Slime 40028 Manuel utilisateur

PART #40028

ALL-PURPOSE INFLATOR

CORDLESS AND RECHARGEABLE FOR RAFTS AND TIRES

ATTENTION! READ ALL INSTRUCTIONS CAREFULLY

FAILURE TO FOLLOW WARNING INSTRUCTIONS CAN RESULT IN FIRE,

PERSONAL INJURY OR PROPERTY DAMAGE.

RECHARGEABLERECHARGEABLERECHARGEABLE

CAUTION: HOT • DO NOT HOLD IN HAND WHILE OPERATING. PLACE INFLATOR ON

A HARD, CLEAN SURFACE

1. DO NOT use inflator continuously for more than 10 minutes. Allow unit to cool

approximately 25 minutes between uses. Do not leave inflator unattended.

2. DO NOT run vehicle while inflator is operating. Engine must be turned OFF.

3. DO NOT operate the inflator with a beverage in the cup holder.

4. ALWAYS use a pressure gauge to check actual tire pressure. DO NOT OVERINFLATE!

5. Keep inflator out of reach of children.

6. For use with 12-volt DC power outlets rated 15 amps or higher. Do not use with older 8

amp cigarette lighter receptacles.

TECH SPECS

IDEAL USES RAFTS, INFLATABLES, TIRES, MATTRESSES

TIRE INFLATION TIME 6 MIN*

MATTRESS INFLATION TIME 1 MIN**

CFM 1.0 (28 LPM)

HIGH PRESSURE AIR HOSE LENGTH 24” (60cm)

POWER SOURCE 1 12 VOLT ACCESSORY OUTLET ADAPTER

POWER SOURCE 2 120 VOLT WALL ADAPTER (RECHARGE ONLY)

POWER SOURCE 3 12 VOLT RECHARGEABLE BATTTERY (OPERATE ONLY)

GAUGE DIGITAL GAUGE WITH INFLATE-RIGHT™

LIGHT LONG-LASTING LED

* (0-35 Psi, Standard Tire-P195/65 R15) ** Twin air mattress

Ball Raft Raft Raft &

Mattress

Raft &

Mattress

Raft &

Mattress

Rubber bumpers

Two built-in cup holders

Carrying handle

Bright LED

light

Protective brushed

aluminum faceplate

On/Off buttons

Light •

High pressure motor •

High volume motor •

Inflate/deflate portals

• For rafts and mattresses

120 volt

wall adapter

12 volt accessory

power adapter

Rubberized feet

• For added stability

High volume air hose

• For inflatables

High pressure air hose

• For tires

Storage compartments

• For air hose and inflatable adapters

Digital gauge with

Inflate-Right™

• Choose & set

pressure

• Inflator stops

when set pressure

is reached

High durability

motor

Built-In

Rechargeable battery

Battery level

indicator

HOW TO INFLATE TIRES:

1. Attach air hose to tire by fully screwing the

connector onto the tire valve.

2. Plug power cord into power accessory outlet or

leave unplugged to run from battery.

NOTE: The unit will not run unless the gauge is

turned on by pressing the “set” button.

3. To set the Inflate-Right™ system, press either arrow

button under the display for 3 seconds until the

target pressure blinks.

4. Use the up and down arrow buttons to reach your

target pressure. The inflator will store this pressure

automatically after a few seconds.

5. To inflate, press the button with the tire symbol.

Once your target pressure is reached, the inflator

will shut off. The inflator can be manually shut off

by pressing the tire symbol button again.

6. Unplug power cord (if necessary) and disconnect

the air hose.

NOTE: Correct tire pressure can be found in vehicle’s

owner manual or driver’s side door jamb.

TO TOGGLE PRESSURE UNITS (PSI/kPa/BAR):

Press the “Set” button at the base of the gauge.

HOLD FOR 3 SECONDS

TARGET PRESSURE

HOW TO USE RAFT PUMP:

The raft air pump is used for inflatables only (more

specifically, high volume/low pressure applications)

and cannot be used for tires and balls which require

higher pressure.

1. Attach raft hose to desired inflation adapter, and

make sure connection is tight.

2. Connect hose to the inlet or outlet on the front of

the inflator. The “+” side is used for inflation

and “–“ for deflation.

3. Press button with the raft symbol to activate the

raft pump. Once desired pressure is reached, turn

power off and remove all connections.

CAUTION:

1. While operating, never block the inflator input or output.

2. Soft inflatables (i.e. rafts, balls, etc.) may not have recommended pressure

markings. Be careful not to inflate items beyond their capacity.

3. Never operate the inflator with a beverage in the cup holder.

BATTERY:

· Your unit has been initially charged. However, it is

always good to top it off prior to use for full

performance.

· Note: It takes 16 hours to fully charge your battery

from the wall (AC outlet).

· Note: It takes 6 hours to fully charge from your car

power outlet (DC outlet).

· The unit should be charged every 4 months to keep

the battery at peak performance.

BATTERY LEVEL INDICATOR

TROUBLESHOOTING:

Inflator fails to operate when plugged in:

1. The fuse, located in the plug adapter, may

have blown.

2. Unscrew the tip of the plug adapter, remove

fuse and inspect. If necessary, replace fuse

with one of the same amperage.

Inflator does not start or blows fuses:

1. Push the power plug firmly into the receptacle and twist it back and forth (if using DC

adapter plug).

2. Check receptacle and plug terminals for dirt and debris. (Use a non-conductive probe,

not fingers or metal.)

3. Check vehicle’s power outlet fuse. It should be 15 amps minimum.

4. The Inflate-Right™ pressure may be set below the desired pressure. Reset.

Inflator runs but does not inflate:

1. Be sure the connector is fully threaded on the tire valve.

2. Check tire for leaks, and check hose for breaks and leaks at fittings.

Inflator runs slowly:

1. Possibly overheated from excessive use. Shut it off and allow to cool for 25 minutes.

2. Voltage may be too low. Check condition of vehicle battery.

NOTE: If tire is totally deflated, it is possible that the tire could separate from the rim

allowing air to leak out when trying to inflate. In the event this situation occurs, you

will have to jack up the tire prior to inflation.

BATTERY DISPOSAL: This product contains a rechargeable sealed lead-acid

battery. The environmental laws in some counties require retailers to accept returns of

rechargeable batteries for proper disposal. Check the county laws before disposing this

product.
