Sony S Series Manuel utilisateur

Sony Professional Europe2014 Sony Professional Europe2014

Ultra Short Throw Projectors

VPL-SX631, VPL-SW631, and VPL-SW636C PC/Less

Sony Professional Europe2014

Why Sony

More than 40 years accumulated Projector technology

In house Key device (LCD)

Cutting edge core technology

4k SXRD Technology (used in D-Cinema, Simulation, H Cinema)

3D / 4K solution from Lens to Living Room

Consumer Product Synergy enhancement

Business group merged for joint development

Developing the future of display technology

Thin Wrapped OLED / RGB Laser, Phosphor Laser/3 LCD

BRAVIA PRO

Sony Professional Europe2014

Why Sony Projectors

Organic Inorganic

Brighter Images

Better on the eyes

Better Grey Scale

Color alignment

Less Bright than spec

(Colour Brightness)

Colour Break up

Blurring / Bleed

(moving images)

3LCD System

Single Chip DLP System

Inorganic polarizer

3LCD Panels

Sony’s BrightEra with long lasting optics deliver higher picture quality,

substantially brighter images, higher efficiency, better contrast,

consistent colour stability and longer durability and usability.

Sony Professional Europe2014

Model Resolution Features Brightness Replacement Resolution Features Brightness

VPl-SX630 XGA 3200lm VPL-SX631 XGA 3300lm

VPL-SW620 WXGA 2600lm No replacement

VPL-SW620C WXGA Interactive 2600lm No Replacement

VPL-SW630 WXGA 3100lm VPL-SW631 WXGA 3300lm

VPL-SW630C WXGA Interactive 3100lm No Replacement

VPL-SW635C WXGA Interactive / PC Less 3100lm VPL-SW636C WXGA Interactive / PC Less 3300lm

Model Transition

The New Models are available from January 2016.

S Series UST Projectors – General Information

Sony Professional Europe2014

S Series Ultra Short Throw Projectors without the wall mount are available on special Tender Deal request

Bundled BOM (Projector & Mount) need to be set up

Information provided when available

S Series UST Projectors – General Information

Sony Professional Europe2014

S Series UST Projectors – General Information

Model Main Specification

VPL-SX631 3300lm, XGA, 2500:1, HDMI, 2X RGB, RJ45, Opt. Wireless, Mic, 6.9Kg

VPL-SW631 3300lm, WXGA, HDMI, 2X RGB, RJ45, Opt. Wireless, Mic , 6.9Kg

VPL-SW635C 3300lm,PC Less, WXGA, 2500:1, HDMI, 2X RGB, RJ45, Interactive

−Applications:

−Secondary Schools (Shadow-less projection)

−Corporate (Open Space environments)

−PC/Less Operation (VPL-SW636C)

−Predecessor models:

−VPL-SX60, VPL-SW630 and VPL-SW635C

−No Replacement for VPL-SW620 and VPL-SW620C

−Prime Support Contract:

−3 years and 3000 hours Lamp

−Availability:

−All Models: January 2016

XGA, WXGA 3300lm, 3LCD, UST Projectors

Sony Professional Europe2014

2500lm

3500lm

3000lm

VPL-EW295

3700lm

VPL-EX295

3700lm

VPL-EW2455

3100lm

VPL-EX255

3200lm

VPL-EW235

2600lm

VPL-EX2235

2700lm

Replacement ST / UST Interactivity

Complete Education Line Up – Product Positioning

13 models* to fit every classroom needs (Brightness, Interactivity)

*included E200 Series replacement models

VPL-SX236

3200lm

0.46:1 TR.

VPL-SX226

2700lm

0.46:1 TR.

VPL-SW225

2600lm

0.46:1 TR.

VPL-SW235

3000lm

0.46:1 TR.

VPL-SX631

3200lm

0.27:1 TR.

VPL-SW631

3100lm

0.27:1 TR.

VPL-SW636C

3100lm

0.27:1 TR.

PC Less

Sony Professional Europe2014

S Series UST Projectors – Target Markets

Education – Secondary School

Shadow-Less Projection / Short Throw 0.27:1

Bright Era 3LCD Technology (Better Colour, Durability)

3 Brightness Mode (High, Standard, ECO)

8,000hr Lamp Life (TCO / Long lamp life)

Security Lock / Password Protected

Corporate – Open Space / Small rooms

Multi-input (RGB, HDMI, Video)

PC/Less Operation (VPL-SW635C)

8,000hr Lamp Life (TCO / Long lamp life)

ECO Power Saving (Brightness, Power Down)

Bright Era 3LCD Technology (Better Colour, Durability)

Sony Professional Europe2014

S Series UST Projectors – New Key Features

High Image Quality

New color/white balance setting, provides

clearer text & better white.

Clear edge

Clear and correct color

Whiter

High Image Quality

New Gamma curve setting provides richer

color and clear images in all contents.

Richer

Color

Brighter

Sony Professional Europe2014

S Series UST Projectors – New Key Features

User Input Labeling

Customize labeling on inputs to suit customers

Connected devices . . . .

Input A = PC Computer

Input B = DVD Player

New Wall Mount

PSS-645 designed to increase screen within

Low celling classrooms.

Remove upper part of the baseplate
