Mounting instructions
EN
SKYLIGHTS
E_MH_Mounting_instructions_Skylux_Electric_screen 01/01/2021
2/9
Safety
Take the necessary and required safety precautions, such as safety nets and lifelines when installing from the
outside, safety goggles, gloves, hard hat, etc.
Do not step on the glass.
Falling from height
• When using ladders to go on the roof:
- Ladder in good condition?
- Set up correctly at an angle of 75°?
- Secured below and on top against moving?
- Don’t take heavy material with you on the ladder (3-point contact rule)! If possible,
use a crane to lift the material.
• Do not lift material over the roof edge; use a crane to put the material on the roof.
• Roof zone: make sure the part of the roof where the skylight/barrel vault will be installed is
safe enough, e.g. secure the edge (support system in the roof gutter that supports against the
outer wall of the building, with suitable A B C category depending on the roof pitch) or use a
scaffold so no one can fall off the roof. If the roof is not safe enough, always use a harness with
lifeline (adapted to the fall height), attached to a suitable attachment point.
•Make sure the roof is stable and does not have dangerous openings or insufficient secure parts
(e.g. corrugated sheets, …). Take the necessary measures if this is not the case: strengthen,
use suitable safety nets below the danger zones, …
• Before making the roof opening for the skylight/barrel vault: make sure there are safety nets
conform to the current legislation. The nets must be attached firmly and sufficiently to the
building.
•When using an aerial work platform: always wear and secure your harness (mandatory)! Leaving
the cage is forbidden.
• Never walk backwards on a roof, always walk forwards.
• Make sure there’s enough light in the working zone.
Low-hanging obstacles and falling loads
• Forbidden to walk under or within a radius of 1 m of a hanging or lifted load.
• Demarcate the danger zone below the skylight/barrel vault, in the building as well as on the
outside near the outer walls (in case material slides off the roof). If the zone is demarcated,
people cannot be hit by any falling loads. It’s prohibited to enter these danger zones during
construction.
Crushing hazard
• All working tools are in good condition, provided with a valid CE label and all necessary safety
regulations. These cannot be removed.
• People who use these working tools are educated for this purpose. Protections are always
present on all working tools. They are in good condition and need to be set correctly.
Tripping/falling
•Safety is key and it begins with order and tidiness. Clean everything immediately, leave nothing
lying around.
• Trash needs to be sorted.
• Be cautious with electric cables (danger of tripping/falling). Never walk backwards!
• Make sure there’s enough light in the working zone.
01/01/2021 3/9
E_MH_Mounting_instructions_Skylux_Electric_screen
Sharp objects
• Make sure your fingers/hands are not pinched and watch out for cuts while handling skylights
or barrel vaults.
• Be careful where you put your hands during the installation.
• Wearing cut-resistant gloves is mandatory.
Ergonomics
• Always lift loads correctly: bend your knees, move your feet instead of forcing your spine, lift
as close to your body as possible.
• Parts of more than 25 kg must be lifted with at least 2 persons.
Connection and charging
• Not suitable for charging appliances.
Personal protective equipment
• Work clothes, safety shoes and helmet are mandatory for everyone.
• Lifeline and harness are mandatory if the edge is not secured enough or if there are no safety nets below the
roof opening. They are also necessary when using an aerial working platform.
• Use gloves when handling skylight or barrel vault parts.
• Safety glasses and hearing protection are mandatory when using saws / grinders.
Always perform a Last Minute Risk Analysis!
If in doubt: STOP! Do not take unnecessary risks. Ask your supervisor if needed.
E_MH_Mounting_instructions_Skylux_Electric_screen 01/01/2021
4/9
Table of contents
SAFETY p. 2
TABLE OF CONTENTS p. 4
OVERVIEW PROFILES AND PARTS p. 4
NECESSARY TOOLS p. 4
DIMENSIONS OF THE INNER SUNBLIND p. 5
INSTALLATION p. 5
PUSH BUTTON p. 9
Overview profiles and parts
Necessary tools
PVC GRP
Ø 9
Ø 5
Ø 9
230 V
#
Inner sunblind 230 V
or
Inner sunblind Solar
77375 Leaf spring
5115 Hilo screw 25 mm PH2
78278 Rivet white 5.6 mm
Ø 5 mm
78179 Roll of tape 2mm
10 m
78328
(optional)
Cuttable covering rubber
for cable 50 m
77433 Bluetooth push button
interface Skylux
78267 Mounting instructions
inner sunblind
Ø 9
(not for Solar)
01/01/2021 5/9
E_MH_Mounting_instructions_Skylux_Electric_screen
Dimensions of the inner sunblind
The size of the inner sunblind depends on the daylight size of the curb.
