ST STM3210E-EVAL Manuel utilisateur

November 2008 Rev 3 1/48

UM0488

User manual

STM3210E-EVAL

evaluation board

Introduction

The STM3210E-EVAL evaluation board is designed as a complete development platform for

STMicroelectronic's ARM Cortex-M3 core-based STM32F103Z microcontroller with full

speed USB2.0, CAN2.0A/B compliant interface, two I2S channels, two I2C channels, five

USART channels with smartcard support, three SPI channels, two DAC channels, FSMC

interface, SDIO, internal 64 KB SRAM and 512 KB Flash, JTAG and SWD debug support.

The full range of hardware features on the board helps you to evaluate all peripherals (USB,

motor control, CAN, MicroSD card, smartcard, USART, NOR Flash, NAND flash, SRAM)

and develop your own applications. Extension headers make it possible to easily connect a

daughter board or wrapping board for your specific application.

Figure 1. STM3210E-EVAL evaluation board

Order code

To order the STM32F103Z evaluation board, use the order code STM3210E-EVAL.

www.st.com

Contents UM0488

2/48

Contents

1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.2 Demonstration software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2 Hardware layout and configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2.1 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.2 Boot option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.3 Clock source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.4 Reset source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.5 Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.6 Serial Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.7 CAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.8 RS232 connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.9 Motor control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.10 Smartcard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.11 MicroSD card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.12 Temperature sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.13 Analog input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.14 IrDA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.15 USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.16 Development and debug support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.17 Display and input devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.18 SRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.19 NAND Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.20 NOR Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.1 Motor control connector CN1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.2 Analog input connectors CN2, CN3 and CN5 . . . . . . . . . . . . . . . . . . . . . 16

3.3 CAN D-type 9-pin male connector CN4 . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.4 QST connector CN6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

UM0488 Contents

3/48

3.5 Trace debugging connector CN7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.6 RS232 connector CN8 with RTS/CTS handshake support . . . . . . . . . . . 18

3.7 JTAG debugging connector CN9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.8 Daughter board extension connectors CN10 and CN11 . . . . . . . . . . . . . 19

3.9 RS232 connector CN12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

3.10 MicroSD connector CN13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

3.11 USB type B connector CN14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3.12 Audio jack CN15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3.13 TFT LCD connector CN16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3.14 Power connector CN17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3.15 Smartcard connector CN18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4 Schematic diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Appendix A STM3210E-EVAL IO assignment. . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Overview UM0488

4/48

1 Overview

1.1 Features

●Three 5 V power supply options: power jack, USB connector or daughter board

●Boot from user Flash, system memory or SRAM

●I2S Audio DAC, stereo audio jack

●128 Mbyte MicroSD card

●Both A and B type smartcard support

●64 or 128 Mbit serial Flash, 512 Kx16 SRAM, 512 Mbit or 1 Gbit NAND Flash and 128

Mbit NOR Flash

●I2C/SMBus compatible serial interface temperature sensor

●Two RS-232 channels with RTS/CTS handshake support on one channel

●IrDA transceiver

●USB2.0 full speed connection

●CAN2.0A/B compliant connection

●Inductor motor control connector

●JTAG and trace debug support

●240x320 TFT color LCD

●Joystick with 4-direction control and selector

●Reset, wakeup, tamper and user buttons

●4 color LEDs

●RTC with backup battery

1.2 Demonstration software

To use the STM3210E-EVAL evaluation board, you must have the demonstration software

version 1.1 or later. If the version installed on your evaluation board is earlier than version

1.1, you must download the latest version from www.st.com.

UM0488 Hardware layout and configuration

5/48

2 Hardware layout and configuration

The STM3210E-EVAL evaluation board is designed around the STM32F103Z

microcontroller in a 144-pinTQFP package. The hardware block diagram Figure 2 illustrates

the connection between the STM32F103Z and peripherals (LCD, SPI Flash, USART, IrDA,

USB, audio, CAN bus, smartcard, MicroSD card, NOR Flash, NAND Flash, SRAM,

temperature sensor, audio DAC and motor control) and Figure 3 will help you locate these

features on the actual evaluation board.

Figure 2. Hardware block diagram

Hardware layout and configuration UM0488

6/48

Figure 3. STM3210E-EVAL evaluation board layout

CN10

Extension connector

CN8

USART2

STM32F103Z

CN2,3,5

BNC

U13

IrDA

CN14

USB

CN12

USART1

RESET B2

WAKEUP CN18

Smartcard B3

Tamper U19

Joystick B4

User key

CN1

Motor control

CN4

CAN

connector

CN6

QST

CN7

Trace

CN9

JTAG

U17

Color LCD

CN15

Audio jack

RV1

Potentiomete

CN11

Extension connector

CN13

MicroSD card

CN17

5V power

UM0488 Hardware layout and configuration

7/48

2.1 Power supply

The STM3210E-EVAL evaluation board is designed to be powered by 5V DC power supply

and to be protected by PolyZen U15 in the event of wrong power plug-in. It is possible to

configure the evaluation board to use any of following three sources for the power supply:

●5V DC power adapter connected to CN17, the power jack on the board (PSU on silk

screen for power supply unit).

