Sonance Symphony Extreme Manuel utilisateur

THE LEADER IN ARCHITECTURAL AUDIO™

“Photo Courtesy of Modern Home Systems, www.modernhomesystems.com”

Symphony Extreme

INTRODUCING THE FIRST TRUE WEATHERPROOF IN-WALL & IN-CEILING SPEAKERS -

Symphony Extreme speakers from Sonance are designed to fit into every aspect of your

leisure lifestyle while providing you superior audio performance. Symphony Extreme speakers

are made to withstand high humidity and are built to survive temperature extremes - from -30

degrees up to 220 degrees - while maintaining superior sound quality. Symphony Extreme

speakers are also shock-resistant and can withstand the pelting of the high seas and salt air,

making them excellent choices for marine applications.

Use them in the sauna, in the ceiling of your shower, install them on your yacht or anywhere

outdoors. Choose from three different styles depending upon your application – the XTR and

XSSTR are round speakers designed for in-ceiling installations, and the XT made for in-wall

installations.

All Symphony Extreme speakers owe their weather resistance to a very innovative design. All

exposed plastic parts are made of durable, high temperature plastic, which has a substantially

higher melting point. Finished with grilles made of stainless steel to weather the elements of

time, a baffle O-ring and a frame neoprene gasket that makes them watertight and enhances

the moisture barrier.

Perfect for indoor and outdoor areas where stereo performance is desired from one speaker,

the new Symphony Extreme XSSTR in-ceiling speaker combines the proprietary Single Stereo

Technology with an innovative weatherproof design that enables superior stereo sound

quality from one speaker in a variety of environments.

From the Death Valley dry heat of a sauna to the Amazon rainforest humidity of a shower

stall, Symphony Extreme knows no placement boundaries and they deliver the same Sonance

Symphony sound quality that you’ve come to love.

“Photo Courtesy of DSI Entertainment”

• Waterproof design deters high humidity environments

• Withstands extreme temperatures –30 to 220 degrees

• Perfect for marine applications – you can even hose it down!

• Shallow depth design for difficult installs

• Paintable grilles to match you interior or exterior design

The Symphony Extremes

sleek design is perfect for

shallow depth installations.

“Photo Courtesy of DSI Entertainment”

SYMPHONY EXTREME

SPECIFICA T I O N S

SONANCE • 212 AVENIDA FABRICANTE •SAN CLEMENTE,CA 92672-7531 • TEL: 800-582-7777 • 949-492-7777 • FAX: 800-538-5151 • 949-361-5151

ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.

TAKE THE T O U R AT WWW.SONANCE.COM

Extreme XT In-Wall Speaker Extreme XTR In-Ceiling Speaker

Tweeter: 1” (25mm) Polyurethane dome

Woofer: 6 1/2” (165mm) One-piece aluminum cone with

rubber surround

Frequency Response: 55Hz - 20kHz ± 3dB

Impedance:8 ohms nominal/6 ohms minimum

Power Handling: 5 to 60 watts

SPL: 89dB 1W/1m

Grilles: Stainless Steel

Speaker Dimensions (W x H x D): 8 1/8” x 12 3/16” x

2 1/2” (206mm x 310mm x 64mm)

Cutout Dimensions (W x H): 6 3/4” x 10 7/8

(172mm x 276mm)

Special Features:

•Frame Neoprene Gasket

•High Tempurature Plastic for all exposed plastic parts

•All crossover components secured with tie-wraps

Tweeter: 1” (25mm) Polyurethane dome

Woofer: 6 1/2” (165mm) One-piece aluminum cone with

rubber surround

Frequency Response: 55Hz - 20kHz ± 3dB

Impedance:8 ohms nominal/6 ohms minimum

Power Handling: 5 to 60 watts

SPL: 89dB 1W/1m

Grilles: Stainless Steel

Speaker Dimensions (D x D): 9 3/4” x 3 5/8”

(248mm x 310mm)

Cutout Dimensions (D): 8 5/32”(207mm)

Special Features:

•Frame Neoprene Gasket

•High Tempurature Plastic for all exposed plastic parts

•All crossover components secured with tie-wraps

Extreme XSSTR In-Ceiling Speaker

In-Ceiling single stereo technology: Get Great Stereo

sound from one speaker!

Tweeter: Two - 1” (25mm) Polyurethane dome

Woofer: 6 1/2” (165mm) One-piece aluminum cone, dual

voice coil and a rubber surround

Frequency Response: 55Hz - 20kHz ± 3dB

Impedance:8 ohms nominal/6 ohms minimum

Power Handling: 5 to 60 watts

SPL: 89dB 1W/1m

Grilles: Stainless Steel

Speaker Dimensions (D x D): 9 3/4” x 5 3/16”

(248mm x 132mm)

Cutout Dimensions (D): 8 5/32” (207mm)

Special Features:

•Frame Neoprene Gasket

•High Tempurature Plastic for all exposed plastic parts

•All crossover components secured with tie-wraps

Symphony Extreme Speakers:
