Integrated Remote

Commander

Operating Instructions

RM-AV2500

WARNING

To prevent fire or shock

hazard, do not expose the

unit to rain or moisture.

To avoid electrical shock, do

not open the cabinet. Refer

servicing to qualified

personnel only.

WARNING

You are cautioned that any changes or

modifications not expressly approved in

this manual could void your authority to

operate this equipment.

For the customers in the USA

Owner’s Record

The model number is located on the front

panel.

The serial number is located on the inner

side of the battery compartment.

Record these numbers in the spaces

provided below. Refer to them whenever

you call upon your Sony dealer

regarding this product.

Model No. RM-AV2500

Serial No.

NOTICE FOR THE CUSTOMERS IN

THE U.S.A.

NOTE

This equipment has been tested and

found to comply with the limits for a

Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are

designed to provide reasonable

protection against harmful interference

in a residential installation. This

equipment generates, uses, and can

radiate radio frequency energy and, if

not installed and used in accordance with

the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

harmful interference to radio or

television reception, which can be

determined by turning the equipment off

and on, the user is encouraged to try to

correct the interference by one or more of

the following measures:

–Reorient or relocate the receiving

antenna.

–Increase the separation between the

equipment and receiver.

–Connect the equipment to an outlet on

a circuit different from that to which

the receiver is connected.

–Consult the dealer or an experienced

radio/TV technician for help.

Features

The RM-AV2500 Remote Commander

provides centralized control of all your

AV components from a single remote

commander and saves the trouble of

operating different AV components with

different remote control devices. The

following are its main features.

Centralized control of Sony AV

components with this one remote

commander

This Commander is preset at the factory

to operate Sony brand components, so

you can use it out of the box as a control

center for your Sony AV components.

Remote control signals for non-Sony

components are also preset

This Commander is preset for most major

brands components including Sony. You

can remote control your components by

setting their code numbers (page 8).

Learning function for programming

other remote control signals you

need

This Commander has a learning function,

to learn remote control signals to operate

non-preset components or functions

(page 15).

In addition, the Commander can learn

remote control signals (infrared signals

only) of non-Audio Visual components

such as air-conditioners, lights, etc. (some

specific appliances or functions may not

be available) (page 35).

Setting a maximum of 24 macro

commands of a maximum of 32

successive steps

A maximum of 24 macro commands

which provide a maximum of 32

successive steps by pressing a single

button can be set (12 system control

macros and 12 component macros).

Macro execution speed is changeable.All

power on/off macro commands for Sony

components are preset at the factory.

Multi component in one screen

When you operate a lot of equipment all

together, you need not change the screen.

When watching a DVD, the DVD run

system key, the Power key for TV and

Receiver or the input change key can be

displayed on one screen, and it can be

operated, without switching the screen.

Alias function

Keys memorized on other screen can be

link, it is not necessary to learning again.

For example, it is useful to display the

Power key for TV or the input change

key on the CABLE screen (page 43).

Channel macro function allows you

to select a channel with a single key

Up to 4 key steps can be programmed on

macro keys. If you set the key operations

for entering a channel number on a

macro key, you can select the channel by

pressing that macro key (page 41).

Easy-to-operate touch key LCD with

blue back light

This Commander has a touch key LCD

that changes the key display according to

the selected component. The Commander

is easy to operate as only the keys

necessary to operate the selected

component are displayed. The display

backlight allows operation even in the

dark.

Table of Contents

Getting Started

Installing the Batteries ......................................................................................................... 6

When to replace the batteries.............................................................................................. 6

Location and Function of Controls ....................................................................................... 7

Basic Operations

Setting the Code for PresetAudio and Visual Components ................................................. 8

Setting a component code ................................................................................................... 8

Checking if the code number works ................................................................................ 10

Finding a component code with the Search function.................................................... 11

Operating Your Components with the Remote Commander .............................................. 13

To control the volume ........................................................................................................ 14

Notes on operating your components ............................................................................. 14

Using Non-Preset Remote Control Operations — Learning Function ................................ 15

For accurate learning ......................................................................................................... 19

Changing or erasing the function of a taught key or button ....................................... 19

Advanced Features

Controlling theVolume ofVisual Components Connected to anAudio System ................. 21

Executing a Series of Commands — System Control Functions......................................... 22

Programming a series of commands to the SYSTEM CONTROL buttons ................ 23

Notes on System Control Operations .............................................................................. 27

Programming a series of commands to the Component Select buttons..................... 27

Changing the interval between operation steps ............................................................ 29

Adding an Extra Function to the Component Select Buttons............................................. 30

Programming the Power-On command of the selected component

(for Sony components only) ........................................................................................... 30

Adding a command that is required when selecting a component ............................ 32

Copying the settings of a Component Select button to another button ........................... 34

Programming a Frequently Used Key Operation for SYSTEM CONTROL Buttons ............... 35

Notes on learning the signals of an air-conditioner ...................................................... 37

Transferring Data between Remote Commanders.............................................................. 37

Transferring data ................................................................................................................ 37

