Easily configured with any Web Browser using the New and

Improved Web-based Interface

NAT-based firewall provides a high level of security for your

network

Built-in Parallel and USB Print Server alleviates the need to keep

one PC on at all times to act as a print server

True plug and play device – All ports can be cascaded to another

switch or PC to grow your network easily. No crossover cable

required

Hacker Attack Logging provides a method of monitoring any

potential hackers trying to break into your network

Protect your network with the Advanced Stateful Packet

Inspection (SPI) Firewall

Manage your network access with content filter options based on

Time, Date, Port, and MAC Address

VPN pass-through support allows remote users secure access to

their corporate infrastructure

Platform independent – works with Windows, Mac, and Linux

Four high-speed 10/100 Mbps auto-sensing MDIX/MDI ports LAN

ports – no crossover cables required

10/100Mbps WAN port

Firewall security through Network Address Translation

Network Log

VPN tunneling via L2TP, PPTP, and IPSec pass-through

Built-in Parallel and USB Print Server

Broadband Router SMCBR14UP

Barricade™ 4-port Broadband Router

with Parallel and USB Print Server

www.smc.com

The Barricade™ SMCBR14UP 4-port Broadband Router with

Parallel and USB Print Server is an ideal all-in-one networking

solution for home and small business users. This platform

independent multi-functional broadband router combines

4-port 10/100 Mbps dual speed switch, built-in Parallel

and USB print server, and firewall capability for security

against hackers and other an authorized users.

The Barricade™ SMCBR14UP 4-port Broadband Router

with Parallel and USB Print Server provides a WAN port as

well as Network Address Translation (NAT), which translates

your WAN IP address into private LAN IP addresses keeping

your internal network hidden from the rest of the

Internet. Barricade fully supports VPN tunneling via

L2TP, PPTP, and IPSec pass-through allowing remote

users secure access to their corporate infrastructure.

Also, a feature known as Network/ Security log has been

implemented which detects, logs, and reports any potential

hacker attacks to your network. The new broadband router

also allows the connection of multiple users to the

Internet using a single WAN IP address. LAN IP addresses are

auto-assigned and easily managed through DHCP server

capabilities, and the IP routingsupports a range of popular

applications. This new device is a complete networking

solution for PC or Mac users, and is backed by SMC’s limited

lifetime warranty and 24/7 technical support.

FEATURES BENEFITS

OVERVIEW

TECHNICAL SPECIFICATIONS SMCBR14UP

NETWORK INTERFACE

• 4 - 10Base-T/100BaseTX RJ-45 ports (Auto-MDIX/MDI)

• 1 - 10Base-T/100BaseTX Broadband WAN port

• 1 - DB-25 (female) – Parallel Printer Port

• 1- USB Jack (type A), USB 1.1 Compliant

INTERNET SHARING METHODS

• Static IP, Dynamic IP, PPPoE, PPTP

PROTOCOLS

• TCP/IP, VPN pass-through (IPSEC, PPTP)

CABLING TYPE

• 10Base-T: UTP/STP Category 3 or 5

• 100Base-TX: UTP/STP Category 5 or better

SPEED

• WAN:

• 10 Mbps (10Base-T Ethernet)

• 100 Mbps (100Base-TX Fast Ethernet)

• LAN:

• 10 Mbps (10Base-T Ethernet) or

• 100 Mbps (100Base-TX Fast Ethernet)

LEDs

• Power

•Status

• 1 - WAN (10M /100M)

• 4 - LAN (10M /100M)

• USB Status

PRINT SERVER

• Supports Win 95/98/NT/2000/XP, UNIX LPR

NAT Router - Ethernet Interface

• Static or dynamic IP, PPPoE

CONFIGURATION & MANAGEMENT

• Web-based

MAXIMUM USERS

• DCHP server up to 253 IP addresses

SECURITY FEATURES

• Stateful Packet Inspection (SPI)

•NAT

• Denial of Service (DoS)

• IP / Port / MAC Address / URL Filtering

• Email Alerts

• Multiple login Accounts/ Admin and guest account

ROUTER FEATURES

• Port Forwarding

• Special Applications

• DDNS

• Syslog Server

• Wake up on LAN

• RIP V.1 and RIP V.2 support

DIMENSIONS

• 9 .25 x 5.31 x 1.49 in

• 235mm x 135mm x 38 mm

WEIGHT

• 0.8 lbs

•0.36 kg

OPERATING

• Temperature: 0~40oC / 32~104oF

• Humidity 10%~90% non-condensing

STORAGE

• Temperature: -20~70oC / -4~158oF

• Humidity: 0~95% non-condensing

POWER REQUIREMENTS

• Input Power 5V 2A

• AC power consumption _11Watts max (AC 0.1A/110Volt)

STANDARDS

• IEEE 802.3 10Base-T Ethernet

• IEEE 802.3u 100Base-TX Fast Ethernet

COMPLIANCES - EMC/SAFETY

•FCC

•CE

•VCCI

• UL

WARRANTY

• Limited Lifetime

www.smc.com

Contact

North America

38 Tesla

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/ Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local

country contact information
