FLAT WIDE DISPLAY MONITOR

FWD-40LX2F

FWD-40LX2X

FWD-32LX2F

FWD-32LX2X

KLH-W32

KLH-W26

PROTOCOL MANUAL

1st Edition

FWD-40LX2F/40LX2X/32LX2F/32LX2X

KLH-W32/W26

Table of Contents

1. Communication Parameters .......................................................... 1

2. Pin Assignment ...................................................................................... 1

3. Communication Data Format ......................................................... 1

4. General Function ................................................................................... 3

5. Picture/Sound ........................................................................................ 11

6. Size/Shift .................................................................................................. 13

7. Status Enquiry ....................................................................................... 16

8. User Reset ............................................................................................... 20

9. Service ........................................................................................................ 20

FWD-40LX2F/40LX2X/32LX2F/32LX2X

KLH-W32/W26

1. Communication Parameters

Communication Method RS-232C

Synchronous Method Asynchronous

Baud Rate 9600 bps

Character Length 8bit

Parity None

Start Bit Length 1bit

Stop Bit Length 1bit

Flow Control None

2. Pin Assignment

The control command is not acceptable for 3 seconds after

the power is turned on from the standby state and for 5

seconds after the power is turned on when AC is set to ON

from OFF state. Send the command after waiting each

required time. In the case when the power is turned on

from the standby state, the starting up by using the timer

(KLH-W26/W32 does not have this function), the power

key of main unit or the remote commander is included as

well as the command from RS-232C.

12345

Monitor side : D-sub

_External view _

6789

12345

6789

Host side : D-sub 9pin

_External view _

FWD-40LX2F/40LX2X

FWD-32LX2F/32LX2X

Personal computer

Pin No. Signal

1NC

2 RXD

3 TXD

4NC

5 GND

6NC

7NC

8NC

9NC

Pin No. Signal

1NC

2 RXD

3 TXD

4NC

5 GND

6NC

7NC

8NC

9NC

3. Communication Data Format

(a) Control message

No. Item Value

1 Header 0x8C:Control

2 Category 0xXX

3 Function 0xXX

4 Data1 (Length) 0xXX

5 Data2 (Data1) 0xXX

: : 0xXX

X Data (X-3) 0xXX

X+1 Check Sum 0xXX

*Check Sum: Sum total of 1 to X. Lower one-byte data is validated when a

value exceeds 255 (1byte).

*Set the command interval to 500 ms or more when transmitting the

Control command continuously.

*Set the command interval to 500 ms or more when transmitting the same

command (Enquiry) after the Control command.

(b) Enquiry message

No. Item Value

1 Header 0x83:Enquiry

2 Category 0xXX

3 Function 0xXX

4 Data1 0xFF

5 Data2 0xFF

6 Check Sum 0xXX

*Check Sum: Sum total of 1 to 5. Lower one-byte data is validated when a

value exceeds 255 (1byte).

2FWD-40LX2F/40LX2X/32LX2F/32LX2X

KLH-W32/W26

1Control answer

No. Item Value

1 Header 0x70:Answer

2 Answer*0x00:Completed

0x01:Limit Over

0x02:Limit Under

0x03:Command Canceled

3 Check Sum 0xXX

*0x00:Completed Packet is correctly received and process is

also correctly completed.

0x01:Limit Over Packet is correctly received, but the data

value is over the upper limit.

0x02:Limit Under Packet is correctly received, but the data

value under the lower limit.

0x03:Command Canceled Packet is correctly received, but the data

value is not correct or the request cannot be

accepted in the current host state.

*Check Sum: Sum total of 1 to 2. Lower one-byte data is

validated when a value exceeds 255 (1byte).

2Enquiry answer (Complete)

No. Item Value

1 Header 0x70:Answer

2 Answer 0x00:Completed

3 Return Data Size 0xXX

4 Return Data1 0xXX

: : 0xXX

X Return Data (X-3) 0xXX

X+1 Check Sum 0xXX

*0x00:Completed Packet is correctly received and process is also

correctly completed.

*Return Data: Returns the read value.

*Check Sum: Sum total of 1 to X. Lower one-byte data is validated

when a value exceeds 255 (1byte).

3Enquiry answer (Command cancel)

No. Item Value

1 Header 0x70:Answer

2 Answer 0x03:Command Canceled

3 Check Sum 0x73

0x03:Command Canceled Packet is correctly received, but the data

value is not correct of the request cannot be

accepted in the current host state.

4Error answer

No. Item Value

1 Header 0xE0:Answer

2 Answer*0x00:No Function Error

0x01:Check Sum Error

0x02:Data Length Error

3 Check Sum 0xXX

*0x00:No Function Error Packet header, category of function code are not

included in this protocol.

0x01:Check Sum Error Check sum value of received packet is not

correct.

0x02:Data Length Error Packet is correctly received, but the data size is

over the upper limit.

*Check Sum: Sum total of 1 to 2. Lower one-byte data is validated

when a value exceeds 255 (1byte).

