Soundcore Zero Manuel utilisateur

Model No.: Z5180

V01

Soundcore Model Zero

User Manual

Uživatelská příručka | Brugervejledning | Benutzerhandbuch | Manual del usuario

Käyttöopas | Manuel de l’utilisateur | Manuale utente | Manual do Usuário

Användarhandbok | Gebruikershandleiding | Brukerhåndbok

取扱説明書 | 사용 설명서 | 用户手册 | 使用者手冊

Руководство пользователя |  | 

01 02

EN EN

Safety Instructions

• Avoid dropping.

• Do not disassemble.

• Do not submerge in water.

• Avoid extreme temperatures.

• Do not use the device outdoors during thunderstorms.

• Use original or certified cables.

• Do not use any corrosive cleaner/oil to clean.

What’s Included

User's manual

The adapter vary by region.

At a Glance

2 3 4 5

bass

AUX POWER

1BassUp button / BassUp indicator 6Power button

2Volume down control 7Power indicator

3Multi-function button 83.5mm audio input port (AUX)

4Volume up control Power port

5Bluetooth button / Bluetooth indicator Charging indicator

01 02

EN EN

Safety Instructions

• Avoid dropping.

• Do not disassemble.

• Do not submerge in water.

• Avoid extreme temperatures.

• Do not use the device outdoors during thunderstorms.

• Use original or certified cables.

• Do not use any corrosive cleaner/oil to clean.

What’s Included

User's manual

The adapter vary by region.

At a Glance

2 3 4 5

bass

AUX POWER

1BassUp button / BassUp indicator 6Power button

2Volume down control 7Power indicator

3Multi-function button 83.5mm audio input port (AUX)

4Volume up control Power port

5Bluetooth button / Bluetooth indicator Charging indicator

03 04

EN EN

Using Your Soundcore Model Zero

1. Turn On / O

ON Press and hold for more than 2 seconds.

OFF Press and hold for more than 2 seconds

a. Bluetooth mode

Bluetooth ON

Soundcore

Model Zero

bass

Enter Bluetooth Pairing Mode

Flashing Blue Bluetooth Pairing Mode

Solid Blue Connected to a device

2Enter True Wireless Stereo Group Mode / Disconnect True Wireless

Stereo

Double Flashing

White True Wireless Stereo Group Mode

Solid White Connected to True Wireless Stereo

bass

2 2

With True Wireless Stereo technology, you can pair your Soundcore

Model Zero with another Soundcore Model Zero to explore the best

sound eects with le and right sound channels separated on both

speakers.

03 04

EN EN

Using Your Soundcore Model Zero

1. Turn On / O

ON Press and hold for more than 2 seconds.

OFF Press and hold for more than 2 seconds

a. Bluetooth mode

Bluetooth ON

Soundcore

Model Zero

bass

Enter Bluetooth Pairing Mode

Flashing Blue Bluetooth Pairing Mode

Solid Blue Connected to a device

2Enter True Wireless Stereo Group Mode / Disconnect True Wireless

Stereo

Double Flashing

White True Wireless Stereo Group Mode

Solid White Connected to True Wireless Stereo

bass

2 2

With True Wireless Stereo technology, you can pair your Soundcore

Model Zero with another Soundcore Model Zero to explore the best

sound eects with le and right sound channels separated on both

speakers.

05 06

EN EN

Play / Pause

Play Next Song

Press to turn Bass Up on and o

Answer Call / End Call / Switch between a call on hold and an active

call

2s Reject Call

2s End current call and answer incoming call / End current call and

switch to call on hold

2s Switch audio source between Speaker and Phone

Put current call on hold and answer incoming call

2s Activate Siri / Other Voice Control Soware

Volume Up / Down

Solid White (Bluetooth indicator) On a Call

Flashing Blue (Bluetooth indicator) Incoming Call

When turned on, Soundcore Model Zero will automatically connect

to the last connected device if available. If not, press the Bluetooth

pairing button to activate pairing mode.

To pair a dierent device, press the Bluetooth button to re-enter

pairing mode. Then repeat the pairing steps.

Having connection problems? Remove Soundcore Model Zero from

your device’s Bluetooth history and ensure it’s less than 3 feet away.

