Sony TA-VE800G Manuel utilisateur

Integrated AV

Amplifier

Operating Instructions

Mode d’emploi

Manual de Instrucciones

Manual de Instruçõnes

3-856-144-11(1)

TA-VE800G

2GB

WARNING

To prevent fire or shock

hazard, do not expose

the unit to rain or

moisture.

To avoid electrical shock, do not open

the cabinet. Refer servicing to qualified

personnel only.

Do not install the appliance in a

confined space, such as a bookcase or

build-in cabinet.

Precautions

On safety

• Should any solid object or liquid fall

into the cabinet, unplug the amplifier

and have it checked by qualified

personnel before operating it any

further.

On power sources

• Before operating the amplifier, check

that the operating voltage is identical

with your local power supply. The

operating voltage is indicated on the

nameplate at the rear of the amplifier.

• This unit is not disconnected from the

AC power source (mains) as long as it

is connected to the wall outlet, even if

the unit itself has been turned off.

• If you are not going to use the

amplifier for a long time, be sure to

disconnect the amplifier from the

wall outlet. To disconnect the mains

lead, grasp the plug itself; never pull

the cord.

• AC power cord must be changed only

at the qualified service shop.

On placement

• Place the amplifier in a location with

adequate ventilation to prevent heat

buildup and prolong the life of the

amplifier.

• Do not place the amplifier near heat

sources, or in a place subject to direct

sunlight, excessive dust or

mechanical shock.

• Do not place anything on top of the

cabinet that might block the

ventilation holes and cause

malfunctions.

On operation

• Before connecting other components,

be sure to turn off and unplug the

amplifier.

On cleaning

• Clean the cabinet, panel and controls

with a soft cloth slightly moistened

with a mild detergent solution. Do

not use any type of abrasive pad,

scouring powder or solvent such as

alcohol or benzine.

If you have any question or problem

concerning your amplifier, please

consult your nearest Sony dealer.

3GB

TABLE OF CONTENTS

Introduction

Features 4

Understanding How the Amplifier Works 6

Getting Started

Unpacking 7

Hookup Overview 7

IR Repeater Hookups 8

Audio Component Hookups 8

Speaker System Hookups 9

TV/VCR Hookups 10

AC Hookups 11

Before You Use Your Amplifier 11

Preparing and Using the Remote

Inserting Batteries into the Remote 12

How to Use the Remote 12

Registering a TV 14

Registering Audio/Video Equipment 16

Programming Infrared (IR) codes from other remotes

(USER IR setting) 20

Basic Operations

Selecting a Component 22

Recording 24

Using the Sleep Timer 25

Using Sound Fields

Introduction 26

Using Pre-programmed Sound Fields 26

Getting the Most Out of Dolby Pro Logic Surround Sound 28

Customizing Sound Fields 29

Advanced Operations

Using the Index functions 31

Operating a CD Changer 33

Operating Several Components in Sequence Automatically

(macro play) 35

Settings and Adjustments

Remote Operation of Audio Sources Without the TV

(illuminated control flasher) 36

Playing Sources Automatically (auto play) 37

Starting a Source Automatically at Power On (auto start) 37

Adjusting the Sensitivity of the Remote 38

Selecting the Display Parameters 38

Adjusting the Position of the On-Screen Display 39

Additional Information

Front Panel Descriptions 40

Rear Panel Descriptions 41

Troubleshooting 42

Specifications 44

Glossary 45

Index 46

About This Manual

The instructions in this manual are for

model TA-VE800G.

Conventions

• The instructions in this manual

describe the controls in the on-screen

display. You can also use the controls

on the amplifier if they have the same

or similar names as those in the on-

screen display.

• The following icon is used in this

manual:

Indicates hints and tips for

making the task easier.

This amplifier incorporates the Dolby

Pro Logic Surround system.

Manufactured under license from Dolby

Laboratories Licensing Corporation.

“Dolby ,” the double-D symbol aand

“Pro Logic” are trademarks of Dolby

Laboratories Licensing Corporation.

