5
SOLIRIS IB
1.Move the awning/blindto its UP position (awning/blindretracted).
2.Press and simultaneouslyfor approx.3secondsuntil the awning/blind begins to movedown.
➜theLEDshinesgreen.
3.Stop the awning/blindat the position you wishto record as the intermediateposition (Correcting the position using , and willnotaf-
fecttheprogrammingprocess.)
4.Press for approx.2 seconds.
➜ThegreenLEDlights off,theintermediate position is programmed.
Iftheawning/blindis above the intermediate position,press .
➜ Theawning/blindwillmove to the intermediate position.
Iftheawningis below the intermediate position,nothinghappens.
IftheSuncontrol sliding switch is setto sun control On and theawning/blind is above the intermediate position,theawning/blindwill auto-
maticallymovetothe intermediate position as soonas the brightness exceeds thevalue set on the Sun potentiometer.
Theawning/blindmustbe in the intermediate position. Tocanceltheintermediateposition,press forapprox.10seconds.
➜TheLEDwillshine red,theintermediate position is now cancelled.
Inawningandvenetian blind modes (chapter 4.1)it is possible to programan intermediate position from the UPlimit position (awning/blind re-
tracted).
Freely selectable intermediate position
4.2
To programme the slattilting operation an intermediate positionmust already have been
programmed(chapter4.2).
1.Set the venetianblind at its UP limit position(blind retracted).
2.Press .
➜ Theblindwillmove to the intermediate position,theslatsareclosed.
3.Press and simultaneously.
➜ Afterapprox.3 secondsthe slats will momentarily moveUP and the LED shinesgreen.
4.Adjust the right tilitingangle using ,and .
5.Press for approx.2 seconds.
➜ThegreenLEDlights off,theslat tilting procedure is nowprogrammed.
Slat tilting
4.3
InVenetianblindmode (chapter 4.1.2) it is possibleto programme a slat tiltingoperation.
UPlimitposition DOWNlimit positionIntermediate position
We reserve the right to make changes due to technical improvements.
4.2.1 Programmingtheintermediate position
OneThe CENTRALIS uno RTS (atleast) connected on theIB Bus must be seton“auto”position.
4.2.2 Reachthe intermediateposition
4.2.3 Canceltheintermediate position
4.3.1 Programmingtheslattilting operation
Oncetheintermediateposition has been reached (chapter4.2.2),theblindautomatically moves upwards with theprogrammed slat tilt.
Iftheblindis below the intermediate positionand the last order wasa DOWN command,you will only get the tiltingof the slats by pressing .
To cancel,the blind is moved downfrom its highest final position(blind retracted) to the intermediateposition using the button. Whenit
reachestheintermediateposition the slat tilting operationautomatically opens the slats. Tocanceltheslat tilting operation,press for approx.
10seconds.
➜Assoonasthe red LED is illuminated,theslattiltand intermediate position are cancelled.
4.3.2 Callinguptheslat tilting operation
4.3.3 Canceltheslattilting operation
