DISK UNIT

BKNW-116

INSTALLATION MANUAL

1st Edition

Serial No. 10001 and Higher (SY)

Serial No. 30001 and Higher (J)

Attention-when the product is installed in Rack:

1. Prevention against overloading of branch circuit

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

make sure that the rack does not overload the supply

circuit.

2. Providing protective earth

When this product is installed in a rack and is

supplied power from an outlet on the rack, please

confirm that the outlet is provided with a suitable

protective earth connection.

3. Internal air ambient temperature of the rack

When this product is installed in a rack, please make

sure that the internal air ambient temperature of the

rack is within the specified limit of this product.

4. Prevention against achieving hazardous

condition due to uneven mechanical loading

When this product is installed in a rack, please make

sure that the rack does not achieve hazardous

condition due to uneven mechanical loading.

!WARNING

This manual is intended for qualified service personnel only.

To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that

contained in the operating instructions unless you are qualified to do so. Refer all servicing to

qualified service personnel.

!WARNUNG

Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.

Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die

Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei

Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen.Andere als die angegeben

Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung

dazu besitzen.

!AVERTISSEMENT

Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien.Afin

de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les

réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.

Pour toute réparation faire appel à une personne compétente uniquement.

1 (E)

BKNW-116

Table of Contents

Manual Structure

Purpose of this manual ......................................................................................... 2(E)

Contents ................................................................................................................ 2(E)

Related manuals.................................................................................................... 2(E)

Caution for Handling the Unit with Built-in HDD................... 3(E)

1. Installation

1-1. Installation Procedure.............................................................................1-1(E)

1-2. Supplied Accessories and Packing Materials.........................................1-1(E)

1-3. Operating Conditions .............................................................................1-2(E)

1-4. Power Supply .........................................................................................1-2(E)

1-4-1. Voltage and Power Requirements .........................................1-2(E)

1-4-2. Power Cord............................................................................1-2(E)

1-5. Installation Space ...................................................................................1-3(E)

1-6. Rack Mounting.......................................................................................1-4(E)

1-7. How to Connect Hybrid Recorder..........................................................1-8(E)

1-7-1. Connection ............................................................................1-8(E)

1-7-2. Setting of Hybrid Recorder ...................................................1-8(E)

2. Service Overview

2-1. Signal Inputs and Outputs ......................................................................2-1(E)

2-2. Filter Cleaning........................................................................................2-2(E)

2 (E) BKNW-116

Purpose of this manual This manual is the installation manual of hard disk unit BKNW-116. This manual is

intended for use by trained system and service engineer, and provides the informa-

tion that is required to install.

Contents This manual is organized by following sections.

Section 1 Installation

Explains operating condision, installation space, how to connect to hybrid recorder,

and so on.

Section 2 Service Overview

Explains signal input/output and filter cleaning.

Related manuals Besides this “installation manual”, the following manuals are available for this hard

disk unit BKNW-116.

• Operation manual (Supplied with BKNW-116.)

This manual is necessary for application and operation of the BKNW-116.

• Maintenance manual (available on request)

This manual describes the maintenance information, and information that premises

the parts level service. If this manual is required, contact your local Sony Sales

Office/Service Center.

Manual Structure

3 (E)

BKNW-116

This unit has built-in hard disk drives (HDDs). Pay careful attention to the following and operate with

care when installing and servicing this unit.

Never give any mechanical shock and vibration.

This may cause an HDD trouble or destroy the data in HDD.

.Pack this unit using specified packing materials when carrying the unit. Use a cart with less-vibration

when carrying this unit by a cart. If an excessive mechanical shock and vibration are applied, the HDD

may be damaged.

.Never move this unit under the power-on state. Take out or insert this unit from/to the rack under the

power-off state. Also never install or remove the cabinet under the power-on state.

.When this unit is in a vehicle, never turn on the power during running.

.When putting the unit on the floor, put this unit gently with the four specified feet which is attached to

the bottom of the unit on the floor. If there are no feet on the bottom, attach them before putting this

unit, or put this unit gently so that no sound is generated.

Never operate the unit for 30 seconds after the power is turned off.

The disks in HDD rotate by inertia for a while after the power is turned off. In this case, the heads are in

the unstable state. During this period, the HDD is more sensitive to a mechanical shock and vibration

than during power-on state. Never give even a slight shock at least 30 seconds after the power is turned

off. Operations can be initiated (because the disks stop) after 30 seconds or more.

In the event of trouble in HDD

If there is something wrong with the HDD of this unit (a failure occurs in the HDD), handle this unit in

the same manner as described above. This protects the HDD from increace of the damage till confirming

the contents of the failure or analyzing the failure.