4GB

Features

On-screen control of Audio/Video components

The TA-VE800G Integrated AV Amplifier is an audio/video control centre with a unique interface. By connecting the

amplifier to your TV, an on-screen display appears and lets you operate the various connected audio/video

components. Use the remote to move the pointer (hand-shaped icon) on the on-screen display and select functions.

This unit’s on-screen display lets you control audio/video components as well as any other device that can be

controlled by an infrared remote control, such as lighting fixtures.

For details on how the amplifier controls other equipment, see page 6.

Introduction

PUSH

ENTER

5GB

Introduction

A wide variety of sound fields including Dolby Pro Logic surround

Since the amplifier comes preset with 12 different sound fields (like HALL, THEATER, ARENA, etc.), you can enjoy exciting

sound effects simply by choosing one from the SOUND FIELD SELECT screen.

The amplifier also incorporates a Dolby Pro Logic decoder, so you can enjoy programmes recorded in Dolby Surround with

a surround effect similar to a movie theatre.

CD Changer Control

Connecting a Sony CD changer equipped with a Control A1 terminal allows you to access and display the disc information

stored in the CD changer in alphabetical order, numerical order, or by group name. You can also select the disc to be played

discs from the on-screen display using the amplifier’s remote.

6GB

Understanding How the Amplifier Works

The remote control supplied with the TA-VE800G uses infrared (IR) rays to command the amplifier and control the

on-screen display.

Since this amplifier uses menu operations, you must connect a TV.

On-screen operation

1The remote commander emits an infrared (IR) signal when you press direction control button (1above).

2This controls the movement of the pointer (hand icon) in the on-screen display (2above).

3When you move the pointer to an on-screen icon, and press the centre of the direction control button, the

infrared (IR) emitter transmits the corresponding IR control code to the respective programme source (3

above).

If the screen does not appear or the pointer does not move when you press the direction control button

The IR code from the remote is not fully reaching the infrared receptor on the amplifier (1above). Make sure there are no

obstacles between the remote and the amplifier.

If the programme source fails to respond or is slow to respond

The IR control code from the IR repeater is not fully reaching the infrared receptor on the programme source. Connect the extra

IR repeater (supplied) and position it facing the programme source (see “IR Repeater Hookups” on page 8).

If some of the programmed on-screen controls are unresponsive or slow, rerecord the IR codes for those buttons ( see

“Registering non-Sony Audio/Video equipment” on page 16).

The TV is used as a monitor

To watch TV programmes, use the TV tuner built into your VCR. The VCR controls in the on-screen display let you switch the

programme positions using the amplifier’s remote.

You can use the TV’s tuner when the amplifier is turned off, but operations must be performed using the remote supplied

with the TV.

TV (monitor)

Video signal

Video signal (Input from source

components combined with on-screen

display)

IR emitter

and receptor

LD player, etc.

Video signal

VCR, etc.

()0pP=+

FUNCTION

–

VOL

ALL

OFF

USERSUB

PUSH

ENTER

TA-VE800G

IR control codes

Introduction

7GB

Getting Started

Unpacking

Check that you received the following items with the

amplifier:

• Remote commander RM-VR1 (remote) (1)

• Size AA (R6) batteries (2)

• IR repeater (1)

• Video cable (1)

• Getting Started and Basic Operation Guide (1)

Hookup Overview

The amplifier allows you to connect and control the

following audio/video components. Follow the

hookup procedures for the components that you want

to connect to the amplifier on the pages specified. To

learn the locations and names of each jack, see “Rear

Panel Descriptions” on page 41.

Getting Started

Front

speaker

(L)

Front

speaker

(R)

Speaker

System

Hookups (9)

Rear

speaker

(L)

Rear

speaker

(R)

IR Repeater

Hookups (8)

Satellite decoder

VCR

LD player

Monitor

TV/VCR Hookups (10)

CD player

Tape deck

DAT/MD deck

Turntable

Audio Component

Hookups (8)

Centre

speaker Active

woofer

Video camera/

Video game

TV/VCR

Hookups (10)

Before you get started

• Turn off the power to all components before making

any connections.

• Do not connect the mains leads until all of the

connections are completed.

