PRECAUTIONS
- Never cover up the appliance when it is in use.
- Always keep the appliance at least 0.5 metres removed from inammable materials.
- Make sure no water can enter the appliance.
- Always use the correct cords and fuses.
- Always remove the plug from the wall socket before carrying out maintenance work on the appliance.
- Repairs and/or alterations are only allowed to be carried out by qualied persons.
- Never introduce foreign objects into the appliance. This avoids damage.
- Keep supply cords out of reach of pets.
- Never hose the appliance down.
- Don not use damaged appliances.
- Do not use the appliance in bathrooms or near swimming pools.
OPERATION
Type plate
Check whether the available supply voltage corresponds with the connecting voltage mentioned on the type plate.
Connection data:
10 kW, fuse minimum 20A, connecting cable 4 x 2.5mm².
Main/selector switch
1. The unit is out of action. After deactivation from a heating position, the fan will keep running for some time.
Therefore, never deactivate the unit by removing the plug from its socket, this to prevent the maximum thermostat
from cutting out unnecessarily.
2. Fan position
3. Heating position - 6.6 kW
4. Heating position - 10 kW
412
3
WARNING!
Do not touch the exhaust, also when the fan is not running, as heating elements can be hot when appliance
preheats or cools down.
Safe guards
The heater is guarded against overheating by an automatic maximum temperature limiter. Should switching of this
limiter occur as a result of a power cut etc. the heater can be cooled o rapidly by turning the power back on. The
fan will blow cold air over the limiter and the heater will resume it’s normal function after a short time.
Room thermostat - RTC
At the front of a unit, a thermostat connection with a plug has been provided. When a room thermostat is being
used, this plug must be removed and replaced by the plug on the room thermostat. Always make sure that a plug is
present as without a plug the heating system will not function.
CAUTION!
Make sure that cables cannot be damaged by mechanical forces, such as forklift trucks, sharp objects or animals.
WARRANTY CONDITIONS
- The warranty period is 1 year after acceptance by the user.
- the warranty covers the gratuitous replacement of either defective components of the complete
appliance, at the manufacturer’s discretion.
- If a claim is made under warranty, the appliance shall be sent to the dealer carriage paid.
- Repairs under warranty shall only be carried out by the manufacturer or by qualied persons
appointed by him for this purpose.
- Components replaced under warranty shall automatically become the property of the manufacturer.
- Any damage sustained in transit shall be reported to the supplier not later than on the eighth day after arrival of
the appliance on site.
THE WARRANTY BECOMES NULL AND VOID
- If the appliance has been connected to a voltage other than the voltage stated on the type plate,
or if the appliance is used incorrectly or inexpertly.
- If the appliance is repaired or modied by unauthorized third parties. Any expenses incurred by the manufacturer
in rectifying the appliance as a result of such repairs or modications are payable by the user.
- If the appliance is damaged through inexpertly and/or careless use. Consequential damage resulting from
such use shall not be claimable from the manufacturer or the supplier
ENVIRONMENT
This symbol on the product(s) and / or accompanying documents means that used electrical and electronic
equipment (WEEE) should not be mixed with general household waste. For proper treatment, recovery
and recycling, please take this product(s) to designated collection points where it will be accepted free of
charge. Alternatively, in some countries, you may be able to return your products to your local retailer
upon purchase of an equivalent new product. Disposing of this product correctly will help save valuable
resources and prevent any potential negative eects on human health and the environment, which could
otherwise arise from inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point. Penalties may be
applicable for incorrect disposal of this waste, in accordance with your national legislation.
