Star AR-1000 Manuel utilisateur

DOT MATRIX PRINTER

AR-1000

TECHNICAL MANUAL

[SECOND EDITION ]

NOTICE

•Allrightsreserved.Reproductionofanypartofthismanualinany

form whatsoever, without STAR’s express permission is forbid-

den.

•The contents of this manual are subject to change without notice.

•All efforts have been made to ensure the accuracy of the contents

of this manual at the time of going to press. However, should any

errors be detected, STAR would greatly appreciate being in-

formed of them.

•The above notwithstanding, STAR can assume no responsibility

for any errors in this manual.

INTRODUCTION

This manual describes the AR-1000 dot matrix printer.

It is designed for use as a reference for periodic inspections and maintenance procedures to be executed

by service personal. It is not intended for the general user. Users of this manual should have a basic

knowledge and understanding of the English language.

•This manual is divided into the following sections:

Chapter 1 General Specifications

Chapter 2 Adjustments

Chapter 3 Parts Replacement

Chapter 4 Maintenance and Lubrication

Chapter 5 Parts List

•First edtion : Oct.1997

Second edtion : Aug.1998

(Blank Page)

CHAPTER 1

GENERAL SPECIFICATIONS

1. General Specifications ............................................................................................3

2. External Appearance and Composition ................................................................. 5

3. Parallel Interface ......................................................................................................7

3-1. General Specifications .................................................................................. 7

3-2. Connector Signals .........................................................................................7

4. Serial Interface .........................................................................................................8

4-1. General Specifications .................................................................................. 8

4-2. Connector Signals and Functional Descriptions ........................................8

5. Block Diagram..........................................................................................................9

(Blank Page)

– 3 –

1. General Specifications

Printing System Serial Impact Dot-Matrix

Printing Speed Pitch Draft (cps/dpi) LQ (cps/dpi)

Pica (10 cpi) 250/120H 83/360H

Elite (12 cpi) 300/120H 100/360H

Semi-condensed (15 cpi) 375/120H 125/360H

Condensed pica (17.1 cpi) – 143/360H

18 cpi 300/180H –

Condensed elite (20 cpi) 250/240H 167/360H

H: half-dot

Print Direction Draft: Bi-directional/Uni-directional logic seeking

(Selectable by Command)

LQ: Bi-directional/Uni-directional logic seeking

(Selectable by Command)

Bit-Image: Bi-directional/Uni-directional logic seeking

(Selectable by Command)

Print Head Number of pins: 24

Life: 200 million dots/pin (Normal Mode)

100 million dots/pin (Multi Part Mode)

Line Spacing 1/6″, 1/8″

n/60″, n/180″, n/216″,n/240″, n/360″: software

Environment Operating temperature: 41˚F to 95˚F (5˚C to 35˚C)

Storage temperature: -22˚F to 149˚F (-30˚C to 65˚C)

Operating humidity: 30% to 80% (noncondensing)

Storage humidity: 20% to 90% (noncondensing)

Paper Cut-sheet

Paper width: 3.0″to 8.3″/ 76.2 to 210 mm

Paper length: 2.5″to 11.7″/ 63.5 to 297 mm

Paper weight (1-ply): 14 to 42 lbs / 52 to 156 g/m2/ 45 to 135 kg

Multi-part: 11 to 14 lbs / 40 to 52 g/m2/ 34 to 45 kg; pressure

sensitive paper. Total thickness: 0.014″/0.35mm

– 4 –

Pass-Book

Paper width: 4″to 6″/ 101.6 to 152.4 mm

Paper length: 5.0-8.0”/127.0-203.2mm(WiththePass-bookopening.)

Paper thickness: Max 2.0mm (Total thickness)

Paper number: Max 14 (Except cover)

Interface Standard: RS-232C serial

Option: Centronics parallel or RS-232C serial

Ribbon Type On-carriage, dedicated

Monochrome: Black only

Ribbon Life P24: 2million characters (ASCII Draft)

Power Supply 220V AC +15%/-15%, 50Hz

Power Consumption 13W during stand-by

55W during ASCII draft printing

Options IS-NP192 Serial interface unit

IS-NPC Parallel interface unit

Fig. 1-1 External Dimensions

320mm

12.6"

410mm

16.1"

194.5mm

7.66"

Weight 18.94 lbs/8.6kg

– 5 –

2. External Appearance and Composition

Fig. 1-3 Rear View of the Printer

Fig. 1-2 Front View of the Printer

Front cover

Platen knob

Control panel

Power switch

Document table

Document

table

extension

Power terminal

Serial interface

connector

– 6 –

Fig. 1-4 Print Cover Removed

Fig. 1-5 Diagram of Internal Layout

Platen Print Head

Gap Motor

Carriage Motor

Paper Feed Motor

Shutter Motor

Main Logic Board

Power Supply Unit

Control Panel Board
