INTRODUCTION
IB810 User’s Manual 1
Introduction
Product Description
The IB810 Pentium 4 Full Size PICMG CPU Card incorporates the
Intel® advanced 845 Chipset Memory Controller hub and supports
478-pin Intel Pentium 4 processors of 1.3GHz and up to 2GHz. This
CPU card represents the perfect choice for those who want superior
performance for rugged and demanding applications in industrial
automation, image processing, multimedia and telecommunications.
The IB810 CPU card has a unique thermal cooling design that makes it
ideal for meeting 1U chassis requirements. Designed for the highest level
of computing performance yet available on SBCs, IBase’s IB810 features
400MHz front side bus, ATA-100 IDE data transfers, and up to 2GB of
DDR memory support. IB810 features ATI Mobility Radeon M6-M
(8MB embedded) or M6-D (16MB embedded) graphics controller
offering 4X AGP and 8MB or 16MB of internal video Double Data Rate
RAM that supports interface for TMDS, LVDS, CRT and TV-out
interface.
This single board computer also offers flexibility with 4 USB ports, ICH2
integrated Ethernet, watchdog timer, DiskOnChip socket, ISA High
Drive, PCI to ISA bridge and an MicroPCI socket supporting various
MicroPCI add on cards. IB810 is a high-performance flexible CPU card
that comes with one built-in MicroPCI socket that supports MicroPCI
daughter cards with VGA, VGA/LAN, Ethernet (LAN), SCSI, and IEEE
1394 functions.
DiskOnChip flash disks are storage devices that have no moving parts
and emulate FDD/HDD with Flash/RAM/ROM offering reliable
data/program storage and long life span. They are reliable and suitable for
industrial or other harsh environments characterized by motion, shock,
vibration, adverse temperature, dust and humidity. Other features include
faster data access, longer MTBF, lower power consumption, cost
effective for small capacity and small form factor.
