Snapper 1696005 Manuel utilisateur

Not for

Reproduction

Parts Manual fo

26", 28" & 30" TWO STAG

2011

LARGE FRAME SNOWTHROWERS

Revision: - 6/14/2011

Briggs & Stratton Yard Power Products Group

Manual No. 7105286

535 Macon Road

McDonough, GA, 30253 U.S.A.

800-935-2967

Descri

tionModel No.

169600

L1226E

169600

L1528E

1696011 L1528EX

169600

L1730E

169601

L1730EX

Not for

Reproduction

Not for

Reproduction

Table Of Content

TP 400-5495---LF-N

26", 28" & 30" TWO STAGE

2011 3

Manual No. 7105286

PAGE GROUP

4Handles & Controls Group

8Auger Housing Group

10 Auger Drive Group

12 Gear Case Assembly - Heavy Duty

14 Chute & Rotation Group

16 Engine & Frame Group - 11.5TP

20 Engine Group - 14.5HP & 16.5HP

24 Traction Drive Group - Easy Turn

28 Decals Group

30 Wheels & Tires Group

Not for

Reproduction

Manual No. 7105286 26", 28" & 30" TWO STAGE

2011

Handles & Controls Group

Not for

Reproduction

Footnotes:

Manual No. 710528626", 28" & 30" TWO STAGE

2011 5

Handles & Controls Group

Part No Descri

tionItem Qty

0010 1737966 1 HEADLIGHT, Oval

0010-10 ----- 1 * BULB, 881-12V 27W Halogen Lamp (Included with Ref. No. 0010)

0020 1738247D 1 COVER, Panel

0030 1960715 3 SCREW, Truss Head Torx, 1/4-20 x 3/4

0040 1732471 1 CABLE & SPRING ASSEMBLY, Auger Drive, RH

0050 1737759A 1 HANDLE, Lower

0060 1734587A 1 HANDLE, Upper, RH

0070 1734586A 1 HANDLE, Upper, LH

0080 1921333 2 CAPSCREW, Hex Head, 5/16-18 x 1, G5

0090 1664847 2 SCREW, Hex Washer Head, Taptite, 5/16-18 x 3/4

0100 1935048 2 NUT, Hex Flange, Two Way Lock, 5/16-18

0110 7035744 4 KNOB, Wiing, 5/16-18

0120 1750299 2 BOLT, Carriage, Curved Head, 5/16-18 x 2-1/4

0130 7091189 2 BOLT, Carriage, Curved Head, 5/16-18 x 2

0135 7090391 4 WASHER, Internal Tooth, 5/16

0140 1920397 4 NUT, Hex Lock ESNA Light, 1/4-20

0150 1678392 2 SPACER, 1/4 ID x 3/8 OD x 5/16"

0160 1921962 4 CAPSCREW, Hex Head, 1/4-20 x 1-3/4, G5

0170 1739783A 1 LEVER, Clutch, RH

0180 1739782A 1 LEVER, Clutch, LH

0190 1733505BM 1 BRACKET, Pivot, Free Hand

0200 1736360 1 ROD, Hold Down

0210 1733095 1 SPACER, 1/4 ID x 3/8 OD x 1/8"

0220 1960353 1 WASHER, 1/4

0230 1736542 2 SPACER, Stepped

0240 1750554 2 BOLT, Shoulder, 10-24

0250 1933896 2 NUT, Hex Lock, Nylon Insert, 10-24

0260 1726317 2 GRIP

0270 2820263 2 NUT, Hex, 5/16-24

0280 1917356 1 LOCKWASHER, Spring, 5/16

0290 1739290 1 BALL JOINT

0300 1751543 1 ROD, Speed Control

0310 1923701 1 CAPSCREW, Hex Head, 3/8-16 x 2, G5

0320 1931277 3 NUT, Hex Flange, Whiz Lock, 5/16-18

0330 724361 1 SPRING, 3/4"

0340 1918266 1 WASHER, 3/8

0350 1919439 1 NUT, Hex Lock ESNA Light, 3/8-16

0390 1737684 1 BRACKET, Controls

0400 1960589 1 SCREW, Phillips Head, #10-24 x 3/4

0410 1733192 1 KNOB, Slot Speed

0420 1933896 1 NUT, Hex Lock, Nylon Insert, 10-24

0430 1736836 1 SPEED LEVER

0440 727331 1 CABLE, Forward Drive

0450 723154 1 BOOT, Spring End Cover

Note* See your local hardware store for replacement bulbs & fuses.

