SS-V831ED

Satellite Speaker

• 1 Satellite Speaker to Complete a 6.1/7.1 Channel Surround Sound System

• Adds Surround Back Channel Capability to 5.1 Channel Speaker Package

• Designed to Match the SA-VE835ED Speaker Package

• Extended Definition Tweeter for High Resolution Audio

• Optional Floor Speaker Stands: WS-FV10C

• Includes Pedestal Stand

General Features

• Silver Color Matches

WEGA® Television Sets

Audio Features

• Extended Definition Tweeter

— Frequency Response

Ideal for High Resolution

Audio

• Neodymium Magnets for

Tweeters — Superior

Power Handing and

Response

• Die-Cast Aluminum

Cabinets — Minimizes

Resonance

• Unique Enclosure Design

— Sloped Rear Baffle

Minimizes Standing Waves

• Voice Matched to SA-

VE835ED Speaker Package

Inputs

• Color Coded Spring

Terminals: Front, Center,

Surround

Convenience Features

• Additional Speaker to

Complement 5.1 Channel

Speaker Package

• Magnetic Shielding

• 8 ohm Impedance

• Optional Floor Speaker

Stands: WS-FV10C

KEY FEATURES

ADDITIONAL FEATURES

Product Information

SS-V831ED

Satellite Speaker

Specifications

Satellite Speaker

(SS-V831ED)

• Speaker System: 2-Way

Bass Reflex Magnetically

Shielded Type

• Speaker Unit: 21/4"x 2

Woofer Unit/ 3/4" Extended

Definition Tweeter

• Sensitivity: 87dB (1W/1M)

• Frequency Range:

120Hz - 70,000Hz

• Power Handling:

140 Watts Maximum

• Nominal Impedance: 8

ohms

Accessories

Supplied Accessories

• Instruction Manual

• Pedestal Speaker Stand (1)

• Speaker Screw and

Speaker Washer

• Speaker Cord (32' 91/4")

Weights & Measures

• Satellite Speaker

(SS-V831ED)

Approx. Dimensions

(W x H x D):

w/Grille and No Pedestal

Stand: 35/8"x7

1/4"x 57/8"

w/Grille and Pedestal

Stand: 37/8" x 83/4" x 61/4"

Approx. Weight:

w/Grille and No Pedestal

Stand: 2 lbs. 14 oz.

w/Grille and Pedestal

Stand: 3 lbs. 1 oz.

ADDITIONAL FEATURES

Product Information

©2002 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony, CineMotion, Hi-Scan, Jog Dial, Precision Drive, and WEGA are trademarks of Sony. Dolby Digital

is a registered trademark of Dolby Laboratories Licensing Corporation. dts is a registered trademark of Digital Theater Systems, Inc. All other trademarks and logos are property of their respective owners.

Optional Floor Speaker Stands:

WS-FV10C

SA-VE835ED Complimentary

5.1 channel speaker package
