SPRT POS58VI Manuel utilisateur

POS58VI

LineThermalPrinter

User sManual

VER1.00）

PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT

Content

Introduction 2

Chapter1Characteristicand Specification 3

1.1Printing Specification 3

1.2PrintingPaper 3

1.3PrintingFont 3

1.4Interface 3

1.5PrintingControlCommand 4

1.6PowerSupply 4

1.7Operation Environment 4

1.8OutlineDimension 4

Chapter2Operation 4

2.1PrinterAppearance 4

2.2PaperInstallation 6

2.3InterfaceConnection 6

2.3.1ParallelInterface 6

2.3.2SerialInterface 7

2.3.3USB Interface 9

2.3.4Cashdrawer connection 9

2.4Buttons and Indicators 9

2.5Self-test 10

2.6HexadecimalDump……………………………………….10

2.7UpgradeMode……………………………………………..11

Chapter3Printing DriverInstallation 11

Appendix1Performance Index 11

PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT

２

Introduction

POS58VI printerisanewtype linethermalprinter,it featuresinfast

speedprint,lowprintnoise,highreliability,perfectprintqualityand ribbon

needless avoidingthe vexation of regularmaintenance.

POS58VI printer: small inoutlinedimension,simpleoperation,and

extensiveapplication,especiallysuitablefor commercialcash register,

PC-POS, bankPOSand all kinds ofreceipts print.

PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT

３

Chapter 1Characteristicand Specification

1.1Printingspecification

●Printing method:directthermal

●

Printing paperwidth:57.5±0.5mm

●Printing density:8dots/mm, 384 dots/line

●Printing speed:approx. 75mm/s (validcontentof eachlineisn’tover25%)

●Reliability:

Printingheadlife:100km

MCBF:5million lines

Using condition:

＊Print12 ×24 ASCII characters,print50 lineseachtime,intermittent

printrepeatedly

＊Eachdot-lineprintingatthesametimeshould notexceed25%,each

character-lineand onedotverticallyprinting repeatedlyshould

notexceed11times

＊Use specifiedthermalpaper

●Validprinting width:48mm

1.2PrintingPaper

●Thermalpapermodel: TF50KS－E（Japanpaperco.ltd）

AF50KS-E(JUJOTHERMAL)

●Thermalpaper: Width－－－－－－－－ 57.5±0.5mm

OuterDiameter －－－ 80mm（max.）

InnerDiameter －－－ 13mm（min.）

Thickness 0.06-0.08mm

1.3PrintingFont

●ANK Characterset:

12×24 dots，1.25（W）×3.00（H）mm;

●GB2312-80(Chinese):

24×24 dots，3.00（W）×3.00（H）mm.

1.4Interface

●RS232interface:

DB25 socket(female), supports XON/XOFF and RTS/CTSprotocol

Baud rate:1200-115200bps adjustable.

Datastructure:onestart bit+7or 8databits +onestopbit

PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT

４

●Parallelinterface:

DB25 socket(male),8-bit parallelinterface,supports BUSY/ACK

handshaking protocol,TTL.

●USB interface：

Standard B typeUSB interface.

●Cash drawercontrol

DC12V，1A，6-pinRJ-11socket.

1.5PrintingControlCommand

●Characterprintcommand:supportsdoublewidthanddoubleheight

printing ofANK characters,user-definedcharacters and Chinesecharacters,

thecharacterlinespacing is adjustable.

●Graphicsprintcommand:supportsthe printingof bit mapgraphicswith

differentdensity

●GSbarcodeprintcommand:supports UPC-A、UPC-E、EAN-13、EAN-8、

CODE39、ITF25、CODABAR、CODE93、CODE128 barcodeprint.

1.6Power Supply

●DC12V±10％，2A(onecore)

1.7OperationEnvironment

●Operation environmenttemperature:0～50

Relativehumidity:10～80％

●Storagetemperature:-20～60

Relativehumidity:10～90%

1.8OutlineDimension

●205(L) X118 (W) X129(H) mm

Chapter 2Installationand Operation

2.1Printer Appearance

PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT

５

Fig2-1 Printerouterappearance

Fig2-1 Printerouterappearance (back)

PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT

６

2.2Paper Installation

POS58VIadopts 57.5±0.5mm widththermalpaper.

Thesteps of thermalpaperinstallationareasthefollowing:

1. Whenthereis nopaperintheprinthead, pls don’tpress【FEED】buttonto

avoidaffectingthelifeof printinghead. Opening openbutton toopenthe

casecoverand changepaper.

