SOUNDMASTER CD9180 Manuel utilisateur

CD9180 / English manual

ENG 1

LOCATION OF CONTROLS

1. Dir UP / ASP button

2. EQ button

3. MODE / PROG button

4. SKIP / SEARCH DN button

5. STOP button

6. PLAY / PAUSE button

7. SKIP / SEARCH UP button

8. LCD display

9. Battery compartment

10. Open knob

11. Volume knob

12. Phone jack

13. DC jack

14. Recharge switch

15. Recharge Indicator

PREPARATION BEFORE USING

Battery Installation

A T T E N T I O N !!!

On operation with standard/conventional batteries, be sure that the

charging switch „

RECHARGE

“ (14) is on „

OFF

“ position,

otherwise the

batteries may become hot and may explode.

CD9180 / English manual

ENG 2

1. Open Battery Compartment cover.

2. Insert 2 batteries ( UM-3, “AA”, LR6 or equivalent ) in the correct polarity as indicated.

(Heavy duty batteries are recommended).

3. Close the cover properly.

*In order to operate the player on batteries, the optional AC/DC adaptor must be

disconnected from the DC 4.5V Jack.

AC—

——

—DC Adaptor

*Before connection, make sure the AC voltage of the adaptor correspond to your local AC

outlet voltage.

1. Plug the DC output of the adaptor to the DC 4.5V jack.

2. Connect the adaptor (4.5V/600mA with polarity ) to a power outlet.

RECHARGEABLE BATTERY OPERATION

This unit can fully recharge the specified rechargeable battery, in approximately 15 hours.

The rechargeable batteries (NOT supplied) should be recharged before they are used for the

first time because they are low in power or if they have not been used for a long period (over

60 days).

1. Open the battery compartment cover and insert two of the recommended

rechargeable batteries, matching polarity. (1.2V 650mA).

(Both batteries must be of rechargeable nickel-cadmium type, otherwise the

batteries may explode or leak.)

2. Plug in the AC adaptor and set the Recharge switch to ON position to start charging.

(Use only the AC adaptor supplied with the set for charging.)

3. After 15 hours. Please unplug the AC adaptor and switch the Recharge switch to the

off

position.

(Do not charge continuously for 24 hours or more. Doing so can cause the

performance of the rechargeable battery to deteriorate.)

Note : • You may play DISCS whilst charging the batteries.

4. If the operating time decreases drastically even when the rechargeable

nickel-cadmium

batteries are properly recharge, purchase a new set of rechargeable nickel-cadmium

batteries.

5. When charging for the first time or after a long time, playing time may be reduced. In

this case, charge and discharge the batteries several times.

CD9180 / English manual

ENG 3

DISC PLAYING

Sound Effects

During playback you can choose between the following Sound Effects:” BBS, Pop, Jazz, Rock,

and Classic”, by pressing EQ BUTTON repeatedly. To turn off the effects, press the EQ

BUTTON repeatedly until the “Sound Effects” indicator disappears.

Getting Start

1. Insert the headphone/earphone plug to PHONE JACK.

2. Press the OPEN KNOB, and then the door opens, put a disc into the CD compartment with

label side upward.

3. Push the disc gently around the centre area until it clicks so that the disc fits into the pivot.

(To remove the disc: pick up the disc, holding the edge, while pressing the pivot gently.)

4. Close the door and press the PLAY/PAUSE BUTTON once.

5. The Display will show the total number of tracks/files/directories of the disc, and then it

begins to play the first track/file.

General Operation

PLAY/PAUSE BUTTON —Press once to start playback in the original order.

Press again to stop the disc play temporarily.

STOP BUTTON ■—Press once to stop playback.

Press again to turn off power.

SKIP/SEARCH BUTTONS —Press once to skip to next track or back to

previous track .

Press continuously to search forward or

backward .

DIR UP/ASP BUTTON —ASP ON/OFF ( For CD ).

—Directory UP ( For MP3 Disc ).

Resume function

This player is equipped with a resume function, means CD-disc will automatic start at position,

where CD-disc was stopped by last use. ATTENTION, this function works only, when no other

CD-disc was insert in meantime into the player. If you wish to start with track 1, press FR

button frequently until track 1 shown into display.

Automatic Turn Off (Auto Power Off)

If the player is in STOP mode for approximately 30 seconds, it will turn off automatically.

CD9180 / English manual

ENG 4

Various Playing Modes

MODE BUTTON —There are 3 kinds of function: ( FOR CD ) :

A. Repeat Play

During Play Mode

·Press the MODE BUTTON once to play current track repeatedly.

·The repeat indicator will appear in the display.

During Play Mode

·Press the MODE BUTTON twice to play the entire disc repeatedly.

·The repeat indicator will appear in the display.

NOTE –

––

–To cancel REPEAT PLAY simply press the MODE BUTTON until the repeat

Indicator disappears.

B. Intro Scan,

During Play Mode

·Press the MODE BUTTON three times.

