SMC2662W

11Mbps Wireless USB Adapter

11Mbps Adapter

The Wireless USB adapter combines the ease-of-use and

convenience of USB-enabled PCs with the benefits of

11Mbps wireless operation in a full-featured solution for

the networked environment It connects instantly with

an existing Ethernet installation to support mobile

users, temporary work sites, sharing of peripherals and

wireless multimedia

Wireless solutions provide the ultimate in mobility,

simple and flexible installation options, a reduced cost

of ownership (no cabling costs or maintenance), and

excellent scalabilty in supporting additional PCs on the

LAN 11Mbps wireless LAN solutions are ideal for use

with cable or xDSL modems and SOHO applications

In the typical wireless configuration, an Access Point

(SMC2655W) connects to a wired network The Access

Point supports up to 64 users, with a maximum range of

450 metres Users access the LAN via SMC wireless

adapters in their notebooks or desktops The wireless LAN

adapters interface between the client Network Operating

System and the Access point In a peer-to-peer

configuration, one wireless card is needed for each

computer, but no Access Poin t is required

All SMC products are backed by a limited lifetime

warranty

Features and Benefits

High Performance & Functionality

lWireless connectivity via USB port

lUp to 11Mbps wireless LAN

lUp to 450 metres operating range

l2 4 GHz frequency band

lDirect Sequence Spread Spectrum (DSSS)

l64-bit or 128-bit encryption

Flexible System Management

lInstant access to shared information without the

need to plug in

lNetwork managers can set up, move, or expand a

new LAN with no need for installation or moving

wires

l11Mbps performance will meet most forseeable

networking needs

lWireless LANs are tremendously convenient, help

to enhance productivity, and provide a real cost

benefit over traditional wired networks (no

installation or maintenance expenses)

lPlug-and-play; no configuration needed

Compatibility

lIEEE 802 11b

lWindows 98/ Me/ 2000

EZ Connect™ Wireless USB Adapter

SMC2662W

Data Sheet

Product Model No. Description

Wireless Adapter SMC2662W EZ Connect 11Mbps Wireless

USB Adapter

Operating Systems

Win98 WinNT Win2000

Specifications

Physical Characteristics

Data ates

l11, 5 5, 2, 1Mbps

Maximum Channels

lUS & Canada: 11

lEurope: 13

lJapan: 14

Operating ange

lUp to 450 metres

Network Configuration

lAd-hoc (peer-to-peer)

lInfrastructure

adio Signal Type

lDirect Sequence Spread Spectrum (DSSS)

Encryption

l64-bit or 128-bit key

Operating Frequency

lUS Canada: 2 400 - 2 483 5GHz

lETSI Japan: 2 400 - 2 497GHz

Sensitivity

lMin -76dBm for 11Mbps @BER 10E-5;

lMin -80dBm for 5 5/ 2/ 1Mbps @BER 10E-5

Modulation

lQPSK, BPSK, CCK

Output Power

l13dBm (50mW) (maximum)

Operating Systems

lWindows 98/ ME/2000

Inband Management

lWindows 98/ ME/2000 Configuration Utility

Power Consumption

l400mA @5v transmit

l300mA @5v receive

SMC Net orks Europe

Head Office

Edificio Conata II

Fructuós Gelabert 6-8 20,4a

08970 - Sant Joan Despi

Barcelona

Spain

Telephone

+34 93 477 4920

Facsimile

+34 93 477 3774

SMC Net orks

Spain

Calle Josefa Valcarcel, 8

28027 - Madrid

Spain

Telephone

+34 91 320 2884

Facsimile

+34 91 320 8438

SMC Net orks

Northern Europe

Ground Floor, Exa House

Alexandra Court

Denmark Street

Wokingham

Berkshire, RG40 2SL

United Kingdom

Telephone

+44 (0)118 974 8700

Facsimile

+44 (0)118 974 8701

SMC Net orks

Nordic

Vallingbyplan 26, 2 tr

SE-162 65 Vallingby

Sweden

Telephone

+46 (0) 8 687 0700

Facsimile

+46 (0) 8 87 62 62

SMC Net orks

South Africa

Zonneblom Building

16th Road

Constantia Square

Midrand

South Africa

Telephone

+27 (0) 83 292 40 43

Facsimile

+27 (0) 11 805 80 60

SMC Net orks

Southern Europe

2 - 8 rue des Bourets

92150 Suresnes

France

Telephone

+33 (0) 1 41 38 32 32

Facsimile

+33 (0) 1 41 38 01 58

SMC Net orks

Central Europe

Freischützstr 81

D-81927 Munich

Germany

Telephone

+49 (0) 89 92861-0

Facsimile

+49 (0) 89 92861-230

SMC is a registered trademark; and EtherPower, EZStart, SimulTasking, TigerSwitch and SuperDisk are trademarks of SMC Networks, Inc

Size

l13 33 x 10 79 x 2 85cm

Weight

l0 19Kgs

LED Indicators

lPower

lTransmit

lReceive

Antenna

lExternal

Temperature

lOperating: 32˚ - 122˚F

lStorage: 32˚ - 158˚F

Humidity

l0% - 95% (non condensing)

Standards Conformance

Compliances

lFCC Part 15, Sec 15107 and 15 109 (USA)

lETSI 300 328, ETSI 300 826

lEN 55022 Class B, EN 60950

lCE Mark

Standards

lIEEE 802 11b

lUSB 11

www.smc.com

EZ Connect™ Wireless USB Adapter

SMC2662W

Data Sheet
