HYBRID NETWORK FILESERVER

FSV-VN7

FSV-CS7

INSTALLATION MANUAL

1st Edition

FSV-VN7/CS7

!WARNING

This manual is intended for qualified service personnel only.

To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that

contained in the operating instructions unless you are qualified to do so. Refer all servicing to

qualified service personnel.

!WARNUNG

Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.

Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die

Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei

Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen.Andere als die angegeben

Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung

dazu besitzen.

!AVERTISSEMENT

Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien.Afin

de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les

réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.

Pour toute réparation faire appel à une personne compétente uniquement.

FSV-VN7/CS7 1

Table of Contents

4. Troubleshooting

5. Appendix

5-1. License Agreement .........................................................5-1

5-2. IP Address Change by Command Line ..........................5-1

5-3. Mount..............................................................................5-1

5-4. System Shutdown and Reboot ........................................5-1

Manual Structure

Purpose of this manual ................................................................. 2

Related manuals ........................................................................... 2

1. Introduction

2. Tool and Measuring Instruments

3. Installation Procedure

3-1. Configuration ..................................................................3-2

3-1-1. Prerequisite for Connection...................................3-2

3-1-2. Configuration ........................................................3-2

3-2. Setting .............................................................................3-5

3-2-1. LIB-162 (AIT Library) ..........................................3-5

3-2-2. CSM-20 (SAIT Library)........................................3-5

3-2-3. Your PC for Webmin Access ................................3-6

3-2-4. FSV-VN7 (Main Server) .......................................3-6

3-2-5. FSV-CS7 (Cache Server) ......................................3-8

3-3. Library Configuration .....................................................3-9

3-3-1. License Registration ..............................................3-9

3-3-2. Verification of Library Connection .......................3-9

3-3-3. Verification of Firmware Revision .....................3-10

3-4. System Settings.............................................................3-11

3-4-1. Main Server Time Setting ...................................3-11

3-4-2. NTP Setting .........................................................3-12

3-4-3. Cache Server Time Settings ................................3-12

3-5. Volume Registration .....................................................3-12

3-5-1. Start-up ................................................................3-12

3-5-2. Volume Registration ...........................................3-13

3-5-3. Final Verification of Volumes.............................3-14

3-6. Final Verification ..........................................................3-15

3-6-1. Alert Messages ....................................................3-15

3-6-2. Mount ..................................................................3-15

3-6-3. Alert Mail ............................................................3-17

3-6-4. Migration and Reload to/from Tape and Cache

Server ..................................................................3-18

3-6-5. Shutdown of the HNF System.............................3-19

3-6-6. Restart of the HNF System..................................3-19

3-7. Connection of UPS .......................................................3-20

3-8. UPS Setting...................................................................3-20

2FSV-VN7/CS7

Purpose of this manual This is the Installation Manual of Hybrid Network Fileserver FSV-VN7/CS7.

This manual describes the information items that premise the service based on the

components parts such as introduction, tool and measuring instruments, installation

procedure, troubleshooting, assuming use of system and service engineers.

Related manuals Besides this “Installation Manual”, the following manuals are available.

• Administrator’s Guide (Supplied with this unit.)

This manual is necessary for application and operation of this unit.

Part number: 3-991-690-XX

Manual Structure

1-1

FSV-VN7/CS7

STANDBY

MENU ENTER CANCEL

ERROR

STANDBY

MENU ENTER CANCEL

ERROR

STANDBY

MENU ENTER CANCEL

ERROR

STANDBY

MENU ENTER CANCEL

ERROR

ACY-DR162 (AIT Drive)

SDX3-100C or

SDX4-200C

Hybrid Network Fileserver (this system)

Management

Software

Basic System

Option units

Cleaning Tape

Application

Server

Cache Server

Cache

Server

Switching Hub

Main Server

AIT Library

Administrator's

Computer

Web Administration Screen

Existing LAN

This manual describes how to install an HNF (Hybrid Network Fileserver).

When installing an HNF, refer to this manual accordingly, although it is not bundled in the product.

The HNF can extend 8 units of FSV-CS7 (Cache Server) and up to 4 units of LIB-162/A3, A4 (AIT

Library) or up to 2 units of CSM-20 (SAIT Library) to meet the customer’s requirement.