Then try pairing again. To get the best sound quality, make sure

there is a clear line of sight between the connected device and your

speaker.

b. Multi-point play

1. Connect the first mobile phone to your Soundcore Model Zero, press the

Bluetooth button once on Soundcore Model Zero aer the connection is

successful.

2. Press the Bluetooth button on Soundcore Model Zero twice to enter

Bluetooth pairing mode.

3. Connect the second mobile phone to Soundcore Model Zero. Once the

second mobile phone is connected to Soundcore Model Zero, turn on the

Bluetooth of the first mobile phone, then find Soundcore Model Zero in your

pairing list. Click it for connection, make sure the connection is successful.

Note: Soundcore Model Zero can only play the music on one mobile phone at

a time.

05 06

EN EN

Play / Pause

Play Next Song

Press to turn Bass Up on and o

Answer Call / End Call / Switch between a call on hold and an active

call

2s Reject Call

2s End current call and answer incoming call / End current call and

switch to call on hold

2s Switch audio source between Speaker and Phone

Put current call on hold and answer incoming call

2s Activate Siri / Other Voice Control Soware

Volume Up / Down

Solid White (Bluetooth indicator) On a Call

Flashing Blue (Bluetooth indicator) Incoming Call

When turned on, Soundcore Model Zero will automatically connect

to the last connected device if available. If not, press the Bluetooth

pairing button to activate pairing mode.

To pair a dierent device, press the Bluetooth button to re-enter

pairing mode. Then repeat the pairing steps.

Having connection problems? Remove Soundcore Model Zero from

your device’s Bluetooth history and ensure it’s less than 3 feet away.

Then try pairing again. To get the best sound quality, make sure

there is a clear line of sight between the connected device and your

speaker.

b. Multi-point play

1. Connect the first mobile phone to your Soundcore Model Zero, press the

Bluetooth button once on Soundcore Model Zero aer the connection is

successful.

2. Press the Bluetooth button on Soundcore Model Zero twice to enter

Bluetooth pairing mode.

3. Connect the second mobile phone to Soundcore Model Zero. Once the

second mobile phone is connected to Soundcore Model Zero, turn on the

Bluetooth of the first mobile phone, then find Soundcore Model Zero in your

pairing list. Click it for connection, make sure the connection is successful.

Note: Soundcore Model Zero can only play the music on one mobile phone at

a time.

07 08

EN EN

c. AUX-In mode

AUX

AUX POWER

*SoundLine AUX cable sold separately.

Plugging in an audio cable will automatically switch to AUX mode.

When using AUX mode, control audio playback via the connected

device.

Charging your Soundcore Model Zero

AUX POWER

POWER

Slow Flashing Red (Power indicator) Low Battery

Solid Red (Power indicator) Charging

O Fully Charged

Use the included adapter to charge your Soundcore Model Zero and

make sure it is fully charged before its first use.

Disconnect your speaker from the charger when fully charged. Do not

charge your speaker for extended periods.

When not in use, store your speaker in a cool place.

07 08

EN EN

c. AUX-In mode

AUX

AUX POWER

*SoundLine AUX cable sold separately.

Plugging in an audio cable will automatically switch to AUX mode.

When using AUX mode, control audio playback via the connected

device.

Charging your Soundcore Model Zero

AUX POWER

POWER

Slow Flashing Red (Power indicator) Low Battery

Solid Red (Power indicator) Charging

O Fully Charged

Use the included adapter to charge your Soundcore Model Zero and

make sure it is fully charged before its first use.

Disconnect your speaker from the charger when fully charged. Do not

charge your speaker for extended periods.

When not in use, store your speaker in a cool place.

09 10

EN EN

Specifications

Specifications are subject to change without notice.

Input: 15 V 3A

Audio output: 15 W x 2 + 15 W x 2

Battery capacity : max. 6700 mAh

Charging time : 3.0 hours

Play time (varies by volume level and music content): 10 hours

Size: 256 x 128 x 240mm

Weight (without packaging): 3.9 kg / 138 oz

Bluetooth version: V5.0

Bluetooth range : 20 m / 66 

Anker Innovations Limited

Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong

Kong

Product Number Z5180

Bluetooth Speaker / Soundcore Model Zero

For FAQs and more information, please visit:

Please note that your rights under applicable law governing the sale of

consumer goods remain unaected by the warranties given in this Limited

Warranty.
