Spirit CT900ENT Manuel utilisateur

C T 900ENT TREADMILL

OWNER’S MANUAL

Spirit Fitness

www.spirittness.com

TABLE OF CONTENTS

3 IMPORTANT SAFETY INSTRUCTIONS

4 IMPORTANT ELECTRICAL INSTRUCTIONS

6 IMPORTANT OPERATION INSTRUCTIONS

6 PRODUCT REGISTRATION

7 CT900ENT ASSEMBLY INSTRUCTIONS

13 CONSOLE OPERATION

22 TOUCH SCREEN OPERATION

30 PROGRAMMING THE CONSOLE

48 GENERAL MAINTENANCE

49 MANUFACTURER’S LIMITED WARRANTY

Thank you for purchasing our product, please save these instructions. Please do not perform or attempt any

customizing, adjustments, repair or maintenance that is not described in this manual.

Spirit Fitness

Congratulations on your new treadmill and welcome to the Spirit Fitness family!

Thank you for your purchase of this quality treadmill from Spirit Fitness. Your new treadmill was

manufactured by one of the leading tness manufacturers in the world and is backed by one of

the most comprehensive warranties available. Through your dealer, Spirit Fitness will do all we

can to make your ownership experience as pleasant as possible for many years to come. If not

purchased directly from Spirit Fitness, the local dealership where you purchased this treadmill is your

administrator for all Spirit Fitness warranty and service needs. Their responsibility is to provide you

with the technical knowledge and service personnel to make your experience more informed and any

difculties easier to remedy.

Please take a moment at this time to record the name of the dealer, their telephone number, and the

date of purchase below to make any future, needed contact easy. We appreciate your support and we

will always remember that you are the reason we are in business.

Yours in health,

Spirit Fitness

NAME OF DEALER _____________________________________

DEALER PHONE # _____________________________________

PURCHASE DATE _____________________________________

www.spirittness.com

IMPORTANT SAFETY

INSTRUCTIONS

DANGER —To reduce the risk of electric shock,

always unplug this treadmill from the electrical

outlet immediately after using and before cleaning.

WARNING

To reduce the risk of burns, re electric shock, or

injury to persons:

• Before beginning this or any exercise program,

consult a physician. This is especially important for

persons over the age of 35 or persons with pre-

existing health conditions.

• Keep children away from the treadmill. There are

obvious pinch points and other caution areas that

can cause harm.

• Keep hands away from all moving parts.

• Never drop or insert any object into any openings.

• Do not use outdoors.

• Do not attempt to use your treadmill for any purpose

other than for the purpose it is intended.

• The hand pulse sensors are not medical devices.

Various factors, including the user’s movement, may

affect the accuracy of heart rate readings. The

pulse sensors are intended only as exercise aids in

determining heart rate trends in general.

• Wear proper shoes. High heels, dress shoes,

sandals, or bare feet are not suitable for use on your

elliptical. Quality athletic shoes are recommended to

avoid leg fatigue.

• Maximum User Weight: 450 lbs,

• This appliance is not intended for use by persons

with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction

concerning use of the appliance by a person

responsible for their safety.

• Keep children under the age of 13 away from this

machine.

• Never operate this treadmill if it has a damaged

cord or plug, if it is not working properly, if it has

been dropped or damaged, or dropped into water.

• Keep the cord away from heated surfaces.

• Do not operate where aerosol (spray) products are

being use or where oxygen is being administered.

• Connect this treadmill to a properly grounded outlet

only. See Grounding Instructions.

Spirit Fitness

• ASTM F2115-05 Specications 6.1.2.11—The recommended minimum clearance required around each

treadmill for access to, passage around, and emergency dismount shall be stated. The minimum dimensions are

to be: 0.5 m (19.7 in.) on each side of the treadmill, and 1 m (39 in.) behind the machine.

SAVE THESE INSTRUCTIONS - THINK SAFETY!

IMPORTANT ELECTRICAL INSTRUCTIONS

WARNING

NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. As with any appliance with

a large motor, the GFCI will trip often. Route the power cord away from any moving part of the treadmill

including the elevation mechanism and transport wheels.

NEVER remove any cover without rst disconnecting AC power. If voltage varies by ten percent (10%) or

more, the performance of your treadmill may be affected. Such conditions are not covered under your

warranty. If you suspect the voltage is low, contact your local power company or a licensed electrician for

proper testing.