The detail of connection is described in Section 3-1 Configuration.

This system is a hybrid NAS (Network Attached Storage) device that is composed of a main server, a

cache server, an AIT Library and a SAIT Library into an integrated storage system. It can be mounted

from an application server as a dedicated storage system. Using the pre-installed hierarchical storage

management software, each component in the system is configured to automatically provide optimum

access based on frequency of data use. All system settings and maintenance can be performed remotely

from a web-based administration screen.

System Example with AIT Libraries (LIB-162)

Section 1

Introduction

1-2

FSV-VN7/CS7

ACY-DR20 (SAIT Drive)

SAIT1-500

Hybrid Network Fileserver (this system)

Management

Software

Basic System

Option units

Cleaning Tape

Application

Server

Cache Server

Cache

Server

Switching Hub

Main Server

SAIT Library

Administrator's

Computer

Web Administration Screen

Existing LAN

System Example with SAIT Libraries (CSM-20)

1-3

FSV-VN7/CS7

List of models

Model Name Serial Number Remarks

FSV-VN7 (Main Server)

LIB-162/A3 (AIT Library) 1,096,001 thru 1,196,021 Up to 4 units connectable

1,362,601 thru 1,382,600

1,382,601 thru 1,387,600

2,478,601 thru 2,479,600

2,479,601 thru 2,480,600

LIB-162/A4 (AIT Library) 2,505,001 thru 2,506,000

2,507,001 thru 2,508,000

CSM-20S (SAIT Library) 2,541,501 thru 2,542,500 Up to 2 units connectable

FSV-CS7 (Cache Server) 1,038,001 thru 1,040,000 Up to 8 units connectable

FZLH16AL *1—License

FZLH20SL *2—License

1000 BASE-T compatible —Recommended hub: CentreCom

switching hub AT-GS916GB (Allied Telesyn)

ACY-DR162/A3L (AIT3 Drive) 1,720,001 thru 1,730,000

ACY-DR162/A4L (AIT4 Drive) 2,497,001 thru 2,497,500

ACY-DR20/S1 (SAIT1 Drive) 1,412,001 thru 1,422,000

SDX3-100C (AIT3 data media) 15 tapes for each AIT Library

SDX4-200C (AIT4 data media) (Mix of AIT3 and AIT4 is not allowed in

one library.)

Cleaning Tape —One for each AIT Library

SDX1-CL (for AIT3 drives) (It needs to be a specified model to the

SDX4-CL (for AIT4 drives) library type.)

Cleaning tape —One tape for each SAIT Library

SAIT1-CL (for SAIT1 drives)

19”Mount Kit (ACY-RK2) 1,193,001 thru 1,203,000 For LIB-162 (AIT Library)

19”Mount Kit (ACY-RKSL) —For CSM-20 (SAIT Library)

Magazine Kit (ACY-MZ20) —For CSM-20 (SAIT Library)

Barcode Labels (ACY-BL60A) 1,745,001 thru 1,755,000 For LIB-162 (AIT Library)

UPS

Recommended UPS: Smart-UPS 1500 RM

(SUA1500RMJ2U)

Dedicated serial cable for UPS 940-0024C

(AP9824LJ (Interface Kit: C))

The package for UPS is required.

(Supplied by WW Service) apcupsd-std-3.10.13-1.i386.rh8.rpm

(Supplied by WW Service)

*1: When installing optional AIT Library(ies), have other FZLH16AL (License) for each AIT Library.

*2: When installing optional SAIT Library(ies), purchase the FZLH20SL (License) for each SAIT Library.

2-1

FSV-VN7/CS7

This section describes the general tools for installation on this product.

General Tools

General tools, such as a screwdriver required to install an HNF, are shown in this list.

Tools whose names are displayed in blue have hyper-link to the details of the specification.

You may be able to get the equivalent one in your market.

Description SONY Parts No. Remarks

Torque Drivers and Bits for assembly —assembly and disassembly

Notebook PC —

Ethernet Cable (Cat5 Network Cable) At least 1.5 m length

USB keyboard —

VGA Display —

Section 2

Tool and Measuring Instruments