• Be sure to make connections firmly to avoid hum

and noise.

• When connecting an audio/video cable, be sure to

match the colour-coded pins to the appropriate jacks

on the components: Yellow (video) to Yellow; White

(left, audio) to White; and Red (right, audio) to Red.

8GB

Getting Started

IR Repeater Hookups

Overview

This section describes how to connect the supplied

extra infrared (IR) repeater to the amplifier. The

repeater emits infrared signals corresponding to those

emitted by the remote controls supplied with the

respective components. Connected this repeater to

obtain additional coverage if you experience difficulty

controlling a certain component using the amplifier’s

on screen display (OSD) control functions, or your

installation prevents the repeater on the front panel

from reaching all of the equipment you need to control.

For the specific location of the terminal, see the

illustration below.

Hookups

Notes

• Use the supplied adhesive tape to secure the IR repeater

so that its front faces the equipment to be controlled.

• If you experience trouble controlling the connected

equipment, the infrared (IR) signals transmitted from the

repeater may not be reaching the infrared receptor on the

respective equipment. In such a case, reposition the IR

repeater closer to that piece of equipment.

IR OUT

Amplifier IR repeater

IR OUT

Audio Component Hookups

Overview

This section describes how to connect your audio

components to the amplifier.

For specific locations of the jacks, see the illustration

below.

What cords will I need?

Audio cords (not supplied) (1 for each CD player and

turntable; 2 for each tape deck, DAT deck, or MD deck)

Hookups

The arrow çindicates signal flow.

CD player

Tape deck

DAT/MD

Red (R)Red (R)

White (L)White (L)

CTRL A1

Tape deckAmplifier

OUTPUT

LINE

TAPE

INREC OUT

OUTPUT

LINELINE

INPUT

DAT/MD

INREC OUT

OUTPUT

LINELINE

INPUT

DAT/MDAmplifier

Amplifier CD player

PHONO

TAPE

TUNER CD DAT/MD

9GB

Getting Started

Tuner

Turntable

• If your turntable has an earth lead

To prevent hum, connect the earth lead to the ySIGNAL

GND terminal on the amplifier.

CONTROL A1 Hookups

• If you have a CONTROL A1 compatible Sony CD player

or tape deck

Use a CONTROL A1 cord (not supplied) to connect the

CTRL A1 jack on the CD player or tape deck to the S-LINK

CTRL A1 jack on the amplifier. Refer the separate manual

“CONTROL-A1 Control System” and the Operating

Instructions supplied with your CD player or tape deck

for details.

• If you have a Sony CD changer with a COMMAND

MODE selector

If the CD changer’s COMMAND MODE selector can be

switched between CD 1, CD 2, and CD 3, be sure to set the

command mode to “CD 1” and connect the changer to the

CD terminals on the amplifier.

However, if you have a Sony CD changer with VIDEO

OUT terminals, set the command mode to “CD 2” or “CD

3” and connect the changer to a set of the amplifier’s video

component terminals (VIDEO 1, VIDEO 2, or LD).

TUNER

OUTPUT

LINE

Amplifier Tuner

Amplifier Turntable

PHONO

OUTPUT

LINE

Speaker System Hookups

Overview

This section describes how to connect your speakers to

the amplifier. Although front (left and right) speakers

are required, centre and rear speakers are optional.

Adding centre and rear speakers will enhance the

surround effects. Connecting an active woofer will

increase bass response.

For specific locations of the terminals, see the

illustration below.

For optimum surround sound effect, place your

speakers as shown below.

What cords will I need?

Speaker cord (not supplied) (1 for each speaker)

Twist the stripped ends of the cord about 15 mm (2/3 inch).

Be sure to match the speaker cord to the appropriate

terminal on the components: + to + and – to –. If the cords

are reversed, the sound will be distorted and will lack bass.

(+)

(–)

45°

Rear speaker

60 - 90 cm

Front speaker

FRONT SPEAKERS

WOOFER REAR

SPEAKERS CENTER

SPEAKER

(continued)

10GB

Getting Started

MONITOR

AV 1

Hookups

Front speakers

Rear and centre speakers

Active woofer

If your TV monitor uses separate speakers

You can connect one of them to the SURROUND OUT

CENTER terminal for use with Dolby Pro Logic

Surround Sound (see page 28).

