SMC Networks SMC EZ Switch 10/100/1000 SMCGS8P-Smart Manuel utilisateur

OVERVIEW

The SMC EZ Switch™ 10/100/1000 (SMCGS8P-Smart) is an 8-port 10/100/1000 gigabit smart switch with

PoE that brings the speed of gigabit ethernet to the desktop with the ﬂ exibility of PoE. Equipped with 8 auto-

MDIX ports and 1 combo SFP port, this gigabit switch is suitable for enterprise or SMB environments that

demand high performance and ﬂ exible PoE installations. Power over Ethernet enables you to install wireless

access points, IP cameras or VOIP phone systems without the need to run extra power sockets.

The SMCGS8P-Smart also provides a ﬂ exible web based management interface to enable the conﬁ guration

of switch features, port settings including security, QoS with 4 priority queues, link aggregation, VLAN’s and

PoE. These features allow traditionally unmanaged networks to increase throughput and ﬂ exibility. Security

is becoming critical in next generation networks so this switch has added security features to protect your

network. SMC has brought together ease of use, critical features and the ﬂ exibility of PoE into one package.

The SMCGS8P-Smart is ideal for desktop or wiring closest edge conﬁ gurations.

www.smc.com

SMCGS8P-Smart

EZSwitch™ 10/100/1000 8 Port Gigabit Web Managed

Smart Switch including 1 Combo port (RJ-45/SFP)

10G FIBER

1G FIBER

10G COPPER

1G COPPER

10/100

PoE

PHONE CABLES

WIRELESS

LEGEND

10G FIBER

1G FIBER

10G COPPER

1G COPPER

10/100

PoE

WIRELESS

LEGEND















APPLICATION DIAGRAM

POWER TO CONNECT

KEY FEATURES

10/100/1000 Gigabit Copper Ports and 1 combo port

(RJ-45/SFP)

Flexible QoS and VLAN

The gigabit Ethernet ports provide high speed and legacy

connections to all nodes on the network, while the combo port

allows ﬁ ber connections to be connected, thereby ensuring a

migration path for network installations.

Qos allows prioritization based on 802.1p and DSCP using 4

priority queues for better network performance and VLAN support

both port and tag based VLANs for more efﬁ cient management.

Smart Web Management Power over Ethernet Capability

Flexible and easy to use web interface enables quick installation

and conﬁ guration for any user

With IEEE802.3af compliant PoE on non-Combo Copper ports,

devices such as VoIP Phones and IP cameras can be installed

without running separate power lines. Maximum of 62W per de-

vice.

SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS

PORTS

• 8 Auto-MDIX 10BASE-T/100BASE-TX/1000BASE-T RJ-45 ports

• 1 Combo SFP ports

NETWORK INTERFACE

• 10BASE-T: RJ-45 UTP Cat. 3,4,5

• 100BASE-TX: RJ-45 UTP Cat. 5

• 1000BASE-T: RJ-45 connector

• Multimode ﬁber cable; 62.5/125 or 50/125 microns

• Single-mode ﬁber cable: 9/125 micron

SWITCH FABRIC

• 16Gbps

SWITCHING DATABASE

• 4K MAC address entries

LED

• System: Power

• Port: Link/Act; Status of SFP ports; PoE

• 1000/100M

WEIGHT

• 2.06Kg

• 4.54lbs

SIZE

• 33.0 x 20.3 x 4.4 cm

• 12.99 x 7.99 x 1.73in

MEMORY BUFFER

• 144 Kbits

POWER CONSUMPTION

• 165W (full PoE Load) Maximum

• AC Input - 100 to 240V, 5-60Hz, 1.5A

• Maximum Current - 1.5A@110VAC, 0.75A@220 VAC

TEMPERATURE

• Operating: 0 to 45 °C (32 to 114 °F)

• Storage: -40 to 70 °C (-40 to 158 °F)

HUMIDITY

• 10% to 90% (non-condensing)

MANAGEMENT FEATURES

• In-Band Management

• Web-based HTTP and SNMP

• Software Loading

• HTTP In-Band

SWITCH FEATURES

• Forwarding Mode

• Store-and-forward

• VLAN Support

• Up to 255 groups; port-based or with 802.1Q

• VLAN tagging

• Quality of Service

• Supports four levels of priority with ﬂexible classiﬁcation

and prioritization based on 802.1p / DSCP

• Port Trunking

• Port Mirroring

• Jumbo Frame support

• Cable Diagnostics

• IP Filter

• Static Port Security

• IGMP Snooping

STANDARDS

• IEEE802.3 Ethernet, IEEE802.3u Fast Ethernet,

• IEEE802.1p Priority tags

• IEEE802.1Q VLAN

• IEEE802.1ac VLAN tagging

EMC/SAFETY COMPLIANCES

• CE Mark

IMMUNITY

• EN 61000-4-2/3/4/5/6/8/11

EMISSIONS

• FCC Class A, CISPR Class A, EN 61000-3-2/3

• VCCI Class A

SAFETY

• CSA/CUS (CSA60950-1 & UL60950-1)

• TUV / GS EN60950-1

• CB IEC60950-1

WARRANTY

• Please check www.smc.com for the warranty

terms in your country/region

SMC1GSFP-SX

• 1G SX SFP Transciever, 550M, Multimode ﬁber

SMC1GSFP-LX

• 1G LX SFP Transciever, 10Km, Singlemode ﬁber

SMC1GSFP-ZX

• 1G LH SFP Transceiver, 70Km, Single-mode ﬁber

CONTACT

North America

20 Mason

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local country

contact information

of SMC Networks in the United States or other countries. Other trademarks

or registered trademarks are the property of their respective owners. Infor-

7/2010

www.smc.com

TECH SPECS - SMCGS8P-SMART