·The INT indicator will appear in the display.

·Press the PLAY BUTTON to play the first 10 seconds of each track on the disc.

NOTE –

––

–To cancel INTRO SCAN, simply press the MODE BUTTON until the INT indicator

disappears.

C. Random Play

During Play Mode

·Press the MODE BUTTON four times.

·The SHUF indicator will appear in the display.

·Press the PLAY BUTTON, all the tracks on the disc will be played in random sequence.

After all the tracks have been played, the system will stop automatically.

NOTE –

––

–To cancel RANDOM PLAY, simply press the MODE BUTTON until the SHUF

indicator disappears.

MODE BUTTON —There are 3 kinds of function: ( FOR MP3 DISC ) :

A. Repeat Play

During Play Mode

·Press the MODE BUTTON once to play current track repeatedly.

·The repeat indicator will appear in the display.

During Play Mode

·Press the MODE BUTTON twice to play the ENTIRE DISC repeatedly.

·The repeat indicator will appear in the display.

During Play Mode

·Press the MODE BUTTON three times to play the current DIRECTORY repeatedly.

will appear in the display.·The repeat indicator

REPEAT PLAY, simply press the MODE button until theNOTE –

––

–To cancel

repeat indicator disappears.

CD9180 / English manual

ENG 5

B. Intro Scan

During Play Mode

·Press the MODE BUTTON four times.

·The INT indicator will appear in the display.

·Press the PLAY BUTTON to play the first 10 seconds of each track on the disc.

NOTE –

––

–To cancel INTRO SCAN, simply press the MODE BUTTON until the INT indicator

disappears.

C. Random Play

During Play Mode

·Press the MODE BUTTON five times.

·The SHUF indicator will appear in the display.

·Press the PLAY BUTTON, all the files on a disc to be played in a random sequence and

after all files are played, system will stop automatically.

NOTE –

––

–To cancel RANDOM PLAY, simply press the MODE BUTTON until the SHUF

indicator disappears.

Program Play ( FOR CD )

1. In stop mode, press the PROG BUTTON to make program memory.

2. “ ” will be displayed, “ 00” means track number to memory and “01” means program

number.

3. Press or button to select the desired track.

4. Press the PROG BUTTON to enter the track into memory, the program numbers which will

be increment one step.

※The program no. “01” has become “02” on the display.

5. Repeat step 3 and 4 until memory is full. ( 64 tracks )

6. Press BUTTON to start the program play.

7. To stop the program play, press the STOP BUTTON.

8. For program play in step “ 7 ”, press the PROG BUTTON, then the BUTTON.

9. To check the program memory, in program play mode, press the or BUTTONS.

10. To erase the program memory, open the door or turn off the power.

Program Play ( FOR MP3 )

1. In stop mode, press the PROG BUTTON to make program memory.

2. “ ” will be displayed, “ 000” means file number, “01” means program number.

3. Press the DIR UP/ASP BUTTON to select the desired directory, the display will become

“ ”, “01” means directory number.

4. Press the or BUTTONS to select the desired file.

5. Press the PROG BUTTON to enter the directory and file into memory. The program number

which will be increment one step.

※The program no. “01” has become “02” on the display.

6. Repeat step 3 and 5 until memory is full. ( 64 files ).

CD9180 / English manual

ENG 6

7. Press BUTTON to start the program play.

8. To stop the program play, press the STOP BUTTON.

9. For program play in step “ 8 ”, press the PROG BUTTON & BUTTON.

10. To check the program memory, in program play mode, press the or BUTTONS.

11. To erase the program memory, open the door or turn off the power.

※If you do not need to select directory but only select files, the above step 3 can be

skipped.

Digital Anti- Shock Operation

The DIGITAL ANTI-SHOCK PROTECTION function uses semiconductor memory to prevent

the unit from skipping when the unit is subjected to shocks and vibration during play.

When the PLAY/PAUSE BUTTON is pressed and the power turns on, the “ASP” appears and

the Digital Anti-Shock Protection function turns on automatically.

LOW BATTERY ALERT

When the low battery indicator appears on the display, please prepare to replace the new

batteries.

Switch off the volume restriction

To protect your hearing, after switching on the device, only reduced volume is available. You

can switch off this “Volume restriction”.

1 »EQ« press and hold.– Display: »HIGH« flashes for 5 seconds.

2 Press again the »EQ« button to switch off the volume restriction.

3 Switch off the “Volume restriction” with »EQ«.

Note:

■

The volume restriction is reactivated after switching off or changing the disk.

SPECIFICATIONS

Output Power : ≥15 mW ( 32 Ω)

Freq. Response : 100 ~ 20000 Hz

Power Source : 2×UM-3”AA” LR6 size batteries ( batteries not included )

4.5v(600mA) AC-DC adaptor

Dimensions : 141mm(W) ×140mm(D) ×26mm(H)

** For improvement purposes, specification and design are subject to change without notice. **
