SMC Networks HPAV-ESW - FICHE TECHNIQUE Instructions d'utilisation et de sécurité

Key Features and Benefits

The EZ Connect Powerline™ Adapter (SMCHPAV-ESW) uses the in-house power network

for high-speed 200Mbps data transmission and is compliant with the HomePlug AV standard.

It comes equipped with 3 Fast Ethernet ports, turning any AC power outlet into a network

connection for up to 3 network-enabled devices such as PCs, laptops, gaming consoles, or

broadband/ ADSL routers. In combination with another HomePlug AV adapter like

SMCHPAV-ETH2 the SMCHPAV-ESW allows to easily share network resources and access

the internet through a secure, high-speed powerline network connection. Supporting Quality

of Service (QoS), the adapter automatically prioritizes video and audio traffic ensuring smooth

data transfer and multimedia streaming. The installation is easy and does not require any

driver or configuration, with push-button 128-bit AES data encryption for maximum security.

Product Overview

SMCHPAV-ESW

200Mbps HomePlug AV Adapter

with 3 Ethernet Ports

No new wires required

Instantly turns any available power outlet into an Ethernet

connection, saving time and money in networking the home.

Network traffic prioritization

Supporting Quality of Service (QoS) the adapter automatically

prioritizes video and audio traffic ensuring smooth data transfer and

multimedia streaming.

Simple push security

Push-button security allows to easily enable 128-bit AES encryption for

maximum data security.

Plug-and-Play, no configuration required

Hassle-free plug-and-play installation. Pre-configured

hardware allows immediate connectivity.

Operating system independent

Works with any operating system, including but not limited to

Windows 7/ Vista/ 2000/ XP, Linux and MacOS.

3-port Fast Ethernet Switch

Connect up to 3 network-enabled devices such as PCs, laptops,

gaming consoles or broadband/ ADSL routers.

Power Saving

Disable LEDs of unused ports to help save energy.

Network Interfaces

-3x RJ-45 (10/100Mbps), Auto-sensing

-1x Powerline (200Mbps)*

LEDs

- One Power

- One Data

- Three Ethernet

Power Supply

- AC 100-240V @ 50-60Hz 60mA

- Consumption: 7W

Standards

-HomePlug AV 1.1

- IEEE 802.3 (Ethernet)

-IEEE 802.3u (Fast Ethernet)

Encryption

-128-bit AES encryption

- Push-button security

Typical Coverage

- Up to 460 square meter home *

OS Support

- Independent from the operating system, works with any

OS including but not limited to Windows, Linux and MacOS

- Configuration Utility: Windows 7/ Vista/ XP (with SP2),

2000 (with SP4)

Package Contents

- 1x SMCHPAV-ESW

- 1x Ethernet Cable (RJ-45)

- 1x Quick Install Guide

- 1x Utility CD

- 1x Warranty Information Card

Dimensions (L*W*H)

-Device : 115 x 42 x 76 mm (4.53 x 1.65 x 2.99 in)

-Package: 220 x 160 x 95 mm (8.66 x 6.30 x 3.74 in)

Weight

- Device : 0.170kg (0.381lb)

Operating Temperature

-0°

C ~ 40°

C (32°

F ~ 104°

Operating Humidity

- 10% ~ 90% Non-condensing

Compliance

-CE,RoHS

-EN 60950-1:2006

- EN 55022:2006

- EN 50412-2-1:2005

Warranty

Please check www.smc.com for the warranty terms in your country.

Features

Contact

North America

20 Mason, Irvine,

CA 92618, U.S.A

1-800-SMC-4YOU

24/7 Technical Support

Europe/Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despi

Barcelona, Spain

Check www.smc.com for your local country contact information

of SMC Networks. Other trademarks or registered trademarks

are the property of their respective owners. Information and

technical features are subject to change without notice. All rights

reserved.

* The actual coverage will vary with the power grid and the

number of PLC terminal device.

* Actual maximum data throughput may vary as network

conditions and environmental factors may reduce the actual

data rate. Some electric appliances such as vacuum cleaners or

microwaves may affect the performance of this product.