Daylight size Art. no.
230V
Art. no.
Solar |
** 60 x 60 cm 78081 80785 2 x 2 2 x 2
70 x 70 cm 78083 80786 2 x 2 2 x 2
80 x 80 cm 78085 80787 2 x 2 2 x 2
90 x 90 cm 78088 80788 2 x 2 2 x 2
100 x 100 cm 78081 80789 2 x 3 2 x 3
110 x 110 cm 78090 80790 2 x 3 2 x 3
120 x 120 cm 78094 80791 2 x 3 2 x 3
130 x 130 cm 78095 80792 2 x 3 2 x 3
140 x 140 cm 78096 80793 2 x 3 2 x 3
150 x 150 cm 78097 80794 2 x 3 2 x 3
40 x 70 cm 78098 80795 2 x 2 2 x 2
60 x 90 cm 78080 80796 2 x 2 2 x 2
70 x 100 cm 78082 80797 2 x 2 2 x 2
80 x 130 cm 78084 80798 2 x 2 2 x 2
80 x 180 cm 78086 80799 2 x 2 2 x 2
90 x 120 cm 78087 80800 2 x 2 2 x 2
100 x 130 cm 78089 80801 2 x 3 2 x 3
100 x 150 cm 78092 80802 2 x 3 2 x 3
100 x 200 cm 78093 80803 2 x 3 2 x 3
* 100 x 300 cm 78836 80804 2 x 6 2 x 6
Installation
Remove everything from the packaging.
Do not use a utility knife to prevent any damage.
Fix the clips with the Hilo screws.
Do not screw on the motor side or the hinge side.
The clips are screwed in the helix (if any) on 10 cm from the side;
if there are 3 brackets on one side (see “dimensions inner sunblind”), provide them in the middle.
daylight size
roof opening
helix
+ 1 reserve
PVC curb
GRP curb
* available on request
** not available for Solar
E_MH_Mounting_instructions_Skylux_Electric_screen 01/01/2021
6/9
Exceptions
Do not screw in the polyester curbs.
Use the rivet instead.
If you screw the bracket in the “old” 16/20 PVC curb, it’s best to screw with inclination (+10°).
After screwing the clips, you take the inner sunblind and push it in the opening
Bluetooth logo always on bottom
side
Power cable comes out of the top
side, or the side against the curb
(customer can choose)
(not for Solar)
Pre-drill with ø 5 mm
through the inner wall.
Ø 9
Ø 5
view from below the skylight
hinge side of
curb * moveable screen
1 x 3 m
M
M
M
opening direction
of the screen
M
M
LEGENDE
Screen motor
Bluetooth receiver * in case of an openable model
01/01/2021 7/9
E_MH_Mounting_instructions_Skylux_Electric_screen
Make sure all springs click over the profile.
Remove the wooden lath.
Pull the screen until it’s level.
Please note: for larger dimensions, the folded fabric is still slightly visible on the profile side.
click!
N
S
NW NE
W E
Position of Solar Pack for best eciency:
Install the Solar Pack at least 10 mm from the edge
of the curb.
If not possible, install as high as possible. This aects
the eciency of the Solar Pack, which means that
the Solar Pack sometimes needs to be recharged.
Pull
10 mm
E_MH_Mounting_instructions_Skylux_Electric_screen 01/01/2021
8/9
230V connection
Cable fixation 1 or cable fixation 2 Exception
Important info Solar
ø 9 mm
ø 9 mm
optional
Art.No. 78328
not watertight
!
USB C
do not charge
devices
Not suitable for
charging appliances!
USB C
01/01/2021 9/9
E_MH_Mounting_instructions_Skylux_Electric_screen
Push button
The system is controlled by a wireless module that can be clicked behind the (existing) switch. A bluetooth
technology ensure the connection between the wireless module and the screen (so no extra cables needed
between the switch and screen).
Wiring diagram
Wires are connected to the external push buttons.
We advise to keep the wires long enough so replacment of the battery is possible without disconnecting the push
buttons.
Manual bluetooth module
Please consult the manual for the bluetooth module for more information.
Push button 1
Push button 2
Push button 3
Push button 4
External push buttons
164 19 24 10 45
Bluetooth 4CH push button interface
Push button 1: Black
Push button 2: White
Push button 3: Blue
Push button 4: Orange
Common: Red
Contains CR2450 battery replace only
by same type and rating
red
orange
blue
grey
black
