Sony DVS-7000A Manuel utilisateur

DIGITAL VIDEO SWITCHER

DVS-7000A

MAINTENANCE MANUAL Part 1

1st Edition

BKDS-7021/7021R/7021LR

BKDS-7022/7022R/7022LR

BKDS-7023/7023R/7023LR

TYPE-3D SWITCHER CONTROL PANEL

BKDS-7011/7011R/7011LR

BKDS-7012

TYPE-4D SWITCHER CONTROL PANEL

BKDS-7270

BKDS-7271

BKDS-7280

BKDS-7420

BKDS-7445

BKDS-7690

BZS-7020A

BKDS-2031

BKDS-2032

BKDS-2041

BKDS-2070

BKDS-7001

BKDS-7030

BKDS-7031

BKDS-7032

BKDS-7033

BKDS-7075

BKDS-7090

BKDS-7103

BKDS-7110

BKDS-7111

BKDS-7113

BKDS-7133

BKDS-7161

BKDS-7163

!WARNING

This manual is intended for qualified service personnel only.

To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that

contained in the operating instructions unless you are qualified to do so. Refer all servicing to

qualified service personnel.

!WARNUNG

DieAnleitung ist nur für qualifiziertes Fachpersonal bestimmt.

Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die

Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei

Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben

Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung

dazu besitzen.

!AVERTISSEMENT

Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien.Afin

de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les

réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.

Pour toute réparation faire appel à une personne compétente uniquement.

DVS-7000A Serial No. 10001 and Higher

BKDS-2031 Serial No. 10001 and Higher

BKDS-2032 Serial No. 10001 and Higher

BKDS-2041 Serial No. 10001 and Higher

BKDS-2070 Serial No. 10001 and Higher

BKDS-7001 Serial No. 10001 and Higher

BKDS-7011 Serial No. 10001 and Higher

BKDS-7012 Serial No. 10001 and Higher

BKDS-7021 Serial No. 10001 and Higher

BKDS-7022 Serial No. 10001 and Higher

BKDS-7023 Serial No. 10001 and Higher

BKDS-7011R Serial No. 10001 and Higher

BKDS-7021R Serial No. 10001 and Higher

BKDS-7022R Serial No. 10001 and Higher

BKDS-7023R Serial No. 10001 and Higher

BKDS-7011LR Serial No. 10001 and Higher

BKDS-7021LR Serial No. 10001 and Higher

BKDS-7022LR Serial No. 10001 and Higher

BKDS-7023LR Serial No. 10001 and Higher

BKDS-7030 Serial No. 10001 and Higher

BKDS-7031 Serial No. 10001 and Higher

BKDS-7032 Serial No. 10001 and Higher

BKDS-7033 Serial No. 10001 and Higher

BKDS-7075 Serial No. 10001 and Higher

BKDS-7090 Serial No. 10001 and Higher

BKDS-7103 Serial No. 10001 and Higher

BKDS-7110 Serial No. 10001 and Higher

BKDS-7111 Serial No. 10001 and Higher

BKDS-7113 Serial No. 10001 and Higher

BKDS-7133 Serial No. 10001 and Higher

BKDS-7161 Serial No. 10001 and Higher

BKDS-7163 Serial No. 10001 and Higher

BKDS-7270 Serial No. 10001 and Higher

BKDS-7271 Serial No. 10001 and Higher

BKDS-7280 Serial No. 10001 and Higher

BKDS-7420 Serial No. 10001 and Higher

BKDS-7445 Serial No. 10001 and Higher

BKDS-7690 Serial No. 10001 and Higher

BZS-7020A Serial No. 10001 and Higher

WARNING

This unit has no power switch.

When installing the unit, incorporate a readily

accessible disconnect device in the fixed wiring, or

connect the power cord to a socket-outlet which must be

provided near the unit and easily accessible, so that the

user can turn off the power in case a fault should occur.

WARNUNG

Dieses Gerät hat keinen Netzschalter.

Beim Einbau des Geräts ist daher im Festkabel ein leicht

zugänglicher Unterbrecher einzufügen, oder das

Netzkabel mu

mit einer in der Nähe des Geräts

befindlichen, leicht zugänglichen Wandsteckdose

verbunden werden, damit sich bei einer

Funktionsstörung die Stromversorgung zum Gerät

jederzeit unterbrechen lä

Attention-when the product is installed in Rack:

1. Prevention against overloading of branch circuit

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

make sure that the rack does not overload the supply

circuit.

2. Providing protective earth

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

confirm that the outlet is provided with a suitable

protective earth connection.

3. Internal air ambient temperature of the rack

When this product is installed in a rack, please make

sure that the internal air ambient temperature of the

rack is within the specified limit of this product.

