Speedtouch 190 Manuel

SpeedTouch™190

SIP Gateway

Operator’s Guide

Release R1.0

SpeedTouch™

190

Operator’s Guide

Release R1.0

Status v2.0

Reference E-DOC-CTC-20040422-0010

Short Title Operator’s Guide ST190 R1.0

communication of its contents is not permitted without written authorization from

THOMSON. The content of this document is furnished for informational use only, may be

subject to change without notice, and should not be construed as a commitment by

THOMSON. THOMSON assumes no responsibility or liability for any errors or inaccuracies

that may appear in this document.

E-DOC-CTC-20040422-0010 v2.0 3

Contents

1 SpeedTouch™190 Product Description ...................... 5

2 SpeedTouch™190 Product Configuration................... 9

3 SpeedTouch™190 Calling Services ............................ 25

E-DOC-CTC-20040422-0010 v2.0

1 SpeedTouch™190 Product Description

E-DOC-CTC-20040422-0010 v2.0 5

1 SpeedTouch™190 Product Description

Introduction The SpeedTouch™190 SIP analog telephone adapter allows regular phones, fax or

modems to call a compatible peer SIP User over a broadband Internet connection.

Contents This Operator’s Guide will teach you to configure every aspect of the Speed-

Touch™190 SIP Gateway.

Updates THOMSON continuously develops new solutions, but is also committed to improve its

existing products.

For more information on THOMSON’s latest technological innovations, documents and

software releases, please visit the SpeedTouch™ web site at:

http://www.speedtouch.com

1 SpeedTouch™190 Product Description

E-DOC-CTC-20040422-0010 v2.0

Product Layout

Indicator Description

Name State

A Power On Power On, normal operation

Off Power Off

B VOIP On Registration successful to the SIP server

Off Registration failed to the SIP server

C LAN On Ethernet connection with the user’s PC

Off No ethernet connection with the user’s PC

D WAN On Ethernet connection with the user’s Internet Gateway

Device

Off No ethernet connection with the user’s Internet Gateway

Device

A B D EC

F G I JH

1 SpeedTouch™190 Product Description

E-DOC-CTC-20040422-0010 v2.0 7

SIP Service

requirements

To be able to configure the SpeedTouch™190, following settings most be provided for

each user:

•A user name (logon ID)

•A password

•IP address or DNS equivalent of your SIP server

•Phone number

To learn how to configure the SpeedTouch™190,

proceed to “2 SpeedTouch™190 Product Configuration”

E TEL On Phone off hook

Off Phone on hook

Flashing The phone is ringing

F TEL To connect the user’s phone

G WAN To connect the user’s Internet Gateway Device

H LAN To connect the user’s local network

I RESET To reset the SpeedTouch™190

J 12V AC To connect the power supply

Indicator Description

Name State

1 SpeedTouch™190 Product Description

E-DOC-CTC-20040422-0010 v2.0