Receiving the data ..............................................................................................................40

Selecting a Channel with a Single Key Press — Channel Macro Function ......................... 41

Creating an Alias Component key (ALIAS).......................................................................... 43

Using Other Functions

Locking the Controls — Hold Function............................................................................... 46

Protecting your settings — Preset Lock Function .............................................................. 46

Changing theAuto Power-Off Time of the Commander ..................................................... 47

Adjusting the Backlight of the Display Window ................................................................. 48

Setting the Key-Touch Beep................................................................................................ 50

Adjusting the beam interval to avoid key misoperation.................................................... 51

Additional Information

Precautions ......................................................................................................................... 54

Maintenance ....................................................................................................................... 54

Specifications...................................................................................................................... 54

Troubleshooting .................................................................................................................. 55

Appendix

Table of Preset Functions.................................................................................................... 59

TV.......................................................................................................................................... 59

VCR....................................................................................................................................... 60

DVD ...................................................................................................................................... 60

CBL (Analog Cable box) .................................................................................................... 61

CBL (Digital Cable box) ..................................................................................................... 62

SAT........................................................................................................................................ 63

AMP...................................................................................................................................... 64

DVR (Digital video recorder)............................................................................................ 65

CD ......................................................................................................................................... 66

MD ........................................................................................................................................ 66

DAT....................................................................................................................................... 67

TAPE ..................................................................................................................................... 67

LCD Touch-Key Display Table............................................................................................... 68

Quick Reference of Operations........................................................................................... 74

Index ......................................................................................................................Back cover

Getting Started

Installing the Batteries

Slide open the battery compartment lid

and insert four size AA(R6) batteries (not

supplied). Be sure to line up the + and –

on the batteries with the + and – on the

battery compartment.

When to replace the batteries

Batteries for remote control

operation and backlight (four

size AA (R6) batteries)

Under normal conditions, alkaline

batteries will last up to 5 months. If the

Commander does not operate properly,

batteries might be worn out and Eis

displayed on the LCD touch panel. When

the display dims or the backlight for the

touch keys grows dim, replace the

alkaline batteries with new ones.

Note

Do not take more than one day to replace the

batteries; otherwise, your setting of the code

numbers (page 8) and learned remote control

signals (page 15) will be erased.

Notes on batteries

•Do not mix old batteries with new ones or

mix different types of batteries together.

•If the electrolyte inside the battery should

leak, wipe the contaminated area of the

battery compartment with a cloth and replace

the old batteries with new ones. To prevent

the electrolyte from leaking, remove the

batteries when you plan not to use the

Commander for a long period of time.

MENU EXIT

SYSTEM CONTROL

MUTING

LIGHT COMMANDER OFF

RECALL

AMP CD

CBL SAT

DVR

TAPE

VCR

DVD

CHANNEL

VOLUME

ABC

8LIGHT button (page 49)

Used to light up the LCD display in

the dark. Press the button once to turn

on the light, and once again to turn it

off. You can also set the backlight to

go off automatically after a certain

period of time.

9Component Select buttons

Selects the component to control.

0MORE button (page 23)

Displays the SYSTEM CONTROL

buttons and number keys.

qa SYSTEM CONTROL buttons (page

22)

You can program up to 32 consecutive

key operations to each of the three

SYSTEM CONTROL buttons. You can

automatically carry out the entire

program by pressing one button.

qs MENU button

Calls up the menu display of the

buttons or keys that have menu

function.

qd OK button and Cursor Control

buttons (page 15)

qf EXIT button

Used to exit the setting menu.

*Note on the VOLUME +/– and

MUTING buttons

The Commander controls or mutes the TV’s

volume when you select a visual component.

The Commander controls or mutes the

amplifier’s volume when you select an audio

component.

You can change this setting also (page 21).

Note on the power on and off of the

Remote Commander

To turn on, press any button except the

COMMANDER OFF button or touch the screen.

To turn off, press COMMANDER OFF, or if

you do not use the Commander, it

automatically turns off after 10 minutes. This

interval can also be changed (page 47).

Location and Function

of Controls

1Component display area

Displays the name of the component

selected.

2LCD touch key display (page 9)

The keys used for operating each

component are displayed.

Note

Do not press the touch keys using sharp

objects such as pins or ball-point pens.

3VOLUME +/– buttons*(page 14, 22)

Adjusts the volume.

4CHANNEL +/– buttons

Selects the channel.

5RECALL button (page 44)

6MUTING button*(page 14, 22)

Mutes the audio. Press the button

once again to resume at the previous

volume.

7COMMANDER OFF button

Turns the power of the Commander

off.

Basic Operations

Setting the Code for

Preset Audio and Visual

Components

The Commander is preset at the factory

to operate Sony brand AV components

(see the table below). If you are using the

Commander with a factory-set Sony

components, skip the following

procedures.

You can use the Commander with other

preset AV components also. To use with

other AV components, you need to follow

the procedures to set the correct codes for

each component.

