INSTRUCTION MANUAL

ONANCE

HIN

INE

™

N-

EILING

PEAKERS

INTRODUCTION

Thank you for purchasing Sonance ThinLine™ TL and SSTR-series speakers. When properly installed

your new speakers will give you years of entertainment pleasure. This manual will teach you all

about your new speakers’ many innovative features and will show you how to get the very best

performance from them. Please read it thoroughly.

The directions in this manual apply to each model in the series. This manual covers the

following speaker models: TL623R, TL622R; TL621R; TL623SSTR.

DESIGN AND FEATURES

• Thin (77mm) depth allows installation in areas too shallow for conventional in-ceiling speakers.

• Pivoting tweeters direct the sound at listeners for clear sound and improved stereo imaging even when speaker placement options

are limited.

•TL623SSTR reproduces both left and right channels from a single speaker — ideal for small spaces like hallways,closets and bathrooms.

• A 3-position tweeter adjustment switch lets you balance the speaker’s high-frequency energy to better compliment your room’s

setup and acoustics (TL623R/TL623SSTR).

• The RotoLock®mounting system makes installation quick and easy.

•The detachable mounting flange expands installation options, allowing the speaker assembly to be easily mounted in custom cabinetry.

BOX CONTENTS

Your Sonance ThinLine speaker box should contain the following items:

ThinLine TL623R/TL622R/TL621R: ThinLine TL623SSTR:

Figure 1: Sonance ThinLine™

TL-Series Speaker (left);

SSTR-Series Speaker (right)

SONANCE THINLINE™ TL and SSTR

SAFETY WARNING:

These speakers have FastMount®tabs that prevent the speaker from falling out of the

mounting hole during the installation process.

The edges of the FastMount tabs are very sharp.

Use caution when handling the speaker.

See

Installation

(page 8) for complete information about the FastMount tabs.

(2) ThinLine TL623R, TL622Ror TL621Rspeakers

(2) Paintable grilles

(2) Plastic paint plugs (installed on fronts of speakers)

(1) Mounting cutout template (in packaging)

(1) ThinLine TL623SSTR speaker

(1) Paintable grille

(1) Plastic paint plug (installed on fronts of speakers)

(1) Mounting cutout template (in packaging)

SONANCE THINLINE™ TL and SSTR

OPTIONAL ACCESSORIES

Symphony FlexBracket (part #92337): Plastic template to reserve a mounting hole for ThinLine speakers in new construction. Designed to be used

with the RotoLock®mounting system.

SymphonyTR Coverplate (part #92335): Reusable cover protects the hole made by the FlexBracket during construction until the speaker is installed.

Sonafill®In-Ceiling System (part #91928): Retrofittable acoustical treatment consisting of two pillows and four tiles that virtually eliminates noises

produced by resonating drywall. Dramatically improves midbass sound quality and reduces sound transmission into adjacent rooms.

SPEAKER PLACEMENT

TL623SSTR

ThinLine Single Stereo Technology®SSTR speakers are ideal for use in hallways, bathrooms, closets, or in any location where listeners will be moving around

and a pair of stereo speakers would be impractical. The location of the speaker should be determined by considering the primary listening location as well

as aesthetic values. Because a single ThinLine SSTR speaker reproduces both stereo channels from a single location, it will deliver outstanding performance

from an extremely wide variety of mounting locations. For optimum results contact your Authorized Sonance Dealer for advice.

TL623R, TL622R, TL621R

When selecting mounting locations for your speakers you should consider such things as your primary listening location, the primary use for the speakers

(distributed audio, 2-channel stereo or home theater) and aesthetic values. Your local authorized Sonance dealer is an expert in audio/video system

planning and installation. We strongly recommend that you work with your dealer to ensure that your system is properly planned, assembled and installed.

Distributed Audio Speaker Placement (Mono signal)

All Sonance ThinLine speaker models have very smooth and predictable off-axis response, so they provide excellent coverage in distributed audio systems from

a wide variety of installation locations. The chart in

Figure 1

shows how far apart the speakers can be placed at different ceiling heights while still

providing good coverage (as shown in

Figure 2

). The distances are based on ear heights of 62” for standing listeners and 40” for seated listeners.