2. Afterpapercasecoveris closed, plsdo notdraw thepaperforwards or

backwards withhands.

2.3Interface Connection

2.3.1ParallelInterface Connection

TheParallelinterfaceof POS58VIprinteris compatiblewithCENTRONICS,

supports BUSYand /ACK handshakingprotocol,it usesDB25 socket(male),

thepinorderof parallelportis asbelowshows:

Pin Order ofParallelPort

Thepinassignmentof parallelinterface is shownasbelow:

PinNo. Signal Direction Description

1 /STB In Strobepulsetolatch data,

reading occursatraisingedge.

DATA1

DATA2

DATA3

DATA4

DATA5

DATA6

DATA7

DATA8

Thesesignals representthe1

bit to8

th bit of theparallel

interface data,eachsignalisat

HIGHT levelwhendatais

logic1,and LOWwhendatais

logic0.

10 /ACK Out

Answerpulse, LOWlevel

signalindicatesthatdatahave

alreadybeenreceivedand the

printergets readytoreceivethe

nextdata.

PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT

７

11 BUSY Out HIGH levelsignalindicates

thattheprinteris BUSY and

cannotreceivedata.

12 PEOut HIGH levelsignalindicates

thatpaperis end.

13 SELOut PullinguptoHIGH level

signalbyaresistor indicates

theprinteris online.

15 /ERR Out PullinguptoHIGH level

signalbyaresistor indicates

thereis no error.

14,16,17 NC --- Noconnection

18-25 GND --- Grounding logical0level

Note: （1）“In”denotesinputting tothe printer，“Out”denotesoutputting

fromtheprinter.

（2）SignallevelisTTLstandard.

Fig. PinAssignmentof ParallelInterface

2.3.2RS232 Interface Connection

TheRS232 interfaceof POS5VIprinter is compatiblewithRS232Cstandard,

supports RTS/CTS and XON/XOFF handshaking protocol,it usesDB25

socket(female), thepinorderoftheRS232 portisasbelow:

Fig. PinOrderofthe SerialPort

Thepinassignmentof RS232 interface is shownasbelow:

PinNo. SignalSource Description

2 RXD HostPrinterreceivesdatafromhost

PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT

８

3 TXD Printer Printertransmits controlcode

X-ON/X-OFF and

datatohost

5 CTS Printer Signal “MARK”indicatesthat

theprinteris “BUSY”and

unabletoreceivedata;

“SPACE”indicatesthatthe

printeris “READY”for

receiving data.

6 DSR printer Whenthissignalis “SPACE”,

it means theprinter “online”.

7 GND —SignalGround

8 DCD printer Samewithsignal “CTS”

Fig. Pin AssignmentofSerialInterface

Note: “Source”①denotesthesource thatsignalcomesfrom;

②Logicalsignallevelis EIA.

Thebaud rateand datastructureinRS232 interface modearesetto9600bps,

8databits, noparitybit and 1stop bit.

Theserialinterface of POS58VIcanbeconnectedwithstandard RS-232C

interface.WhenconnectedtoIBMPC or compatiblemachine, connection

canaccord tothebelow.

Fig. Connection between POS58VIS andIBMPCSerialInterface

PDFcreated withpdfFactorytrialversion www.pdffactory.com

SPRT

９

2.3.3USB Interface

Standard B typeUSB interface

2.3.4CashDrawer Interface

Thecash drawerinterface of POS58VIis RJ-11, 6pinsocket, asbelow,

Thepinassignmentof thecash drawerinterface is asfollows:

Pin No. Signal Direction

1 Chassis Ground ---

2 Cash drawerdriversignal Out

3 Cash draweron/offstatus signal In

4 +12VDC Out

5 N.C ---

6 Cash draweron/offstatus signalground

---

2.3.5Power Connection

POS58VI usesexternalpowersupplyas12VDC±10％,2A,onecoremodel,

asbelow:

2.4ButtonsandIndicators

2.4.1Power switch

Controlon/off statusof power. is off status. Press “-”is on status.

2.4.2FeedButton

【FEED】is paper feedbutton.Printcommand canenableor disable

【FEED】status tobeon oroff. Underenablestatus, holddown【FEED】,

start paperfeeding, releasethebutton paperfeeding stops.

PDFcreated withpdfFactorytrialversion www.pdffactory.com
