From Bicom Systems Wiki
Contents
1 Introduction - How to use Snom 320 with PBXware
■
2 Registering Snom 320
■
2.1 Requirements
■
2.2 Manual Configuration
■
2.3 Auto Provisioning Configuration
■
2.4 Paging
■
2.5 Glossary
■
Introduction - How to use Snom 320 with
PBXware
This "How to" is written to as general guide on how to use your Snom 320 with PBXware using
5.2b Snom 320 firmware. t covers the most common tasks required to have your Snom 320
working efficiently.
Registering Snom 320
Requirements
1. Snom 320 firmware.
- Make sure that the device is loaded with 5.2b firmware.
2. DHCP server.
- Fully configured and operational DHCP server.
Manual Configuration
UAD Settings
STEP ONE: PBXware IP address.
1. Find out the IP address of PBXware server.
STEP TWO: Login to PBXware.
1. Open a new browser window and enter the IP address to access the PBXware administration
interface login screen.
Example: http://192.168.1.2
an example with IP address
2. Hit "Enter" on your keyboard.
3. Login to PBXware with your e-mail address and password.
2. The standard options window will be shown below.
3. Select Snom 320 from the "UAD" select box.
4. Select Location: "Local" or "Remote".
Note:
-"Local" is for all extensions registered on LAN.
-"Remote" is for all extensions registered from remote networks, WAN, Internet etc.
5. Click on the "Next" button.
STEP TWO: Extension values.
1. Enter values into required field text boxes.
REQUIRED FIELDS:
Name:
Enter a name for the extension being created. Example: John Smith.
E-mail:
Enter the e-mail address associated with this extension. This e-mail address will receive all
system notification messages. Example: [email protected].
Creating
Extension/Extensions Add
an example with details filled in
2. Click on the "Save" button.
Creating
Extension/Extensions Edit
an example with details filled in
3. Click on the "Save & E-mail". Account details will be sent to the e-mail address associated
with this extension.
OPTIONAL FIELDS:
Extension:
An auto-generated extension number based on the next available sequential number. An
extension value can be changed. Example: 1000.
Username:
Username is auto generated/populated and cannot be changed since it allows the system to use
this value for other important operations.
Secret:
A secret value associated with the UAD is auto-generated in order to allow the UAD to
successfully register with the system. The secret value can be changed.
PIN:
An auto-generated PIN will allow access to voicemail and online self care.
Registering Phone
STEP ONE: Electricity and Ethernet.
- The Snom 320 needs electricity. Plug the adapter into its jack then connect it to the electricity
network.
- Connect the ethernet port to a hub, router or switch as to access LAN.
Registering Phone
After successfully connecting your Snom 320 to the electricity and data networks it is time to
register it to <%PRODUCT%>.
STEP TWO: Snom 320 IP address.
Find out the IP address of the Snom 320 connected to network.
1. Press the "Help" button.
2. Press the appropriate button to find out the IP address assigned to Snom 320.
3. The IP address will be shown on Snom 320 display.
Registering Phone
STEP THREE: Snom 320 Web Interface.
1. Open a new browser window and enter the IP address in order to access Snom 320
administration interface.
Example: http://192.168.1.101
an example with IP address
2. Hit "Enter" on your keyboard.
STEP FOUR: Configuring Snom 320.
1. Click on "Line 1" link.
2. Enter the following details into the respective fields.
REQUIRED FIELDS:
Account
<%PRODUCT%> extension number. Example: 1000.
Password
The Secret of the extension as received in the e-mail associated with this extension. Example:
3dX3r5
Registrar
IP address of PBXware server. Example: 192.168.1.2
an example with details filled in
3. Click on the "Save" button.
OPTIONAL FIELDS:
Display name
Example: John Smith, Reception, Entrance Main, Agent One etc.
Authentication Username
Usually the same number as for account.
Other fields:
Other "options" or "fields" you should left blank or as it is by default, they have not importance
for registering Snom 320 to PBXware.
4. Click on "Advanced" link.
5. Navigate down and click on "Reboot" button. Snom 320 will reboot for changes to take effect.
Azra - Kredite...
- Conclusion: If everything is done as above described you should have successfully registered
your Snom 320 to PBXware. Dial *123 to verify registration.
- For further information, please contact the manufacturer or check their web site
www.snom.com.
Auto Provisioning Configuration
UAD Settings
STEP ONE: PBXware IP address.
1. Find out the IP address of PBXware server.
STEP TWO: Login into PBXware.
1. Open a new browser window and enter the IP address to access the PBXware administration
interface login screen.
Example: http://192.168.1.2
an example with IP address
2. Hit "Enter" on your keyboard.
3. Login to PBXware with your e-mail address and password.
STEP THREE: UAD status.
1. Make sure the UAD is enabled. To check the UAD status, navigate to "Settings:UAD" and click
on the "edit" icon corresponding to "Snom 320".
