since 1985, we have been providing IT professionals with the quality products

they need to complete their solutions. We offer an unmatched selection of

computer parts, cables, server management solutions and A/V products and

serve a worldwide market through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products and to

access exclusive interactive tools such as the Parts Finder and the KVM

Reference Guide. StarTech.com makes it easy to complete almost any IT

solution. Find out for yourself why our products lead the industry in performance,

support, and value.
