SMART-AVI SWP-T10 Manuel utilisateur

USER MANUAL

(rev 1.0)

Wall Plate Extender

1080p HDBaseT

SWP-T10

Extends VGA, stereo audio, HDMI, IR and RS232

signals with CAT5e/6 up to 70 meters.

WHAT’S IN THE BOX

PART NO. QTY DESCRIPTION

SWP-T10 1 HDBaseT Wall Plate Transmitter

PS12V1.25A 1 Power Supply

1 SWP-T10 Quick Start Guide

CONNECTING THE HDX-WPRO



1.InstalltheSWP‐T10transmitterandplacetheSmartAVIHDXRXreceiver

unitincloseproximitytotheoutputdevice.

2.ConnectaCat5e/6cablebetweentheTXandRXunits(upto70m).

3.ConnectasignalsourcetotheSWP‐T10viaHDMI,VGA,StereoAudio,

RS232orIRconnectors.

4.ConnecttheHDXRXunittothedesiredoutputdevice.

5.Connecta12VpowersupplytoeithertheSWP‐T10ortheHDXRXunit.

TheotherdevicewillbepoweredviaPOE(PoweroverEthernet).

6.UsetheTXfrontpanelSELECTSOURCEbuttontoswitchbetweensource

signals.Usingautomaticselectionwillselectthelastsourceconnected.



Optional:

1. ConnectanRS232cablebetweenSWP‐T10andapersonalcomputerand

aRS232cablefromtheHDXRXunittoanyRS232devicetoremotely

communicatewithorcontrolyourRS232device.

2. ToextendIRremotecontrolfromtheSWP‐T10totheHDXRXunit,con‐

nectanIRreceivertotheSWP‐T10andanIREmittertotheHDXRXfor

infraredremotecontrolupto20m

SWP-T10

SWP-T10 FRONT

SWP-T10 BACK

SWP-T10 3

TECHNICAL SPECIFICATIONS

PORTS

Input ports 1 x HDMI, Type A 19-pin, female; 1 x VGA HD-15, female;

1 x AUDIO IN(Stereo);1 x IR IN; 1 x RS-232 3p captive

screw connector; 1 x 2p captive screw connector

Output ports 1 x IR OUT; 1 x RJ45 (HDBaseT); 1x RS-232 3p captive

screw connector;

VIDEO

Max Data Rate 6.75Gbps

Maximum Pixel

Clock

225MHz

Resolutions Up to 1920x1200 or 1080P@60Hz

Compliance with

HDMI standard

Supports HDMI 1.4 and HDCP1.2

AUDIO

Frequency

Response

20Hz ~ 20KHz

Stereo Channel

Separation

>75dB@20Hz ~ 20KHz

Bandwidth 20Hz ~ 25KHz

OTHER

Power Input 12V DC or 24V DC, 1.25A

Power

Consumption

undetermined

Dimensions(W x D

x H)

4.6” x 4.6” x 1.45”

Weight 0.75lbs

Operating

Temperature

0° to +40°C (32° to 104°F)

Storage

Temperature

-20˚C ~ 60˚C / -4 ˚F ~ 140 ˚F

Humidity 10% ~ 90%

ESD Protection Human body model:

±8kV (air-gap discharge)

±4kV (contact discharge)

SWP-T10

METHODS TO CONTROL SWP-T10

Front Panel Button

The Select/Auto button selects an input source. If you press and hold the

button, the SWP-T10 will enter the automatic switching mode and the Auto-

Switch LED lights up. If you press and hold the button again, the SWP-T10

will exit the automatic switching mode.

RS-232 External Protocol (PC User)

Supports bi-directional RS-232 pass-through control.

This protocol is for communication between PC user and board. The fol-

lowing settings should be used: 9600 baud rate, 8 data

bits, no parity bits, 1 stop bit, and no flow control.

Table 1: Command Protocol

Switch to HDMI Changes the source to HDMI //HD<CR><LF>

Switch to VGA Changes the source to VGA //VG<CR><LF>

Auto ON Enable auto-switching by detecting hot plug. //AE<CR><LF>

Auto OFF Disable auto-switching by detecting hot plug. //AD<CR><LF>

RES 1 Select Change the resolution to 1920 x 1200. //R1<CR><LF>

RES 2 Select Change the resolution to 1920 x 1080. //R2<CR><LF>

RES 3 Select Change the resolution to 1360 x 768. //R3<CR><LF>

RES 4 Select Change the resolution to 1280 x 720. //R4<CR><LF>

RES 5 Select Change the resolution to 1024 x 768. //R5<CR><LF>

SW Update Software update for MSTAR chip. //SU<CR><LF>

Reset to Default Reset to factory defaults //RD<CR><LF>

Table 2: Query Protocol

Version Checks current version of MSTAR software. //V?<CR><LF>

Version Vx.x.x

CHK RES Checks the current resolution. //R?<CR><LF>

Resolution: xx

CHK SRC Checks the current source. //S?<CR><LF>

Input: xx

SWP-T10 5

IR Function

Control devices like HDTVs, BluRay players, and more with

IR Cable Pin Assignment

IR Receiver (RX)

IR Emitter (TX)

SWP-T10

Notes:

SWP-T10 7

Many industry-leading companies have recognized the innovation and power of SmartAVI’s technologies

and have successfully implemented them within their systems. Users of SmartAVI technology include:

800.AVI.2131

Tel: (818) 503-6200 Fax: (818) 503-6208

11651 Vanowen St. North Hollywood, CA 91605

SmartAVI.com

NOTICE

The information contained in this document is subject to

change without notice. SmartAVI makes no warranty of any

kind with regard to this material, including but not limited to,

implied warranties of merchantability and fitness for

particular purpose.

SmartAVI will not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance or use of this material.

No part of this document may be photocopied, reproduced,

or translated into another language without prior written

consent from SmartAVI Technologies, Inc.

Designed and Manufactured in the USA
