Sinus Jevi Electric Heating B.V.
Aambeeld 19
1671 NT Medemblik
The Netherlands
tel. +31 (0)227-549 100
INSTALLATION,OPERATIONAND
MAINTENANCE INSTRUCTIONS
TYPE SHK 15
Hot airgun - SHK 15
Page 4 of 12
GB GB
Sinus Jevi Electric Heating B.V.
Aambeeld 19
1671 NT Medemblik
The Netherlands
tel. +31 (0)227-549 100
INSTALLATION,OPERATIONAND
MAINTENANCE INSTRUCTIONS
TYPE SHK 15
Hot airgun - SHK 15
Page 5 of 12
PRECAUTIONS
- Surface of the appliance is hot when in operation.
- Never cover up the appliance when it is in use.
- Always keep the appliance at least 0.5 metres removed from inammable materials.
- Make sure no water can enter the appliance.
- Always use the correct cords and fuses (16A)
- Always remove the plug from the wall socket before carrying out maintenance work on the appliance.
- Repairs and/or alterations are only allowed to be carried out by qualied persons.
- Never insert foreign objects into the appliance. This avoids damage.
- Keep supply cords out of reach of pets.
- Never hose the appliance down.
- Do not use damaged appliances.
- Do not use the appliance in bathrooms or near swimming pools.
OPERATION
Type plate
Check whether the available supply voltage matches with the connecting voltage mentioned on the type plate.
Connection data:
15 kW, fuse minimum 25A, connecting cable 4 x 2.5mm².
Main/selector switch
1. The unit is out of action. After deactivation from a heating position, the fan will keep running for some time.
Therefore, never deactivate the unit by removing the plug from its socket, this is to prevent the maximum thermostat
from cutting out unnecessarily.
2. Fan position
3. Heating position - 7.5 kW
4. Heating position - 15 kW
CAUTION!
In both heating positions the appliance preheats, after a few minutes warm air will be spread.
WARNING!
Do not reach into the exhaust as heating elements can be hot when appliance preheats or cools down with no fan
running.
B. Temperature switch
The temperature sensor is positioned in such a way that the thermostat will control the ambient temperature. The
preset temperature is maintained automatically.
Safe guards
The heater is protected against overheating by an automatic maximum temperature limiter. Should switching of this
limiter occur due to a power cut etc. the heater can be cooled o rapidly by turning the power back on. The fan will
blow cold air over the limiter and the heater will resume its normal function after a while. As an extra safeguard the
heater is tted with a ap which opens as soon as the air current cuts out. This helps the heater to cool o faster as
the internal heat can escape at the back of the unit.
Room thermostat - RTC
At the front of a unit, a thermostat connection with a plug has been provided. If use is made of a room thermostat,
this plug must be taken out and replaced by the plug on the room thermostat. Always make sure that a plug is
present in the connection. Without a plug the heating system will not function.
CAUTION!
Make sure that the RTC-cable cannot be damaged by animals.
WARRANTY CONDITIONS
- The warranty period is 1 year after acceptance by the user.
- The warranty covers the gratuitous replacement of either defective components of the complete
appliance, at the manufacturer’s discretion.
- If a claim is made under warranty, the appliance shall be sent to the dealer carriage paid.
- Repairs under warranty shall only be carried out by the manufacturer or by qualied persons
appointed by him for this purpose.
- Components replaced under warranty shall automatically become the property of the manufacturer.
- Any damage sustained in transit shall be reported to the supplier not later than on the eighth day after arrival of the
appliance on site.
THE WARRANTY BECOMES NULL AND VOID
- If the appliance has been connected to a voltage other than the voltage stated on the type plate,
or if the appliance is used incorrectly or inexpertly.
- If the appliance is repaired or modied by unauthorized third parties. Any expenses incurred by the manufacturer
in rectifying the appliance as a result of such repairs or modications are to be paid by the user.
- If the appliance is damaged through inexpertly and/or careless use. Consequential damage resulting from
such use shall not be claimable from the manufacturer or the supplier
ENVIRONMENT
This symbol on the product(s) and / or accompanying documents means that used electrical and electronic
equipment (WEEE) should not be mixed with general household waste. For proper treatment, recovery
and recycling, please take this product(s) to designated collection points where it will be accepted free of
charge. Alternatively, in some countries, you may be able to return your products to your local retailer
upon purchase of an equivalent new product. Disposing of this product correctly will help save valuable
resources and prevent any potential negative eects on human health and the environment, which could
otherwise arise from inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point. Penalties may be
applicable for incorrect disposal of this waste, in accordance with your national legislation.
412
3
A
10
20
30
B
