Smith & Noble Board Manuel utilisateur

Wall Mount

Step by Step Installation Instructions

Board Mounted

Cornice/Valance

smithandnoble.com

800.248.8888

Table of Contents

Step 1 - Getting Started (Parts & Tools) ................3

Overview - ...........................................4

Step 2 - Attaching the Brackets ......................5

Step 3 - Mounting the Cornice/Valance ...............6

Optional - Care & Cleaning ............................6

Warranty ..................................Back Cover

A Smooth Set-Up

We want you to love your new Cornice/Valance and that

includes having a smooth installation experience. If you

encounter any difculties or questions, please reach out to us

for help. It’s why we’re here. Call us at 800.248.8888 for more

info on installation.

We recommend you hold on to all packaging until your

hardware is fully installed. Should something go wrong (we

strongly doubt it), we want any potential returns to be a

painless as possible.

Customer Service Hours

Monday — Friday: 6am — 6pm PT

Saturday — Sunday: 7am — 4pm PT

smithandnoble.com

Everything

You Need

smithandnoble.com

800.248.8888

MOUNTING

BRACKET

MOUNTING

BRACKET

MOUNTING

BRACKET

MOUNTING

BRACKET

Getting Started

PENCIL & SCREWDRIVER (NOT INCLUDED) POWER DRILL & LEVEL (NOT INCLUDED)

SCREWS

STEP 1 — PARTS & TOOLS

WALLBOARD OR PLASTER: Hollow wall applications: Use a secure fastener designed

specically for this purpose.

METAL: Prepare by pre-drilling holes and then using the included screws.

CONCRETE, STONE, BRICK OR TILE: Use a masonry drill and surface-specic plugs, anchors, or

screws.When selecting a fastener be sure it’s designed to support the weight of the product being

installed (if you’re not sure, either give us a call or ask a professional at your local hardware store).

Once obtained, follow the fastener manufacturer’s instructions regarding proper installation.

TOOLS YOU WILL NEED TO INSTALL YOUR HARDWARE: Pencil, screwdriver, ¼" nut driver,

level, and a drill with a 7⁄64" drill bit.

Note: It’s important to monitor the amount of pressure you apply when using a drill. If the screws

are too tight this may cause the screw itself to break off in the wall or window frame.

MOLLY

BOLT

SELF DRILLING

ANCHOR

TOGGLE

BOLT

Before you begin, check the accompanying diagram to make sure you have all the parts you need.

You’ll need to make sure the surface you intend to install your hardware is sturdy enough to

accommodate the brackets. If you’re screwing

directly into a surface this means locating wood

studs that are strong enough to securely bond

with the included screws. Otherwise, you’ll

need to use a secure fastener (as illustrated) but

please note this piece is not included.

MOUNTING BRACKETS

Fabric Cornice/Valance

Cornice depth over 3"

OVERVIEW

DEPTH > 3" DEPTH < 3"

Fabric Cornice

Cornice depth 3" and under

smithandnoble.com

800.248.8888

STEP 2 — ATTACHING YOUR BRACKETS

Attaching the Brackets

Center the cornice/valance over the

window opening. Mark the position

of the ends of the cornice/valance on

the wall. Attach the mounting brackets

to the wall 3" in from the marks at the

desired height with screws provided.

Make sure the mounting brackets are

level with one another.

STEP 3 — MOUNTING THE CORNICE/VALANCE

CARE & CLEANING

Mounting the Cornice/Valance

Set the cornice/valance on top of the

brackets. Center over the window

and push back against the wall.

Attach the cornice/valance with the

short screw provided.

Care & Cleaning

Minimal care and cleaning is needed to maintain the beauty of your cornice.

Occasional light vacuuming with a soft bristle attachment or gentle feather dusting is all

that is required to keep your cornice looking fresh and neat.

Attaching the Brackets

(Short Bracket)

Turn the cornice/valance over onto its

top and lay it on a at surface. Attach

the mounting brackets 5" in from each

end and ush with the back of the

dustcover top. If additional brackets are

required, space them equally between

the two existing brackets. Attach with

the short screws provided.

Mounting the Cornice/Valance

(with Short Bracket)

Position the cornice/valance on the wall

at the desired height. Using a pencil,

mark the center of each bracket slot.

Install one of the mounting screws at

one of the marked locations. Install the

additional mounting screws making

sure they are aligned with the rst.

Leave the screws projecting from the

wall approximately 1/8". Slide the

cornice/valance brackets down onto

the screws.

Parts & Tools

FABRIC CORNICES

Cameron Cornice

Warranty Service

The enjoyment of your Cornice should be everlasting, which is why our

products come with a limited lifetime warranty. The warranty applies to

the original owner, requires a proof of purchase (hang on to your receipt!)

and covers defects in material or craftsmanship. Hardware must have been

properly installed. We reserve the right to determine if your hardware

warrants a repair or a replacement. In need of warranty service? Call us at

800.248.8888 and we’ll arrange for a repair or replacement ASAP.