4. Prevention against achieving hazardous

condition due to uneven mechanical loading

When this product is installed in a rack, please make

sure that the rack does not achieve hazardous

condition due to uneven mechanical loading.

DVS-7000AE MMP1

Table of Contents

Manual Structure

Purpose of this manual .............................................................................................. 3

Related manuals......................................................................................................... 3

Contents ..................................................................................................................... 4

1. Service Overview

1-1. DVS-7000A.................................................................................................1-1

1-1-1. Removal and Installation of Front Panel....................................1-1

1-1-2. Location of Main Parts...............................................................1-2

1-1-3. Inserting/Pulling Out of Plug-in Boards ....................................1-4

1-1-4. Capacitor for Data Backup.........................................................1-6

1-1-5. Spare Parts..................................................................................1-6

1-2. Control Panel...............................................................................................1-7

1-2-1. Opening and Closing of Panel....................................................1-7

1-2-2. Turning On/Off the Power Switch .............................................1-8

1-2-3. Removal of Exterior Parts..........................................................1-9

1-2-4. Location of Main Parts.............................................................1-11

1-2-5. Installation and Removal of Boards.........................................1-27

1-2-6. Replacement of Backup Memory IC........................................1-48

1-2-7. Spare Parts................................................................................1-49

2. Replacement of Main Parts

2-1. DVS-7000A.................................................................................................2-1

2-1-1. Replacement of Fan on the Rear Panel ......................................2-1

2-1-2. Replacement of Power Unit .......................................................2-3

2-2. Control Panel...............................................................................................2-4

2-2-1. Replacement of Rotary Encoder ................................................2-4

2-2-2. Replacement of Fader ................................................................2-6

2-2-3. Replacement of EL Display .......................................................2-7

2-2-4. Replacement of FDD (Floppy Disk Drive) Unit........................2-8

2-2-5. Replacement of Power Unit .....................................................2-10

http://getMANUAL.com

2DVS-7000AE MMP1

3. Troubleshooting (Control Panel)

3-1. Self Diagnostics Mode ................................................................................3-1

3-2. Switch Settings on the CPU-263 Board and LEDs Description .................3-2

3-3. Troubleshooting ........................................................................................3-10

3-3-1. Tools and Equipment Required for Troubleshooting...............3-10

3-3-2. Connecting the Test Terminal with Connector to This Unit ....3-12

3-3-3. Starting of the Self Diagnostics Mode .....................................3-13

3-3-4. Test Procedures ........................................................................3-15

3-3-5. Ending the Self Diagnostics Mode ...........................................3-34

4. Periodic Check and Maintenance

4-1. Cleaning ......................................................................................................4-1

4-1-1. Front Panel .................................................................................4-1

4-1-2. Fans ............................................................................................4-1

4-1-3. Track Ball (BKDS-7031) ...........................................................4-2

5. Overall Block Diagrams

5-1. DVS-7000A.................................................................................................5-2

5-2. BKDS-7011/7012........................................................................................5-5

5-3. BKDS-7021/7022/7023.............................................................................5-10

5-4. BKDS-7011R/7011LR ..............................................................................5-16

5-5. BKDS-702xR/702xLR ..............................................................................5-21

DVS-7000AE MMP1

Manual Structure

Purpose of this manual This manual is the maintenance manual part 1 of Digital Video Switcher DVS-7000A.

This manual is intended for use by trained system and service engineers, and

describes the information for general service and periodic maintenance with the

intention of servicing including the replacement of the principal blocks and mounted

circuit boards.

Related manuals The following manuals are prepared for DVS-7000A.

The part numbers of these manuals as of February, 1999 describe.

.User’s Guide (Supplied with BZS-7020A)

This manual describes the application and operation of DVS-7000A.

.Operation Manual (Supplied with DVS-7000A)

This manual describes the overview, system configuration examples and specifica-

tions.

.Installation Manual (Supplied with DVS-7000A)

This manual describes the information when installing DVS-7000A.

Part number : 3-201-863-01

.Maintenance Manual Part 2

The following manuals describe the detailed service information. For obtaining,

please contact your local Sony’s sale/service office.

Volume 1 (Block diagrams and Frame wirings)

Part number : 9-967-615-03

Supplement 4 Part number : 9-967-615-84

Volume 2

(Spare parts, Service overview and Replacement of main parts)

Part number : 9-967-616-03

Supplement 5 Part number : 9-967-616-85

Volume 3 (Semiconductor pin assignments)

Part number : 9-967-617-03

Supplement 3 Part number : 9-967-617-83

Volume 4 (Board layouts)

Part number : 9-967-618-03

Supplement 4 Part number : 9-967-618-84

4DVS-7000AE MMP1

.Maintenance Manual Part 2

Volume 5 (Schematic diagrams 1 A through I)

Part number : 9-967-624-03

Supplement 3 Part number : 9-967-624-83

Volume 6 (Schematic diagrams 2 K through Z)

Part number : 9-967-625-02

Supplement 4 Part number : 9-967-625-84

Contents This manual is organized by following sections.