*Analog audio compact cassette deck

Compo-

nent Select

Button

CBL

SAT

DVD

DVR

VCR

AMP

TAPE

Factory setting

Sony TV

Sony digital

cable box

Sony satellite

tuner

Sony DVD

player

Sony digital

video recorder

Sony TV/Sony

VHS VCR

Sony VHS VCR

(VTR3)

Sony amplifier

Sony CD player

Sony MD deck

Sony cassette

deck

Sony TV/Sony

DVD player

Preset

component(s)

Cable box

Satellite tuner

DVD player

Digital video

recorder

TV/VCR

VCR

Amplifier

CD player

MD deck

Cassette deck*

TV/DVD

See “Table of Preset Functions” (page 59)

for the functions of keys and buttons as

for each component.

Setting a component code

Example: To set up a Philips TV

1See the tables in the supplied

“Component Code Numbers,”

and find the four-digit code

number for the desired

component.

If more than one code number is

listed, use the number that is listed

first.

For example, to set up a Philips TV,

you would use the code number 8056.

The first digit of the component code

number means the component

category (TV, VCR, etc.). For further

details, see the tables in the supplied

“Component Code Numbers.”

2While pressing COMMANDER

OFF, press MUTING.

All the component names in the

display flash.

3Press the Component Select

button for the desired component.

The selected component remains

displayed, and the 0 – 9, ENTER and

DISPLAY keys flash.

4Press the four-digit component

code number followed by the

ENTER key on the touch-key

display.

A beep sounds, and the code number

and “ENTER” appear twice.

5If you want to set a code for

another component, repeat Steps

3 and 4.

6Press COMMANDER OFF.

Notes

•If you press a component code number that is

not on the table in the supplied “Component

Code Numbers,” the Commander beeps and

“NG” flashes after you press the ENTER key.

If this happens, check the component code

number, and try setting again.

•If you do not input anything into the

Commander for over two minutes between

each step, the setup procedure will be

canceled. To set the code, you must press

MUTING again while pressing

COMMANDER OFF.

•The first digit of the component code number

means the component category (TV, VCR,

etc.). The component corresponding to the

four-digit component code number is preset

in Step 4.

To check which code number is

set

Press the DISPLAY key in Step 3 to 5. The

code number and “ENTER” appear

twice.

Continued

4If you have succeeded, check that

the Commander is operating the

other functions of your

component, such as channel and

volume control.

See page 13 for details.

5Press COMMANDER OFF.

If the Commander does not seem to

be working

Try repeating these setup procedures using the

other codes listed for your components (page

8).

Notes on keys which have

“learned” a remote control

signal already

If another signal has already been

programmed on that key or button by the

learning function (page 15), that

“learned” signal will work even after you

set the component code number. To use it

as a preset component key or button, first

erase its learned signal (page 19).

Note on the touch-key display

When you set a component code number,

only the keys that have been preset with

the signals for the desired component

will be displayed. Preset signal of each

key varies depending on the brand.

By using the learning function, you can

program remote control signals to both

the displayed keys and keys that are not

displayed (page 15).

Checking if the code number

works

1Press the corresponding

Component Select button for the

component you have set up.

The Commander turns on and the

touch-keys appear on the display.

2Power on the component with its

power switch.

3Aim the Commander at the

component and press the POWER

key in the touch-key display.

When the remote control signal is

sent, is shown on the display.

The component should power off.

Setting the Code for Preset Audio

and Visual Components

(continued)

Autres manuels pour RM-AV2500 - Integrated Remote Commander

Table des matières

Autres manuels Sony Télécommande

Sony

Sony RM-X4S Operating Instructions (primary... Manuel utilisateur

Sony

Sony RM-VZ220 Manuel utilisateur

Sony

Sony SCPH-10173 Manuel utilisateur

Sony

Sony RM-PP404 Manuel utilisateur

Sony

Sony RM-V210T Manuel utilisateur

Sony

Sony RM-AV2100B Operating Instructions (primary... Manuel utilisateur

Sony

Sony RMT-VP1K Manuel utilisateur

Sony

Sony RM-IP10 Manuel utilisateur

Sony

Sony RM-X5S Manuel utilisateur

Sony

Sony RM-VL610 - Integrated Remote Commander Manuel utilisateur

Sony

Sony RMT-NWS20 Manuel utilisateur

Sony

Sony RM-LJ312 Manuel utilisateur

Sony

Sony RM-V310 Manuel utilisateur

Sony

Sony CDX-T68PKG - Cdxt68x & Rmx69rf Manuel utilisateur

Sony

Sony RM-LJ302 Manuel utilisateur

Sony

Sony RM-VL1000T Manuel utilisateur

Sony

Sony Remote Commander RM-V7 Manuel utilisateur

Sony

Sony RM-V211T Manuel utilisateur

Sony

Sony RM-VL700T Manuel utilisateur

Sony

Sony RM-VZ220 Manuel utilisateur

Sony

Sony RM-SC200 - S Link Remote Manuel utilisateur

Sony

Sony RM-VL600T Manuel utilisateur

Sony

Sony RM-S1AM Manuel utilisateur

Sony

Sony RM-DR1 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