Speaker Spacing (in feet) for a Distributed Audio System

Standing Listener Seated Listener

10-foot ceiling

12-foot ceiling

14-foot ceiling

8-foot ceiling 9.5'

13.5'

17.5'

21.5'

5.7'

9.7'

13.7'

17.7'

Coverage

Area Coverage

Area

Speaker

Spacing

Figure 1: Distributed Audio Speaker Spacing Figure 2: Distributed Audio Coverage Area

SONANCE THINLINE™ TL and SSTR

Home Theater Speaker Placement

Left, Center & Right Channels

• Place the left, center and right speakers from 1 foot to 2 feet in

front of the video screen, anywhere from 6 feet to 10 feet apart,

with the center channel speaker as close to midway between the

left and right speakers as possible.

• The left & right speakers should be at least 2 feet away from the

side walls.

• The main listening position should be between 4 and 10 feet away

from the speakers.

• In some cases pivoting the woofer of each speaker towards the

listening position will help maximize the soundstage, especially

when listening to stereo music sources.

Use

Figure 3

as a guide.

Left & Right Surround Channels (5.1-Channel System)

Locate the left and right surround speakers on the ceiling between 2 feet and 6 feet behind the listening position. The speakers should be between 6 feet

and 10 feet apart. Since the surround speakers are usually called-upon to create diffuse effects like the sound of wind or rain you can mount them close

to walls without adversely affecting sound quality.

• You can create a more diffuse, spacious surround effect by pivoting the tweeters towards a wall or window, away from the listeners.

Use

Figure 3

as a guide.

Left & Right Surround and Surround Back Channels

(7.1-Channel System)

• Left & Right Surround Speakers: Place the left and right

surround speakers directly to the sides of the listening position,

between 6 feet and 10 feet apart. The speakers can be placed close

to the side walls.

• Surround Back Speakers: Place the surround back speakers

between 2 feet and 6 feet behind the listening position. The

surround back speakers should be closer together than the left and

right surround speakers — between 3 feet and 6 feet apart. Like

the left and right surround speakers, the surround back speakers can

be located close to walls without adversely affecting sound quality.

• You can create a more diffuse, spacious surround effect by pivoting

the tweeters towards a wall or window, away from the listeners.

Use

Figure 4

as a guide.

6'– 10'

apart 6' – 10'

apart

2' – 6'

1'– 2'

Left & Right

Surround

Speakers

Left, Center

& Right

Speakers

>2’

Figure 3: 5.1-Channel Home Theater Speaker Placement

6'– 10'

apart 3' – 6'

apart

2' – 6'

>2’

1'– 2'

Surround

Back

Speakers

Left, Center

& Right

Speakers

Left & Right

Surround Speakers

Figure 4: 7.1-Channel Home Theater Speaker Placement

SONANCE THINLINE™ TL and SSTR

Stereo (2-Channel)

• Place the left and right speakers anywhere from 6 feet to 10 feet apart, with the main listening position as close to midway between the speakers as

possible.

• The speakers should be at least 2 feet away from the side walls.

• The main listening position should be between 4 and 10 feet away from the speakers.

• In most cases pivoting the tweeter of each speaker directly towards the main listening position will help maximize the stereo soundstage.

Use the left and right speaker placement in

Figures 3

and

as a guide.

SELECTING THE PROPER SPEAKER WIRE

For the best sound we recommend that you use premium Sonance

MediaLinQ®speaker cable, which also complies with UL fire rating codes.

You may also experiment with audiophile brands of speaker cable and

interconnects, but be sure to check local codes governing wire that may

be installed within walls or ceilings. Different brands of wire can have

different sonic characteristics, and some may be more compatible with the

sonic “signature” of your various audio system components.

For the best sound you should never use thin-gauge speaker wire – it will

constrict the sound and diminish bass response. Extra resistance in the

speaker wire can make a speaker sound less dynamic and reduce

definition of the bass frequencies. In extreme cases, it can even attenuate

high frequencies. Also, amplifier power is wasted in thin wire with extra

resistance, reducing your system’s maximum output level. To prevent

degrading sound quality, the total wire resistance should be less than 10%

of the speaker’s impedance. This means that for an 8-ohm speaker, the

total resistance of the wire should be less than 0.8 ohms. Refer to

Figure 5

when selecting the proper wire gauge for your system.

PREPARING THE INSTALLATION LOCATION

Building a Back Box into the Ceiling Bay

Sonance ThinLine speakers are designed to provide exceptionally musical performance in a wide variety of enclosure volumes. You can get the very best

performance from your speakers by partitioning a section of the ceiling bay to form a sealed back box with a specific internal volume. Building such an

enclosure will create a dramatic improvement in your speakers’ bass performance and power handling.