TV/VCR Hookups

Overview

This section describes how to connect video

components to the amplifier.

For specific locations of the jacks, see the illustration

below.

What cables will I need?

• Audio/video cable (not supplied) (1 for each TV or LD

player; 2 for each VCR)

• Scart cable (not supplied) (1 for the (TV) monitor)

Hookups

The arrow çindicates signal flow.

TV (Monitor)

Satellite decoder

Front speaker

(R)

}]

FRONT SPEAKERS

Front speaker

(L)

}]

Amplifier

}]}]

Rear

speaker

(R)

Rear

speaker

(L)

REAR SPEAKERS

CENTER SPEAKER

Centre

speaker

Amplifier

}]

Active woofer

INPUTMIX

AUDIO

OUT

Amplifier

White (L)

Yellow

Red (R)

White (L)

Yellow

Red (R)

OUTPUT

VIDEO

AUDIO

VIDEO

AUDIO

SATL

Amplifier Satellite

decoder

MONITORLD VIDEO 2

VIDEO 1SATL

Amplifier TV (Monitor)

Autres manuels pour TA-VE800G

Table des matières

Langues :

Autres manuels Sony Amplificateur

Sony

Sony XM-7557 Primary Manuel utilisateur

Sony

Sony TA-NR1 Manuel utilisateur

Sony

Sony XM-N1004 Manuel utilisateur

Sony

Sony TA-DA9000ES Guide de démarrage rapide

Sony

Sony XM-2351 Manuel utilisateur

Sony

Sony PHA-2 Manuel utilisateur

Sony

Sony XM-N1004 Manuel utilisateur

Sony

Sony PHA-3 Mode d’emploi

Sony

Sony TA-E1 Operating Instructions (primary... Manuel utilisateur

Sony

Sony TA-E9000ES - Stereo Preamplifier Guide de l'utilisateur

Sony

Sony XM-1002HX Manuel utilisateur

Sony

Sony XM-430 Primary Manuel utilisateur

Sony

Sony TA-F448EB Manuel utilisateur

Sony

Sony TAE-8450 Manuel utilisateur

Sony

Sony XM-1ES Manuel utilisateur

Sony

Sony XM-N502 Manuel utilisateur

Sony

Sony XM-4060GTX Operating & Connection Manuel utilisateur

Sony

Sony XM-460GTX Marketing Specifications Manuel utilisateur

Sony

Sony XM-SD46X - Stereo Power Amplifier Manuel utilisateur

Sony

Sony TA-AV411 Manuel utilisateur

Sony

Sony XM-460GTX Marketing Specifications Manuel utilisateur

Sony

Sony XM-3046 Manuel utilisateur

Sony

Sony TA-FE320R Manuel utilisateur

Sony

Sony XM-222MK2 Manuel utilisateur

Manuels Amplificateur populaires d'autres marques

ASTRO

ASTRO HVO V40 P Manuel utilisateur

Marantz

Marantz SUPERSCOPE BLA-545 Instructions de montage

NAD

NAD CI980 Manuel utilisateur

Technics

Technics SE-CH770 Manuel utilisateur

Harman Kardon

Harman Kardon HK6300 Manuel utilisateur

NAD

NAD T975 Manuel utilisateur

McIntosh

McIntosh MA6850 Manuel utilisateur

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuel utilisateur

Viatron

Viatron Autrix Manuel utilisateur

GME

GME GA9800 Manuel utilisateur

Atlas

Atlas CP700 Manuel utilisateur

Roland

Roland KC-1000 Manuel utilisateur

Pyle

Pyle PFMRA350BW Manuel utilisateur

Advantage

Advantage S-250 Manuel utilisateur

IRT Electronics

IRT Electronics DVA-3007 Manuel utilisateur

Dimavery

Dimavery BA-100 Series Manuel utilisateur

Schertler

Schertler ROY X Manuel utilisateur

Phonic

Phonic XP 3000 Manuel utilisateur