FWD-40LX2F/40LX2X/32LX2F/32LX2X

KLH-W32/W26

4. General Function

(a) Mode Control

Syntax Header Category Function Data1 Data2 Check Sum

Control 0x8C 0x00 Code Table (1-a)[a] 0x02 Code Table (1-a)[b] 0xXX

Enquiry 0x83 0xFF 0xFF 0xXX

Answer Header Answer Check Sum

Control 0x70 0x00 0x70 Completed

0x70 0x01 0x71 Limit Over

0x70 0x02 0x72 Limit Under

0x70 0x03 0x73 Command Canceled

Answer Header Answer Return to Data Size Return Data1 Check Sum

Enquiry 0x70 0x00 0x02 Code Table(1-a)[b] 0xXX Completed

Code Table (1-a)

[a]Function [b]Range/Switch Code Command

Control Enquiry Standby Power On

0x00 Power*10x00 OFF Yes Yes Enable Enable

0x01 ON

0x01 Input Select*30x08 INPUT1 RGB (Analog) Yes Yes Disable Enable

0x09 INPUT1 YUV (Analog)

0x0C OPTION1 VIDEO

0x0D OPTION1 S-VIDEO

0x0E OPTION1 RGB

0x0F OPTION1 COMPONENT

0x10 OPTION2 VIDEO*2

0x11 OPTION2 S-VIDEO*2

0x12 OPTION2 RGB*2

0x13 OPTION2 COMPONENT*2

0x44 INPUT2 RGB (Digital)

0x45 INPUT2 DTV (Digital)

0x54 INPUT3 RGB (Digital)

0x55 INPUT3 DTV (Digital)

0x02 Force Status Display 0x00 ON Yes Yes Disable Enable

0x01 OFF

0x03 Audio Mute 0x00 OFF Yes Yes Disable Enable

0x01 ON

0x04 Auto Status Display 0x00 ON Yes Yes Enable Enable

0x01 OFF

0x10 Index Number 0x01-0xFF Yes Yes Disable Enable

0x14 Speaker Out 0x00 ON Yes Yes Disable Enable

0x01 OFF

4FWD-40LX2F/40LX2X/32LX2F/32LX2X

KLH-W32/W26

Code Table (1-a)

[a]Function [b]Range/Switch Code Command

Control Enquiry Standby Power On

0x18 Sync Mode 0x00 H/Comp Yes Yes Disable Enable

0x01 Video

0x1B Clock Display 0x00 OFF Yes Yes Disable Enable

0x01 ON

0x24 Input Detect (Option1) 0x00 FW12 (HD15) No Yes Disable Enable

0x01 FW10 (VIDEO, S-VIDEO) BNC

0x02 FW11 (BNC)

0x03 Reserved

0x04 FW31/32

0x05 FW50 (RGB)

0x06 FW20 (UART +CTRL-S)

0x07 Reserved

0x08 Reserved

0x09 Reserved

0x0A Reserved

0x0B Reserved

0x0C Reserved

0x0D Reserved

0x0E Reserved

0x0F Not Connect

0x25 Input Detect (Option2)*20x00 FW12 (HD15) No Yes Disable Enable

0x01 FW10 (VIDEO, S-VIDEO) BNC

0x02 FW11 (BNC)

0x03 Reserved

0x04 Reserved

0x05 Reserved

0x06 FW20 (UART +CTRL-S)

0x07 Reserved

0x08 Reserved

0x09 Reserved

0x0A Reserved

0x0B Reserved

0x0C Reserved

0x0D Reserved

0x0E Reserved

0x0F Not Connect

0x30 PAP*20x00 OFF Yes Yes Disable Enable

0x01 P&P

0x31 Active Picture*20x00 Left Yes No Disable Enable

0x01 Right

0x02 Swap

FWD-40LX2F/40LX2X/32LX2F/32LX2X

KLH-W32/W26

Code Table (1-a)

[a]Function [b]Range/Switch Code Command

Control Enquiry Standby Power On

0x32 Picture Size (P&P)*20x00 Large Left Yes Yes Disable Enable

0x01 Even

0x02 Large Right

0x35 PAP Input Detect 0x08 INPUT1 RGB (Analog) No Yes Disable Enable

(Left)*20x09 INPUT1 YUV (Analog)

0x0C OPTION1 VIDEO

0x0D OPTION1 S-VIDEO

0x0E OPTION1 RGB

0x0F OPTION1 COMPONENT

0x10 OPTION2 VIDEO

0x11 OPTION2 S-VIDEO

0x12 OPTION2 RGB

0x13 OPTION2 COMPONENT

0x44 INPUT2 RGB (Digital)

0x45 INPUT2 DTV (Digital)

0x54 INPUT3 RGB (Digital)

0x55 INPUT3 DTV (Digital)

0x36 PAP Input Detect 0x08 INPUT1 RGB (Analog) No Yes Disable Enable

(Right)*20x09 INPUT1 YUV (Analog)