Not for

Reproduction

Manual No. 7105286 26", 28" & 30" TWO STAGE

2011

Handles & Controls Group

Not for

Reproduction

Footnotes:

Manual No. 710528626", 28" & 30" TWO STAGE

2011 7

Handles & Controls Group

Part No Descri

tionItem Qty

0460 723259 1 BRACKET, Cable Adjusting

0470 1733509 1 ROD & SPRING ASSEMBLY

0480 2108360 2 SPRING, Compression, 2-1/4

0490 1927429 2 SCREW, Hex Washer Head, Taptite, 1/4-20 x 5/8

0500 723873 3 BOLT, Carriage, 5/16-18 x 3/4

0510 1732064BM 1 SUPPORT, Dash

0520 2825094 5 TIE, Self Lock

0570 1750773 1 HARNESS, Deflector

0570-10 ----- 1 * FUSE, 10 Amp (Included with Ref. No 0570)

0600 725331 2 WASHER, Flat, 11/32

0620 5025391 3 NUT, Hex Flange, Nylock, 1/4-20

Note* See your local hardware store for replacement bulbs & fuses.

Not for

Reproduction

Manual No. 7105286 26", 28" & 30" TWO STAGE

2011

Auger Housing Group

Not for

Reproduction

Footnotes:

Manual No. 710528626", 28" & 30" TWO STAGE

2011 9

Auger Housing Group

Part No Descri

tionItem Qty

0010 1687614 1 AUGER HOUSING ASSEMBLY, 26"

0010 1687613 1 AUGER HOUSING ASSEMBLY, 28"

0010 1687606 1 AUGER HOUSING ASSEMBLY, 30"

0020 1733102BM 2 DRIFT CUTTER

0030 725347 2 NUT, Wing, Serrated, 5/16-18

0040 723873 2 BOLT, Carriage, 5/16-18 x 3/4

0050 1739305 3 NUT, Hex Flange, ESNA, 5/16-18

0060 1732384BM 1 BLADE, Scraper, 26"

0060 1709947BM 1 BLADE, Scraper, 28"

0060 1732385BM 1 BLADE, Scraper, 30"

0070 1960699 7 BOLT, Carriage, Short Neck, 5/16-18 x 5/8, G5 (Qty 5 used on 26" & 28")

0080 1935048 7 NUT, Hex Flange, Two Way Lock, 5/16-18 (Qty 5 used on 26" & 28")

0090 1960711 4 BOLT, Carriage, Short Neck, 3/8-16 x 3/4, G5

0100 1727854BM 2 SKID SHOE

0110 1960687 4 NUT, Hex Flange, ESNA, 3/8-16

0120 1733103 2 BEARING, Flange, 1.383 ID x 3.75OD

0130 1931202 6 SCREW, Hex Washer Head, Taptite, 5/16-18 x 1-1/4

0140 722401 2 NUT, Nylock 10 x 24

0150 1736620 2 CLAMP

0160 1960569 2 SCREW, Truss Head Torx, #10-24 x 3/8

0170 1736094 1 BRUSH, Cleanout

0180 2108202 1 BEARING, Ball, 3/4 ID x 1-3/4 OD

0190 1665982 1 RETAINER, Bearing

0200 1931333 3 BOLT, Carriage, Short Neck, 5/16-18 x 3/4, G5

0210 1734932BM 2 COVER, Bushing

Not for

Reproduction

Manual No. 7105286 26", 28" & 30" TWO STAGE

2011

Auger Drive Group