●5V DC power with 500 mA limitation from CN14, the type-B USB connector (USB on

silkscreen).

●5V DC power from both CN10 and CN11, the extension connector for daughter board

(DTB for daughter board on silkscreen).

The power supply is configured by setting the related jumpers JP13, JP12 and JP1 as

described in Table 1. The LED LD5 is lit when the STM3210E-EVAL evaluation board is

powered correctly.

Table 1. Power related jumpers

Jumper Description

JP13

JP13 is used to select one of the three possible power

supply resources.

For power supply jack(CN17) to the STM3210E-EVAL

only, JP13 is set as shown (default setting).

For power supply from the daughter board

connectors(CN10 and CN11) to STM3210E-EVAL only,

JP13 is set as shown.

For power supply from USB (CN14) to STM3210E-EVAL

only, JP13 is set as shown.

For power supply from power supply jack(CN17) to both

STM3210E-EVAL and daughter board connected on CN10

and CN11, JP13 is set as shown (daughter board must

not have its own power supply connected).

JP12 Enables consumption measurements of both VDD and VDDA.

Default setting: Fitted

JP1

Vbat is connected to 3.3V power when JP1 is set as shown

(default setting).

Vbat is connected to battery when JP1 is set as shown.

PSU

DTB

USB

PSU

DTB

USB

PSU

DTB

USB

PSU

DTB

USB

1 2 3

Hardware layout and configuration UM0488

8/48

2.2 Boot option

The STM3210E-EVAL evaluation board can boot from:

●Embedded user Flash

●System memory with boot loader for ISP

●Embedded SRAM for debugging

The boot option is configured by setting the switches BOOT0 and BOOT1.

2.3 Clock source

Two clock sources are available on the STM3210E-EVAL evaluation board for STM32F103

and RTC.

●X2, 32KHz crystal for embedded RTC.

●X1, 8MHz crystal with socket for STM32F103Z microcontroller, it can be removed from

socket when internal RC clock is used.

2.4 Reset source

The reset signal of the STM3210E-EVAL evaluation board is low active and the reset

sources include:

●Reset button B1

●Debugging tools from JTAG connector CN7 and trace connector CN9

●Daughter board from CN11

Table 2. Boot related switches

Switch Boot from Switch

configuration

BOOT0

BOOT1

STM3210E-EVAL boots from User Flash when BOOT0 is set as

shown to the right. BOOT1 is not required in this configuration.

(Default setting)

STM3210E-EVAL boot from Embedded SRAM when BOOT0

and BOOT1 are set as shown to the right.

STM3210E-EVAL boot from System Memory when BOOT0 and

BOOT1 are set as shown to the right.

0 < > 1

Boot 0

0 < > 1

Boot 0

Boot 1

0 < > 1

Boot 0

Boot 1

Table 3. Reset related jumper

Jumper Description

JP19 Enables reset of the STM32F103Z embedded JTAG TAP controller each time a

system reset occurs. JP19 connects the TRST signal from the JTAG connection with

the system reset signal RESET#. Default setting: not fitted

UM0488 Hardware layout and configuration

9/48

2.5 Audio

The STM3210E-EVAL evaluation board supports stereo audio play because it provides an

audio DAC AK4343 connected to both I2S port and two channels of DAC of microcontroller

STM32F103Z. Either external slave mode or PLL slave mode (reference clock BICK or

LRCK) of audio DAC can be used by setting the jumper JP18.

The I2S_MCK is multiplexed with smartcard and motor control, and can be enabled by

setting the jumper JP15. Refer to Section 2.9: Motor control for details. Audio DAC AK4343

is in power-down mode when PDN pin is pulled-down by PG11.

2.6 Serial Flash

A 64 or 128 Mbit serial Flash connected to SPI1of STM32F103Z, serial Flash chip select is

managed by IO pin PB2. The SPI1_MISO is multiplexed with motor control, it can be

enabled by setting the jumper JP3. Refer to Section 2.9: Motor control for details.

2.7 CAN

STM3210E-EVAL evaluation board supports CAN2.0A/B compliant CAN bus

communication based on 3.3V CAN transceiver. The high-speed mode, standby mode and

slope control mode are available and can be selected by setting JP8.