Ideal back box volume requirements:

ThinLine TL623R: 1.5 ft3ThinLine TL621R: 1.0 ft3

ThinLine TL622R: 1.2 ft3ThinLine TL623SSTR: 1.5 ft3

Wire resistance in Ohms vs. length of cable run

Distance in Feet 50' 100' 150' 200' 250' 300'

1.04

.65

.41

.26

.16

.10

18 gauge

16 gauge

14 gauge

12 gauge

10 gauge

20 gauge 2.07

1.30

.82

.52

.32

.20

3.11

1.96

1.22

.77

.49

.31

4.14

2.61

1.63

1.03

.65

.41

5.18

3.26

2.04

1.29

.81

.51

6.22

3.91

2.45

1.55

.97

.61

Figure 5: Speaker Wire Resistance Table

SONANCE THINLINE™ TL and SSTR

Insulating the Ceiling Cavity

You can also reduce sound transmission to adjacent rooms and improve speaker performance by inserting a sheet of unfaced fiberglass insulation over the

back of the speaker. To reduce mechanical noise produced by unsupported drywall, install fiberglass insulation in the ceiling bays adjacent to the speaker

location.

Sonafill®

Sonafill (part #91928) is a retrofittable acoustical treatment system consisting of two pillows and four tiles that virtually eliminates noises produced by

resonating drywall. The tiles have pressure-sensitive adhesive and are installed on the back of the drywall on either side of the speaker between the

ceiling joists; the pillows are then stuffed in place behind the tiles. The system dramatically improves midbass sound quality and reduces sound transmis-

sion into adjacent rooms.

INSTALLING THE SPEAKERS

Before Installation: New Construction

For installations in new construction, Sonance recommends using a Symphony FlexBracket (part #92337) to reserve a location for the speaker. The

FlexBracket has perforated wings that can be positioned at any angle around the bracket, and is nailed or screwed to the studs. This serves as a guide

for the drywaller so that the speaker hole will be in the desired location once the drywall is installed.

Before Installation: Retrofit

1. Determine the location for the speaker (see

Speaker Placement

on page 4).

2. Perform an obstruction survey to be certain that there are no studs, conduit, pipes, heating ducts or air returns in the ceiling cavity that will interfere

with the speaker.

3. The cutout for all ThinLine speakers is 85/32” (207mm). There also must be at least 31/32” (77mm) depth within the ceiling cavity.

4. Position the included cutout template where the speaker is to be located and pencil an outline on the ceiling.

• If you are unsure about obstructions, drill a small hole in the center of the outline and insert a coat hanger wire into the hole to feel-around for

possible obstructions.

5. Cut the mounting hole using a drywall saw, and run the speaker wires from the mounting hole to the amplifier location.

• Consult local building codes before running speaker wires through walls.

Installation

Sonance ThinLine speakers feature exclusive FastMount®tabs and an integral RotoLock®mounting system for quick mounting directly into existing ceilings

and walls.

WARNING: The edges of FastMount tabs are very sharp. Use caution when handling the speaker.

1. Remove the paint plug from the speaker.

2. Run speaker wire from the amplifier location to each speaker.

3. Strip ¼” – ½” of insulation from each speaker lead. Twist the strands or tin the exposed wire with solder to ensure that there are no stray strands.

SONANCE THINLINE™ TL and SSTR

(Stray strands that touch each other can cause a short-circuit that can damage your

amplifier.)

4. The speaker’s connector posts are spring-loaded. Push the top of each connector post

down to open the connector and insert the exposed wires into the holes in the posts.

(The TL623SSTR has connectors for both the left and right channels.)

• The speaker’s positive post is labeled with a red dot; the negative post is labeled with

a black dot. Double-check that you connected amplifier “+” to speaker “+” and

amplifier “–” to speaker “–”.

5. Make sure all the RotoLock clamps are in the full clockwise position so that they are

tucked within the mounting hole’s border. Insert the speaker into the hole in the

ceiling (

Figure 6

). The RotoLock system can accommodate a maximum ceiling material

thickness of 1¼”.

• The FastMount tabs will prevent the speaker from falling out of the mounting hole, allowing

the installer to let go of the speaker to pick-up tools or other items (Figure 7).