0x0C OPTION1 VIDEO

0x0D OPTION1 S-VIDEO

0x0E OPTION1 RGB

0x0F OPTION1 COMPONENT

0x10 OPTION2 VIDEO

0x11 OPTION2 S-VIDEO

0x12 OPTION2 RGB

0x13 OPTION2 COMPONENT

0x44 INPUT2 RGB (Digital)

0x45 INPUT2 DTV (Digital)

0x54 INPUT3 RGB (Digital)

0x55 INPUT3 DTV (Digital)

0x45 Control Mode 0x00 Main +Remocon Yes Yes Disable Enable

0x01 Main

0x02 Remocon

0x03 All Off

0x04 Limited*4

0x46 On Off Timer Mode*20x00 Every Day (Repeat) Yes Yes Enable Enable

0x01 Day Of Week

6FWD-40LX2F/40LX2X/32LX2F/32LX2X

KLH-W32/W26

Code Table (1-a)

[a]Function [b]Range/Switch Code Command

Control Enquiry Standby Power On

0x47 On Timer Enable*2bit0 Sunday 1:Enable, 0:Disable Yes Yes Enable Enable

bit1

Monday 1:Enable, 0:Disable

bit2 Tuesday 1:Enable, 0:Disable

bit3

Wednesday 1:Enable, 0:Disable

bit4 Thursday 1:Enable, 0:Disable

bit5 Friday 1:Enable, 0:Disable

bit6 Saturday 1:Enable, 0:Disable

bit7 Every day 1:Enable, 0:Disable

0x48 Off Timer Enable*2bit0 Sunday 1:Enable, 0:Disable Yes Yes Enable Enable

bit1 Monday 1:Enable, 0:Disable

bit2 Tuesday 1:Enable, 0:Disable

bit3 Wednesday 1:Enable, 0:Disable

bit4 Thursday 1:Enable, 0:Disable

bit5 Friday 1:Enable, 0:Disable

bit6 Saturday 1:Enable, 0:Disable

bit7 Every day 1:Enable, 0:Disable

0x65 IP Setting Mode 0x00 DHCP Yes Yes Enable Enable

0x01 Manual

0x02 Speed

0x66 IP Setting Execute 0x00 No No Yes Enable Enable

0x01 Yes

0x67 IP Setting Result 0x00 Done Yes No Enable Enable

0x01 Error 1 (UART Commu.)

0x02 Error 2 (Duplication)

0x03 Error 3 (IP Add Setting)

0x04 Error 4 (GW Add setting)

0x05 Error 5 (DNS1 Setting)

0x06 Error 6 (DNS2 Setting)

0x07 Error 7 (Sbnt Msk Setting)

0x68 Speed Setting 0x00 100 Mbps/Full Duplex Yes Yes Enable Enable

0x01 100 Mbps/Half Duplex

0x02 10 Mbps/Full Duplex

0x03 10 Mbps/Half Duplex

0x04 Auto

0x70 Input Skip bit0 HD15 Yes Yes Disable Enable

bit1 HDMI1

bit2 HDMI2

bit3 Reserved

bit4 Reserved

bit5 Reserved

bit6 Reserved

bit7 Reserved

Autres manuels pour FWD-32LX2F

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sony Moniteur

Sony

Sony TRINITRON BVM-14F5U Manuel utilisateur

Sony

Sony Trinitron CPD-15SF1 Manuel utilisateur

Sony

Sony CPD-1425 Manuel de référence

Sony

Sony LMD-941W Manuel utilisateur

Sony

Sony PFM-50C1 Instructions d'utilisation

Sony

Sony Trinitron GDM-F400T9 Manuel utilisateur

Sony

Sony LMD-A240 Manuel utilisateur

Sony

Sony Multiscan CPD-G520 Manuel utilisateur

Sony

Sony PFM-42V1N Manuel utilisateur

Sony

Sony Flat Trinitron HMD-A400/L Manuel utilisateur

Sony

Sony LUMA LMD-4420 Manuel utilisateur

Sony

Sony FW-98BZ50L Manuel utilisateur

Sony

Sony Multiscan SDM-M51 Manuel utilisateur

Sony

Sony Multiscan SDM-M51D Manuel utilisateur

Sony

Sony PVM-2541 PVM-1741 PVM-740 LMD-2451W LMD-1751W LMD-4251TD LMD-2451TD LMD-2341W LMD-2041W LMD-1541W LMD-940W LMD-1530W LMD-2110W... Manuel utilisateur

Sony

Sony StylePro SDM-S51R Manuel utilisateur

Sony

Sony SDM-S73 Manuel utilisateur

Sony

Sony pr710te Manuel utilisateur

Sony

Sony SDM-X202 Manuel utilisateur

Sony

Sony PFM-42V1A Manuel utilisateur

Sony

Sony Trinitron CRT Monitor Manuel utilisateur

Sony

Sony PVM-4B1J Manuel utilisateur

Sony

Sony LMD2451MD Manuel utilisateur

Sony

Sony PFM-42V1S Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
