Sony PSP-S360G Manuel utilisateur
Cradle /
護架
/
크레이들
Instruction Manual /
使用說明書
/
사용설명서
PSP-S360 G3-293-974-11(1)
KR
CT
EN
2Precautions
Precautions
Before using this product, carefully read this manual and retain it for future reference.
Refer also to the instructions for use of the PSP®(PlayStation®Portable) system,
especially the Precautions section.
Safety
Observe all precautions and instructions.
Keep the cradle out of the reach of small children.
Do not use a power source other than the supplied (or approved replacement) AC
adaptor and AC power cord.
Do not connect the AC power cord to a voltage transformer or inverter. Connecting
the AC power cord to a voltage transformer for overseas travel or an inverter for use
in an automobile may cause heat to build up in the AC adaptor and may cause burns
or a malfunction.
Do not touch the cradle with wet hands.
If the product does not function properly, disconnect it from the electrical outlet
immediately, and call Customer Service Hotline at the number listed in the official
web site for your region which is accessible from our regional site at http://asia.
playstation.com.
3
EN
Precautions
Use and handling
Do not expose the cradle to high temperatures, high humidity or direct sunlight.
Avoid touching the cradle’s charging terminals with metal objects.
Never disassemble or modify the cradle.
Do not allow liquid or small particles to get into the cradle.
Do not put heavy objects on the cradle.
Do not throw or drop the cradle or subject it to strong physical shock.
Do not expose the cradle to dust, smoke or steam.
Do not place the cradle or accessories on surfaces that are tilted, unstable or subject
to vibration.
Do not leave the cradle on the floor.
Be careful when you dispose of the product or packaging. The product contains metal
and plastic. Follow the instructions of the local authorities when disposing of this
product.
Do not touch any liquid that leaks from the battery with your bare hands.
Do not recharge the battery. If mistreated, the battery may explode.
Keep the battery out of the reach of small children.
Do not allow the battery to come into contact with fire or subject it to extreme
temperatures such as in direct sunlight, in a vehicle exposed to the sun or near a heat
source.
Do not cause the battery to short-circuit.
Do not disassemble, tamper with or incinerate with the battery.
4
Prevent damage to the battery.
Do not carry or store the battery with metal items such as coins or keys. If damaged,
discontinue use.
Do not throw or drop the battery or subject it to strong physical shock.
Do not allow the battery to come into contact with liquids. If it becomes wet,
discontinue use until it is completely dry.
Make sure the + and − polarity of the battery is correct.
Remove the battery after it is exhausted, or if the remote control will not be used for
a long time.
Do not use batteries other than those specified, and always replace with the same type
of battery.
Follow the instructions of the local authorities when disposing of the battery.
Precautions
5
EN
Before using
Before using
The cradle is compatible for use with the PSP-2000 series only. It cannot be used with
the PSP-1000 series.
To use this product, PSP®system software must be version 3.90 or later.
To use this product, both the AC adaptor and AC power cord included with the PSP®
system are required.
To clean this product, use a dry soft cloth. Do not use solvents or other chemicals.
6Part names
Part names
EJECT button
IR port DISPLAY SELECT
button
TV output indicator
System output indicator
DC IN 5V connector
Video out / headset
connector
7
EN
Preparation
Preparation
Setting up the cradle
1Attach the AC adaptor to the cradle.
DC IN 5V connector
2Insert the power plug into an electrical outlet.
8Preparation
Preparing to use the remote control
The remote control is shipped with the battery inserted. An insulation sheet is used to
prevent battery discharge. Remove this insulation sheet before using the remote control
for the first time.
Insulation sheet
9
EN
Attaching the PSP®system
Attaching the PSP®system
1Insert the PSP®system into the cradle.
The PSP®system can be inserted into or removed from the cradle regardless of
whether the power is off or on. To insert the PSP®system into the cradle, line up the
pin positions and press firmly.
Charging the PSP®system
When the PSP®system is attached to the cradle, the POWER indicator on the system
will glow orange and charging will start. When charging is complete, the POWER
indicator will turn off.
10 Attaching the PSP®system
Hints
If the PSP®system POWER indicator does not turn on, check the PSP®system and AC power
cord to verify that they are properly connected to the cradle.
For information about charging time and battery life, refer to the instructions for use of your
PSP®system.
Removing the PSP®system
Push the EJECT button on the cradle to remove the PSP®system.
EJECT button
Caution
The LCD screen is made of glass and may crack if subjected to excessive force. Take care when
removing the PSP®system from the cradle.