OTE

AST

OUNT TABS ARE DESIGNED FOR ONE

TIME USE ONLY

F THE

SPEAKER IS REMOVED FROM THE MOUNTING HOLE THE

AST

OUNT TABS WILL

DISCONNECT AND REMAIN INSIDE THE CEILING

6. Tighten the four screws on the front of the speaker baffle. The RotoLock clamps will

automatically rotate into position and begin clamping the speaker (

Figure 8

• When you notice resistance on the screws the speaker has been clamped successfully.

OTE

HE SPEAKER FLANGE IS DESIGNED TO FLEX AND CONFORM TO ANY SMALL

IMPERFECTIONS IN THE CEILING SURFACE

O NOT TIGHTEN THE SCREWS SO

MUCH SO THAT THE FLANGE BOWS

OUT

IMPORTANT: Always u s e l ow-torque settings; NEVER

over-tighten.

7. Attach the grille after the speaker has been installed. Insert about half of the grille into

the groove at the edge of the speaker. Gently fit the remaining half of the grille by work-

ing around the speaker, fitting the grille into the groove as you go.

OTE

OU CAN ADJUST THE TORQUE APPLIED TO THE

OTO

OCK SCREWS TO

ACHIEVE A PROPER GRILLE FIT

RotoLock

Clamps

Figure 8:

RotoLock

Clamps

FastMount

Tabs

Figure 7:

FastMount

Tabs

Figure 6: Insert Speaker

Into Mounting Hole

SONANCE THINLINE™ TL and SSTR

PAINTING THE SPEAKERS AND GRILLES

You can paint the speakers and grilles before installing them, which will eliminate the “paint scar” that can be left on the ceiling if the speaker ever needs

to be removed for service. You can also paint the speakers after installation, but before the grilles are attached. All Sonance ThinLine speakers come from

the factory fitted with a plastic ‘paint plug’ that protects the speaker drivers while the mounting flange is being painted.

Sonance always suggests painting the grille separately from the speaker. Before painting, carefully remove the under-grille cloth. It is held in place with a

light tacking glue that makes it easy to remove.

Spray the grilles with thinned paint (5 parts thinner to 1 part paint), being careful not to plug the holes. Too heavy a coat of paint on the grille will

adversely affect the sound of the speaker.

Once the grilles and flange are painted and dry, replace the under-grille cloth, remove the paint plug from the mounting flange and install the grille.

SPEAKER ADJUSTMENTS

Pivoting Tweeter

ThinLine TL623Rand TL622Rhave a pivoting tweeter. This lets you direct sound toward or away from the listening area,

depending on how the speakers are being used:

• If you’re using the speakers in stereo or as the front left/center/right speakers in a home theater, pivot the tweeter

directly towards the listening area. This will help the sound from the speakers blend into a solid soundstage even if

the speakers are widely separated.

• If you’re using the speakers as surround channel speakers in a home theater, you can create a more diffuse, spacious

surround effect by pivoting the tweeters towards a wall or window, away from the listeners.

To Pivot the Tweeter:

Apply light pressure to the plastic ring around the outside edge of the tweeter dome, as shown in

Figure 9

. Do not

touch or apply pressure to the tweeter dome.

Tweeter Level Control

The ThinLine TL623Rand TL623SSTR have a tweeter level control switch (see

Figure 10

) that lets you boost or cut the tweet-

er’s level by 3dB. This allows you to adjust the speaker’s brightness to better match your listening room or personal taste.

Once you have installed the speakers, listen to a variety of music that you are familiar with. If the music all tends to

sound too bright or dull, use the Tweeter Level Control to compensate. If some recordings sound dull and some sound bright

the speaker is accurately reproducing differences in the recordings, and you should leave the control in the middle (0dB)

position.