Caution for Handling the Unit with Built-in HDD

1-1 (E)

BKNW-116

1-3. Operating Conditions

1-4. Power Supply

1-5. Installation Space

1-6. Rack Mounting

1-7. How to Connect Hybrid

Recorder

Start

Determination of

installation place

Unpacking

Rack mounting

Connection

End

When the unit is transported, it is required to

pack the unit into the specified new packing

materials. Do not reuse the packing materials

1-2. Supplied Accessories and Packing

Materials

Name Part No. Q’ty

Disk array cable 1-769-670-31 1

Operation manual _1

Individual carton 3-200-082-01 1

Cushion 3-200-083-01 2

Installation manual _1

Protection sheet (standard) 3-704-355-01 1

Power cord is not supplied in this unit. For the power cord,

refer to Section 1-4-2.

1-1. Installation Procedure

This unit has built-in hard disk drives (HDDs). Pay careful

attention when installing the unit.

Be careful not to give a shock and mechanical vibration to

it. This may cause a trouble.

Installation procedure of this unit is shown in the following

flowchart.

Refer to each section about detail of each flow.

Section 1

Installation

1-2 (E) BKNW-116

AC power supply is required a capacity which is commen-

surate with rush current.

If the capacity of the AC power supply is not enough, the

breaker of AC power of a supply side may operate or this

unit may not operate normally.

1-4-2. Power Cord

Use the specified power cord only when connecting.

Never use a injured power cord.

Power cord for the customer in the U.S.A. and Canada.

1Power cord (approx. 2.5 m) !1-557-377-11

2Plug holder (brown) 3-613-640-01

Contact your local Sony Sales Office/Service Center.

Power cord for the customer in Europe.

1Power cord (approx. 2.5 m) !1-782-929-11

2Plug holder (brown) 3-613-640-01

Contact your local Sony Sales Office/Service Center.

If the unit is used in the area except above, contact your

local Sony Sales Office/Service Center.

12 AC inlet

1-3. Operating Conditions

1-4. Power Supply

AC inlet

1-3. Operating Conditions

Operating temperature: 5dC to 40dC

(When the inner of the unit becomes less than 5dC, the

hard disk portion does not start up because of entering

into warm up mode. The inner of the unit becomes 5dC

or more, the hard disk portions start up automatically.)

Operating humidity: 25% to 80%

(Condensation not allowed)

Storage temperature: _20 dC to 60 dC

Locations to avoid:

.Areas where the unit will be exposed to direct sunlight

or any other strong lights.

.Areas near heat sources.

.Dusty areas or areas subject to vibration.

.Areas with strong magnetic field.

.Areas with much electrical noise.

.Areas with much static electricity.

.Areas that is impossible to find a specified room for

installation.

(Refer to “1-5. Installation Space”)

.Areas windtight

Horizontal condition: Do not slant the front and rear of the

unit more than 30 d.

Fix the unit securely to avoid slipping if the unit is not

operated at horizontal place.

1-4. Power Supply

1-4-1. Voltage and Power Requirements

Be sure to operate the unit within the range of following

power voltage.

Power voltage: AC 100 to 240 V ±10%

Power frequency: 50 Hz or 60 Hz

Power consumption: 285 W (AC100 V IN: 3 A)

(AC240 V IN: 1.5A)

Rush current: Power voltage 100 V IN: 7 A

Power voltage 240 V IN: 7 A

This unit’s power line has a switching regulator with the

power factor 98 %.

1-3 (E)

BKNW-116

1-5. Installation Space

474

(498.5)

24.5

427

174

(193)

(1234)

Mass: 23 kg

DISK UNIT BKNW-116

POWER BUSY WARM-UP ALARM

Unit: mm

When pulling out rack mount

Air flows

Rear side

Front side

1-5. Installation Space

When installing, the installation space must be secured in

consideration of the ventilation and service operation.

The air flows of this unit are shown below. Do not block

the exhaust part and ventilation of front and side panels so

that the air flows enough.

Moreover, when this unit is installed without rack mount-

ing, it is recommended that the clearance at the upper, left

and right sides is at least 4 cm.

If the ventilation is not enough, the unit may be damaged

because an increase of the internal temperature of the unit

can not reduce.

1-4 (E) BKNW-116

1-6. Rack Mounting

PS4 x14

Foot

PS4 x14

Foot

PS4 x14

Foot

PS4 x14

Foot

1-6. Rack Mounting

This section explains how to mount this unit in a 19-inch

standard rack.

Install this unit in a rack accurately as following procedure

with the specified rack mount rail.