Table 4. Audio related jumpers

Jumper Description

JP18

External slave mode (MCK from STM32F103Z) is selected

when JP18 is set as shown (default setting).

PLL slave mode (reference clock BICK or LRCK) is selected

when JP18 is set as shown.

1 2 3

Table 5. CAN related jumpers

Jumper Description

JP8

CAN transceiver works in standby mode when JP8 is set

as shown.

CAN transceiver works in high-speed mode when JP8 is set

as shown (default setting).

CAN transceiver works in slope control mode when JP8 is open.

JP6 CAN terminal resistor is enabled when JP6 is fitted.

Default setting: not fitted

1 2 3

Hardware layout and configuration UM0488

10/48

2.8 RS232 connectors

Two D-type 9-pin connectors CN12 (USART1) and CN8 (USART2) are available on the

STM3210E-EVAL evaluation board.

●USART1 connector is connected to RS232 transceiver U7

●USART2 connector with RTS/CTS handshake signal support is connected to RS-232

transceiver U5. The USART2_CTS is multiplexed with motor control, it can be enabled

by setting the jumper JP4. Refer to Section 2.9: Motor control for details.

2.9 Motor control

The STM3210E-EVAL evaluation board supports three-phase brushless motor control via a

34-pin connector CN1, which provides all required control and feedback signals to and from

the motor power driving board. Available signals on this connector include emergency stop,

motor speed, three-phase motor current, bus voltage, heatsink temperature coming from the

motor driving board and 6 channels of PWM control signals going to the motor driving

circuit.

JP 20 allows to choose between two synchronization methods for power factor correction

(PFC).

The I/O pins used on the motor control connector CN1 are multiplexed with some

peripherals on the board; either the motor control connector or multiplexed peripherals can

be enabled by setting the jumpers JP3, JP4, JP11, JP15 and JP16 as described in Table 6.

Table 6. Motor control related jumpers

Jumper Description Multiplexed

peripherals

JP20 JP20 allows to have a PFC synchronization signal redirected to the timer 3 input capture 1

pin, and additionally to the timer 3 external trigger input. JTAG debugging is disabled when

JP20 is fitted. Default setting: not fitted

JP2 JP2 should be kept on open when encoder signal is input from pin 31 of CN1 while it

should be kept on close when analog signal is from pin 31 of CN1 for special motor.

Default setting: not fitted

JP4

MC_EnA is enabled when JP4 is set as shown to the right

(default setting):

USART2_CTS is enabled when JP4 is set as show to the

right:

USART2

JP3 MC_EmergencySTOP is enabled when JP3 is closed. The pin PA6 is used

as SPI1_MISO when JP3 is open. Default setting: not fitted SPI1

JP11 MC_PFCpwm is enabled when JP11 is open. The pin PB5 will be used as

interrupt input from temperature sensor when JP11 is closed. Temperature

sensor

JP15 MC_UH or I2S_MCK are enabled when JP15 is open. The pin PC6 is used

as Smartcard_CMDVCC when JP15 is closed. I2S and

smartcard

JP16 MC_VH is enabled when JP16 is open. The pin PC7 is used as

Smartcard_OFF when JP16 is closed Smartcard

1 2 3

Autres manuels pour STM3210E-EVAL

Table des matières

Autres manuels ST Carte mère

ST STEVAL-PCC001V1 Manuel utilisateur

ST STM8S Manuel utilisateur

ST STM32H753I-EVAL Manuel utilisateur

ST STM32L073Z-EVAL Manuel utilisateur

ST STM32L476G-EVAL Manuel utilisateur

ST NUCLEO-8S207K8 Manuel utilisateur

ST AEK-POW-LDOV01J Manuel utilisateur

ST EVAL-IBD002-35W Manuel utilisateur

ST M24SR-DISCOVERY Manuel utilisateur

ST UM1789 Manuel utilisateur

ST STA333ML Instructions d'installation et d'utilisation

ST STEVAL-LLL011V1 Manuel utilisateur

ST MB1367 Manuel utilisateur

ST ST7LIT15BY0 Manuel utilisateur

ST STM32100B-EVAL Manuel utilisateur

ST STM32 NUCLEO-F042K6 Manuel utilisateur

ST STEVAL-IHM022V1 Manuel utilisateur

ST STM32H753I-EVAL Manuel utilisateur

ST STEVAL-PLC001V1 Manuel utilisateur

ST STMPE801 Manuel utilisateur

ST SPC584B-DISP Manuel utilisateur

ST STEVAL-L6983IV1 Manuel utilisateur

ST STEVAL-1PS03A Manuel utilisateur

ST STEVAL-STRKT01 Guide de l'administrateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