Figure 9:

Pivoting the Tweeter

Tweeter

Level Control

Figure 10:

Tweeter Level

Control

SONANCE THINLINE™ TL and SSTR

SPECIFICATIONS

TL623R

Tweeter: 1" (25mm) Silk dome, Ferrofluid-cooled, pivoting

Woofer: 6½" (165mm) Carbon fiber cone, rubber surround

Frequency Response: 43Hz – 20kHz ±3dB

Impedance: 8 Ohms nominal; 6 Ohms minimum

Power Handling: 5 watts minimum; 135 Watts maximum

Sensitivity: 90dB SPL (2.83V 1 meter)

Grille Material: Perforated aluminum

Adjustments: ±3dB Tweeter level

Dimensions (Dia. x Depth): 9¾" (248mm) x 31/32" (77mm)

Cutout Diameter: 85/32" (207mm)

Shipping Weight: 10 lbs. (4.5kg) Pair

TL622R

Tweeter: 1" (25mm) Silk dome, Ferrofluid-cooled, pivoting

Woofer: 6½" (165mm) Polypropylene cone, rubber surround

Frequency Response: 45Hz – 20kHz ±3dB

Impedance: 8 Ohms nominal; 6 Ohms minimum

Power Handling: 5 watts minimum; 125 Watts maximum

Sensitivity: 89dB SPL (2.83V 1 meter)

Grille Material: Perforated aluminum

Adjustments: None

Dimensions (Dia. x Depth): 9¾" (248mm) x 31/32" (77mm)

Cutout Diameter: 85/32" (207mm)

Shipping Weight: 10 lbs. (4.5kg) Pair

TL621R

Tweeter: ¾" (19mm) Silk dome, Ferrofluid-cooled

Woofer: 6½" (165mm) Polypropylene cone, rubber surround

Frequency Response: 50Hz – 20kHz ±3dB

Impedance: 8 Ohms nominal; 6 Ohms minimum

Power Handling: 5 watts minimum; 100 Watts maximum

Sensitivity: 88dB SPL (2.83V 1 meter)

Grille Material: Perforated aluminum

Adjustments: None

Dimensions (Dia. x Depth): 9¾" (248mm) x 31/32" (77mm)

Cutout Diameter: 85/32" (207mm)

Shipping Weight: 9 lbs. (4.1kg) Pair

TL623SSTR

Tweeter: Two 1" (25mm) Silk domes, Ferrofluid-cooled

Woofer: 6½" (165mm) Carbon fiber cone, rubber surround, dual

voice coil

Frequency Response: 43Hz – 20kHz ±3dB

Impedance: 8 Ohms nominal; 6 Ohms minimum

Power Handling: 5 watts minimum; 135 Watts maximum

Sensitivity: 90dB SPL (2.83V 1 meter)

Grille Material: Perforated aluminum

Adjustments: ±3dB Tweeter level

Dimensions (Dia. x Depth): 9¾" (248mm) x 31/32" (77mm)

Cutout Diameter: 85/32" (207mm)

Shipping Weight: 5 lbs. (2.3kg) Each

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sonance Intervenants

Sonance

Sonance CRK10 Manuel utilisateur

Sonance

Sonance VISUAL EXPERIENCE Series Instructions d'installation

Sonance

Sonance VISUAL PERFORMANCE VP62R TL Manuel utilisateur

Sonance

Sonance VP42 Manuel utilisateur

Sonance

Sonance Mariner 52SS Manuel utilisateur

Sonance

Sonance VISUAL PERFORMANCE VP82 Guide d'installation

Sonance

Sonance PS-C43RT Manuel utilisateur

Sonance

Sonance SM55 Manuel utilisateur

Sonance

Sonance ORIGINAL SERIES Manuel utilisateur

Sonance

Sonance Visual Performance VP61 Manuel utilisateur

Sonance

Sonance VISUAL PERFORMANCE VP65R Manuel utilisateur

Sonance

Sonance Silhouette I Manuel utilisateur

Sonance

Sonance VPXT6R Mode d’emploi

Sonance

Sonance Visual Performance VP85 Manuel utilisateur

Sonance

Sonance IS4 C Manuel utilisateur

Sonance

Sonance Visual Performance VP65R SST Manuel utilisateur

Sonance

Sonance VISUAL PERFORMANCE VP10SUB NC Enclosure Manuel utilisateur

Sonance

Sonance DR Series Manuel utilisateur

Sonance

Sonance Symphony S624T Manuel utilisateur

Sonance

Sonance LCR & SUR Speaker Manuel utilisateur

Sonance

Sonance SONANCE ARCHITECTURAL SERIES ASBPC3RS Manuel utilisateur

Sonance

Sonance PROFESSIONAL PS-C43RTLP Manuel utilisateur

Sonance

Sonance Visual Performance VP65S SUR Manuel utilisateur

Sonance

Sonance Visual Perfomance VP46R SST/SUR Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur

Tannoy

Tannoy SYSTEM 600a Manuel utilisateur