NEVER expose this treadmill to rain or moisture. This product is NOT designed for use outdoors, near a pool

or spa or in any other high humidity environment. The operating temperature specication is 40 to 120

degrees Fahrenheit, and humidity is 95% non-condensing (no water drops forming on surfaces).

Circuit Breakers: Some circuit breakers are not rated for high inrush currents that can occur when a treadmill

is rst turned on or even during use. If your treadmill is tripping the circuit breaker (even though it is the proper

current rating) but the circuit breaker on the treadmill itself does not trip, you will need to replace the facility

www.spirittness.com

breaker with a high inrush type. This is not a warranty defect. This is a condition we as a manufacture have

no ability to control. This part is available through most electrical supply stores. The electrical outlet used

should have a dedicated 20 amp circuit breaker.

GROUNDING INSTRUCTIONS

This product must be grounded. If the treadmill should malfunction or break down, grounding provides a path

of least resistance for electric current, reducing the risk of electric shock. This product is equipped with a cord

having an equipment-grounding plug. The plug must be plugged into an appropriate outlet that is properly

installed and grounded in accordance with all local codes and ordinances.

DANGER – Improper connection of the equipment-grounding conductor can result in a risk of electric shock.

Check with a qualied electrician or serviceman if you are in doubt as to whether the product is properly

grounded. Do not modify the plug provided with the product if it will not t the outlet; have a proper outlet

installed by a qualied electrician.

This product is for use on a nominal 110 volt/20 amp dedicated circuit, and has a grounding plug that

looks like the plug illustrated below. A temporary adapter that looks like the adapter illustrated may be used

to connect this plug to a 2-pole receptacle as shown if a properly grounded outlet is not available. The

temporary adapter should be used only until a properly grounded outlet can be installed by a qualied

electrician. The green colored rigid ear-lug, or the like, extending from the adapter, must be connected to a

permanent ground such as a properly grounded outlet box cover. Whenever the adapter is used, it must be

held in place by a metal screw.

Spirit Fitness

IMPORTANT OPERATION INSTRUCTIONS

• NEVER operate this treadmill without reading and completely understanding the results of any operational change you

request from the computer console.

• Understand that changes in speed or incline do not occur immediately. Set your desired speed or incline level on the

computer console and release the adjustment key. The computer will obey the command gradually.

• Use caution while participating in other activities while on your Treadmill; such as watching television, reading, etc.

These distractions may cause you to lose balance which may result in serious injury.

• Do not use excessive pressure on console control keys. They are precision-set to function properly with little

nger pressure.

RECORD YOUR SERIAL NUMBER

Please record the serial number of this tness product in the space provided below. The serial number is located

at the front of the treadmill by the Power switch.

SERIAL NUMBER:

The self-addressed product registration card must be completed in full and returned to Spirit Fitness. You can also

go to www.spirittness.com/commercialwarrantyregistration.html under the Support tab to register online.

www.spirittness.com

CT900ENT PRE-ASSEMBLY

TOOLS INCLUDED:

8mm Allen Wrench

2 Phillips Screwdrivers

PARTS INCLUDED:

1 Main Frame

2 Uprights

1 Main Panel

1 Console

1 Console Bracket Cover

4 Handrail Covers

2 Upright Covers

2 End Caps

UNPACKING

1. Cut the straps and open box.

2. Locate the hardware package. The hardware is separated into four steps. Remove

the tools rst. Remove the hardware for each step as needed to avoid confusion.

The numbers in the instructions that are in parenthesis (#) are the item number from

the assembly drawing for reference.

Spirit Fitness

CT900ENT STEP ONE

HARDWARE FOR STEP 1

PART TYPE DESCRIPTION QTY

65 BOLT M10x1.5x60mm 10

79 LOCK WASHER 10 10

1. Loosen the 8 screws holding the motor cover in

place and remove the cover.

2. Uncoil wiring harness and run wires through the

RIGHT UPRIGHT (7).

3. Use 5 BOLTS (65) and 5 LOCK WASHERS (79)

to attach the RIGHT UPRIGHT (7) to the MAIN

FRAME (1). Do not pinch wires. Do not tighten

before putting the console on.

4. Use 5 BOLTS (65) and 5 LOCK WASHERS (79)

to attach the LEFT UPRIGHT (8) to the MAIN

FRAME (1). Do not tighten before putting the

console on.