If not, there is a fear of unexpected accident such as a drop

of the unit or turnover of the rack.

.Use the specified rack mount rail.

If not, it may cause of injury by drop of the unit because

strength of rail is not enough.

.To prevent turning over the rack, fix the rack on the

horizontal and firm floor securely with bolts, etc.

.Pay careful attention not to catch the power cord in the

rack mount rails.

.When other equipment with built-in hard disk drive is

already installed in the rack, turn off the power of the

equipment before mounting this unit in the rack.

.Never remove the upper lid, bottom plate, and so on

during rack mounting.

.Adjust so that the temperature inside of the rack is in the

range of the unit’s operating temperature.

.Connect the hybrid recorder after mounting this unit in

the rack.

Specified Rack Mount Kit

RMM-130 (Option)

Parts packed in RMM-130

.Slide rails 2

.Rack angles (handles) 2

.Rail brackets 4

.Plate nuts (large) 4

.Plate nuts (small) 4

.Screws (PSW4 x 16) 4

.Screws (B4 x 8) 8

.Hexagon socket head cap screws 8

.Flat washers 8

.Screws (RK5 x 14) 2

.Ornamental washers 2

.L-shaped hexagon wrench 1

Rack Mounting Procedures

1. Removal of feet

When placing this unit, take care not to give a shock to this

unit. Pay particular attention to move this unit without feet.

(1) Place the unit on its side panel down.

(2) Unscrew the four screws and remove the feet from the

bottom plate of the unit.

(3) Replace the unit to the horizontal position.

Keep these screws and feet which are removed in this

procedure carefully.

When the unit is used without rack mounting, it is required

to attach these feet.

If the unit is placed without four feet, the hard disk drive

may break down by mechanical vibration, shock, etc.

Tightening torque: 98 x10-2 N.m{10 kgf.cm}

Autres manuels pour BKNW-116

Table des matières

Autres manuels Sony Lecteur CD/CDR

Sony

Sony CDU 5211 Series Manuel utilisateur

Sony

Sony Spressa CRX100E Manuel utilisateur

Sony

Sony CDU33A Series Manuel utilisateur

Sony

Sony CDU924S Manuel utilisateur

Sony

Sony CRX - 160E Manuel utilisateur

Sony

Sony ATAPI Drive Manuel utilisateur

Sony

Sony CRX-160S Manuel utilisateur

Sony

Sony SDX-D700C Manuel

Sony

Sony CRX-1611 Manuel utilisateur

Sony

Sony CDU948S Manuel utilisateur

Sony

Sony CRX320EE Manuel utilisateur

Sony

Sony CRX230AE Manuel utilisateur

Sony

Sony CRX220A1 Manuel utilisateur

Sony

Sony CDU31A Series Manuel utilisateur

Sony

Sony VPCB1 Series Mode d’emploi

Sony

Sony CRXP-90MU Manuel utilisateur

Sony

Sony VGC-RB10M - Vaio Desktop Computer Mode d’emploi

Sony

Sony CRX10U Manuel utilisateur

Sony

Sony CRX175M Manuel utilisateur

Sony

Sony VAIO VPCEB42FX Mode d’emploi

Sony

Sony CRX230A Manuel utilisateur

Sony

Sony PCG-GRT Series Mode d’emploi

Sony

Sony CDU948S Manuel utilisateur

Sony

Sony ODS-D55U Manuel utilisateur

Manuels Lecteur CD/CDR populaires d'autres marques

Philips

Philips CDD3610 Manuel utilisateur

QPS

QPS Que!Fire Manuel utilisateur

LG GCC-4241N Manuel utilisateur

Plextor

Plextor 12X-3 Mode d’emploi

Samsung

Samsung SN-324B Manuel utilisateur

Teac

Teac CD-211E Manuel utilisateur

SmartDisk

SmartDisk Firewire CD-R/W Manuel utilisateur

Axis

Axis CD-ROM SERVER Manuel utilisateur

LG CRD-8322B Manuel utilisateur

Memorex

Memorex 32023234 - 52x32x52x External USB2.0 CD... Instructions d'installation

Yamaha

Yamaha CD Recordable/Rewritable Drive CRW3200 Manuel utilisateur

Panasonic

Panasonic KX-LD742 Manuel utilisateur

Pioneer

Pioneer BDR-S13U-X Manuel utilisateur

Panasonic

Panasonic LK-MC606BP Manuel utilisateur

Panasonic

Panasonic CF-VCW Series Manuel utilisateur

LG CRD-8320B Manuel utilisateur

Conner

Conner CFP2107 Series Manuel utilisateur

Plextor

Plextor 12-20C Mode d’emploi
