Sportline 310 Manuel utilisateur
Qlip
PEDOMETER
model 310
WV4405IS01SPT.indd 1WV4405IS01SPT.indd 1 7/9/08 10:04:46 AM7/9/08 10:04:46 AM
TABLE OF CONTENTS
INTRODUCTION 1
HOW TO USE THIS MANUAL 2
REMOVING THE BATTERY INSULATOR TAB 3
WARNINGS & CAUTIONS 4
PEDOMETER FUNCTIONS 5
HOW TO WEAR YOUR PEDOMETER 6
KEYS AND THEIR FUNCTIONS 7
MAIN OPERATING MODES 8
SETTING THE PEDOMETER FUNCTIONS
SETTING TIME 9
SETTING USER DATA 10
OPERATING THE PEDOMETER
VIEWING PEDOMETER DATA 11
RESETTING PEDOMETER DATA 12
TIPS FOR INCREASING YOUR DAILY STEPS 13
REPLACING THE BATTERY 14
CARE & MAINTENANCE 15
RANGES & SPECIFICATIONS 16
WARRANTY 17
WV4405IS01SPT.indd Sec1:1WV4405IS01SPT.indd Sec1:1 7/9/08 10:04:48 AM7/9/08 10:04:48 AM
1
Qlip
INTRODUCTION
Congratulations on your purchase of a Sportline Qlip Pedometer. The Qlip Pedometer
features the Infinity Motion Sensor, a highly advanced pedometer technology that accurately
measures your body movements from multiple locations on the body and in multiple
orientations.
Please keep in mind your pedometer is a sensitive technical instrument. With proper care
and maintenance, it will last for many years. However, improper care and handling can cause
the various sensors to be damaged and to stop functioning.
WV4405IS01SPT.indd Sec2:1WV4405IS01SPT.indd Sec2:1 7/9/08 10:04:48 AM7/9/08 10:04:48 AM
2
Sportline Qlip Pedometers have many unique features and functions. Please read all sections
of this manual carefully and become familiar with the operation of the pedometer before
using it in the field.
Proper setup and operation will greatly enhance the pedometer’s usefulness and your
enjoyment of the product.
The manual is divided into sections outlining each of the major functions of the pedometer.
A drawing of the screen that represents a starting point or other important point for each
operational process is shown adjacent to the instructions; important keys are shown
indicating PRESS & HOLD and PRESS.
The steps for the programming or operation are adjacent to the screen illustration. Key points
and important information are shown in highlighted blocks.
HOW TO USE THIS MANUAL
WV4405IS01SPT.indd Sec2:2WV4405IS01SPT.indd Sec2:2 7/9/08 10:04:48 AM7/9/08 10:04:48 AM
3
Qlip
NOTE: In order to activate your pedometer after purchase, you must remove the battery
insulator tab inside the battery compartment.
1. Unscrew the battery compartment door with a
small Phillips screwdriver.
2. Remove the tab (be sure that the battery is in
the correct polarity position – positive (+) side
of the battery is visible).
3. Replace the battery compartment door and
tighten the fastening screw with a Phillips
screwdriver.
4. Remove the label that appears on the
pedometer display.
REMOVING THE BATTERY INSULATOR TAB
WV4405IS01SPT.indd Sec2:3WV4405IS01SPT.indd Sec2:3 7/9/08 10:04:48 AM7/9/08 10:04:48 AM
4
WARNINGS & CAUTIONS
WARNING: Before starting any exercise program or performing any vigorous physical activity,
we strongly suggest you visit your doctor for a complete physical and to discuss your plans.
CAUTION Qlip Pedometers are not water resistant.
AVOID exposing the Pedometer to extreme conditions.
AVOID rough uses or severe impacts to the Pedometer.
CLEAN the Pedometer occasionally with a soft, dry cloth.
STORE the Pedometer in a dry place when it is not in use for a long time.
WV4405IS01SPT.indd Sec2:4WV4405IS01SPT.indd Sec2:4 7/9/08 10:04:48 AM7/9/08 10:04:48 AM
5
Qlip
PEDOMETER FUNCTIONS
TIME
•Time displayed in 1-second resolution
•12 or 24 hour formats
PEDOMETER
•Measures Walking Steps
•Distance
•Average Speed
•Exercise Time
•Calories Burned
TIMER
•1-Second Resolution
•10 Hour
OTHER
•Removable Clip Holster
WV4405IS01SPT.indd Sec2:5WV4405IS01SPT.indd Sec2:5 7/9/08 10:04:48 AM7/9/08 10:04:48 AM
6
HOW TO WEAR YOUR PEDOMETER
For most accurate measurements, Sportline recommends inserting the unit into a tight,
secure pocket or clipping the unit (with the holster included) to the beltline.
FOR MOST ACCURATE PEDOMETER READINGS:
1. Position the unit in a vertical orientation (angle of 30° or less – see
illustration A. IMPORTANT: positioning the unit horizontally (display
flat to the ground) will compromise accuracy – see illustration B.
2. Secure the unit as close to the body as possible (DO NOT attach to
loose clothing).
NOTE: This Pedometer will be most accurate when worn close to the body. If
the Pedometer is clipped to loose clothing or loosely contained in a pocket, the
unit’s accuracy may be compromised.
To clip the pedometer to your clothing, simply
insert the pedometer unit into the clip holster
as shown.
30°
60°
30°
60°
A
B
WV4405IS01SPT.indd Sec2:6WV4405IS01SPT.indd Sec2:6 7/9/08 10:04:48 AM7/9/08 10:04:48 AM
7
Qlip
MODE KEY
•Scroll through operating modes
•Advance to next setting in Programming
Sequence
RESET KEY
•PRESS & HOLD: Clears data in Pedometer
modes (Step, Distance, Calories, Speed
and Timer)
•Increase values being set during a
Programming Sequence
ADJUST KEY
•PRESS & HOLD: Accesses Programming
Sequence in Time of Day and Step
modes
•Toggle between Metric and Imperial
measurement in Distance and Speed
modes
KEYS AND THEIR FUNCTIONS
ADJUST KEY
RESET KEY
MODE KEY
Qlip
WV4405IS01SPT.indd Sec2:7WV4405IS01SPT.indd Sec2:7 7/9/08 10:04:49 AM7/9/08 10:04:49 AM
8
MAIN OPERATING MODES
The Sportline Qlip has 6 main operating modes: Time, Step, Distance, Calories, Speed, and
Exercise Timer.
• Scroll through main operating modes by PRESSING the MODE key.
• Toggle between Metric and Imperial measurements (in Distance and Speed modes) by
PRESSING the ADJUST key.
TIME OF DAY
PRESS
MODE
STEP
PRESS
MODE
DISTANCE
PRESS
MODE
CALORIES
PRESS
MODE
SPEED
PRESS
MODE
EXERCISE TIMER
PRESS
MODE
WV4405IS01SPT.indd Sec2:8WV4405IS01SPT.indd Sec2:8 7/9/08 10:04:49 AM7/9/08 10:04:49 AM