Section 1 Service Overview

For DVS-7000A, this section describes the removal and installation of front panel,

location of main parts, inserting/pulling out of plug-in boards, capacitor for data

backup, and spare parts.

For control panel, this section describes the opening and closing of panel, removal of

exterior parts, location of main parts, installation and removal of boards, replace-

ment of backup memory IC and spare parts.

Section 2 Replacement of Main Parts

This section describes the main parts replacement.

Section 3 Troubleshooting (Control Panels)

This section describes the self diagnostics mode of the control panels.

Section 4 Periodic Check and Maintenance

This section describes the periodic check and maintenance.

Section 5 Overall Block Diagrams

This section describes the overall block diagrams.

1-1

DVS-7000AE MMP1

Section 1

Service Overview

1-1. DVS-7000A

1-1-1. Removal and Installation of Front Panel

(1) Loosen the four locking screws on the front panel using a flatblade screwdriver.

(2) Remove the front panel in the direction of the arrow.

(3) Install the front panel in the reverse order of the procedures (1) and (2).

Front panel

Locking screws

1-2 DVS-7000AE MMP1

1-1-2. Location of Main Parts

1. Plug-in Boards

1-1. DVS-7000A

1-1-2. Location of Main Parts

8BKDS-2041

Frame memory board

9BKDS-7133

Encoder board

0BKDS-7133

CRK analog component input board

!- BKDS-2031

Chromakey board

!= BKDS-2032

Chromakey upgrade board

!. BKDS-7161

Analog composite output board

or

@/ BKDS-7163

Serial digital output board

!, Output processor board

@- Cross point board

@= BKDS-7103

12 input serial digital board

@] BKDS-7111

Analog composite input board

or

@\ BKDS-7113

Serial digital input board

@[ BKDS-7110

Blank input adaptor board

3 (Spare)

4 and 5

6, 8 and 10

7, 9 and 11

12 and 13

14 and 15

16, 17 and 18

2IF-758 board

3MEM-94 board

4CA-35A board

5CPU-264 board

2Interface board

3Memory board

1CPU-264A board 1System control board

4Application board

5System control board

6BKDS-7420

Color correction board

or

7BKDS-7445

Frame memory adaptor board

6CC-81 board

or

7YC-59 board

8MY-66 board

9ENC-34 board

0ADC-22 board

!- CRK-10 board

!= CRK-11 board

![ Video mixer board

!] BKDS-7280

ME PVW board

!\ BKDS-2070

Enhanced wipe generator board

!; BKDS-7270

Key border board

or

!' BKDS-7271

Fine key/key border board

![ MIX-35 board

!] UP-10 board

!; BD-26 board

or

!' BD-35 board

!, OUT-9 board

!. DA-94 board

or

@/ SD-48 board

@- XPT-16 board

@= DI-36 board

@[ ADC-21 board

@] ADI-3 board

or

@\ DI-34 board

!\ WKG-12 board

Slot No. Option Board Standard Board Function Name

Autres manuels pour DVS-7000A

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sony Changer

Sony

Sony DVS-7250 Instructions de montage

Sony

Sony 26-483-01 Manuel d'instructions

Sony

Sony HDS-X3700 Manuel utilisateur

Sony

Sony MVS-8400 Manuel utilisateur

Sony

Sony XKS-C9111 Manuel utilisateur

Sony

Sony CAV-CVS12ES - Component Video Switcher Manuel utilisateur

Sony

Sony BRS-200 Manuel utilisateur

Sony

Sony MVS-3000A Guide de l'utilisateur

Sony

Sony ESBK-7052 Manuel utilisateur

Sony

Sony CAV-CVS12ES - Component Video Switcher Manuel utilisateur

Sony

Sony DFS-700 Manuel utilisateur

Sony

Sony DVS-9000SF Manuel utilisateur

Sony

Sony DMX-SW1 - Bravia Input Link Manuel utilisateur

Sony

Sony BVS-A3232 Manuel utilisateur

Sony

Sony SB-V60S Manuel utilisateur

Sony

Sony DVS-2000C Manuel utilisateur

Sony

Sony MVS-8000X-C Manuel utilisateur

Sony

Sony CCP-8000 Series Manuel utilisateur

Sony

Sony MVS-8000 Manuel utilisateur

Sony

Sony MK7807V1 Manuel

Sony

Sony XVS-9000-C Manuel utilisateur

Sony

Sony DVS-7200A Manuel utilisateur

Sony

Sony DVS-7000A Manuel utilisateur

Sony

Sony DVS-7200A Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
