Zeus Ultra DMA Solid State Drive

Product Information Datasheet

ii Zeus Ultra DMA Solid State Drives

Export Administration Regulation

This document may contain technical data controlled by the U.S. Export Administration Regulations, and

may be subject to the approval of the U.S. Department of Commerce prior to export. Any export, directly or

indirectly, in contravention of the U.S. Export Administration Regulation is prohibited.

Trademark Information

The SimpleTech name, logo and design are trademarks of SimpleTech, Inc. No right, license, or interest to

such trademarks is granted hereunder, and you agree that no such right, license, or interest shall be asserted

by you with respect to such trademark.

Other product and corporate names mentioned in this document are used for identification purposes only

and may be trademarks or registered trademarks of their respective companies.

Disclaimer of Liability

The performance information and specifications furnished in this document reflect SimpleTech’s

engineering development objectives and should be used for comparative analysis and reference purposes.

The content of this document is accurate as of the date of this publication; however, the information

contained herein, including but not limited to any instructions, descriptions and product specifications, is

subject to change without prior notice.

SIMPLETECH, INC. (SIMPLETECH) PROVIDES NO WARRANTY WITH REGARD TO THIS

DOCUMENT OR ANY OTHER INFORMATION CONTAINED HEREIN AND HEREBY

EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR

FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO ANY OF THE FOREGOING.

SIMPLETECH ASSUMES NO LIABILITY FOR ANY DAMAGES INCURRED DIRECTLY OR

INDIRECTLY FROM ANY TECHNICAL OR TYPOGRAPHICAL ERRORS OR OMMISSIONS

CONTAINED HEREIN. IN NO EVENT SHALL SIMPLETECH BE LIABLE FOR ANY

INCIDENTAL, CONSEQUENTIAL, SPECIAL, OR EXEMPLARY DAMAGES, WHETHER

BASED ON TORT, CONTRACT OR OTHERWISE, ARISING OUT OF OR IN CONNECTION

WITH THIS DOCUMENT OR ANY OTHER INFORMATION CONTAINED HEREIN OR THE

USE THEREOF.

document, including but not limited to any instructions, descriptions and product specifications, is company

private to SimpleTech and shall not be modified, used, copied, reproduced or disclosed in whole or in part,

in any form or by any means, electronic or mechanical, for any purpose, without the written consent of

SimpleTech.

Conventions

The following icons are used throughout this document to identify additional information of

which the reader should be aware.

CAUTION: This icon indicates the existence of a hazard that could result in

equipment or property damage or equipment failure if the safety instruction is

not observed.

NOTE: This icon identifies information that relates to the safe operation of the

equipment or related items.

TIP: This icon identifies helpful hints and tips.

Zeus Ultra DMA Solid State Drives iii

CONTENTS

Contents _______________________________________________________iii

List of Figures __________________________________________________ v

List of Tables ___________________________________________________vi

Product Description______________________________________________ 1

Overview............................................................................................................................................1

Compatibility ..............................................................................................................................2

Compliance and Conformity.......................................................................................................2

Standard Features.............................................................................................................................3

Optional Features ..............................................................................................................................4

Physical Characteristics.....................................................................................................................5

Drive Assembly Exterior Dimensions.........................................................................................5

Drive Assembly Weight..............................................................................................................8

Environmental Characteristics...........................................................................................................8

Temperature, Humidity and Altitude ..........................................................................................8

Shock and Vibration...................................................................................................................9

Electrical Characteristics ...................................................................................................................9

Operating Voltage......................................................................................................................9

Power Consumption.................................................................................................................10

Operation and Performance Characteristics....................................................................................10

ATA (IDE) Bus Modes..............................................................................................................10

Mount Time..............................................................................................................................10

Seek Time................................................................................................................................10

Data Transfer Rate ..................................................................................................................11

Endurance................................................................................................................................11

Reliability..................................................................................................................................11

Functional Description __________________________________________ 13

Confidential:The information inthisdocumentshall notbe used,copied,reproduced,ordisclosed,inwholeorinpart, withoutthe written consentofSimpleTech,Inc.

iv Zeus Ultra DMA Solid State Drives

Zeus SSD Functional Blocks...........................................................................................................13

ATA (IDE) Bus Interface Block................................................................................................13

SSD Control Block...................................................................................................................17

Flash Memory..........................................................................................................................18

Principles of Operation....................................................................................................................19

Operating Modes............................................................................................................................. 20

I/O Primary and Secondary ATA (IDE) Modes........................................................................20

ATA Commands..............................................................................................................................21

ATA Command Flow................................................................................................................21

Standard ATA Commands.......................................................................................................22

Optional ATA Command Support............................................................................................23

Vendor-Specific ATA Commands............................................................................................25

Installation ____________________________________________________27

System Requirements.....................................................................................................................27

Drive Configuration.......................................................................................................................... 27

Configuring 2.5-inch Form Factor Zeus SSD...........................................................................28

Configuring 3.5-inch Form Factor Zeus SSD...........................................................................29

Installing Zeus SSDs....................................................................................................................... 30

Formatting Zeus SSDs for Windows, Linux and Other OS Environments...............................30

Upgrading Zeus SSD Firmware....................................................................................................... 30

Contact and Ordering Information _________________________________31

Contacting SimpleTech................................................................................................................... 31

Ordering Information........................................................................................................................ 31

Acronyms and Abbreviations _____________________________________33

Index _________________________________________________________37

Certification and Warranty _________________________ Inside Back Cover

Zeus Ultra DMA Solid State Drives v

LISTOFFIGURES

1. 2.5-inch Zeus SSD Assembly Drawing...........................................................................6

2. 3.5-inch Zeus SSD Assembly Drawing...........................................................................7

3. 44-pin ATA (IDE) Bus Connector..................................................................................13

4. 40-pin ATA (IDE) Bus/DC Power Combination Connector...........................................14

5. Master/Slave Setting for 2.5-inch Zeus SSDs ..............................................................28

6. Master/Slave Setting for 3.5-inch Zeus SSDs ..............................................................29

vi Zeus Ultra DMA Solid State Drives

LISTOFTABLES

1. 2.5 and 3.5-inch Drive Assembly Dimensions................................................................ 5

2. Environmental Conditions............................................................................................... 8

3. Zeus SSD Typical Power Consumption (watts/mA)..................................................... 10

4. ATA (IDE) Connector Pinout Configuration.................................................................. 14

5. Zeus SSD Capacity...................................................................................................... 18

6. ATA (IDE) Bus Addressing Modes............................................................................... 21

7. Supported ATA Commands..........................................................................................22

8. SSD Identify Drive Information..................................................................................... 23

9. Sanitize Standards Compliance ...................................................................................26

10. ATA (IDE) Cable Requirements ...................................................................................27

Overview Product Description

Zeus Ultra DMA Solid State Drives 1

1 PRODUCTDESCRIPTION

1.1 OVERVIEW

SimpleTech’s Zeus Ultra DMA Solid State Drives (SSDs) incorporate advanced Single-

Level Cell (SLC) NAND flash memory technology to deliver state-of-the-art, non-volatile

mass storage devices. Additional software device drivers are not required. Zeus SSDs

areavailableinboth2.5-inch and3.5-inchformfactors,with standard44and40pin IDE/

ATA interfaces, respectively. Zeus SSDs are fully ATA-5 compliant and conform to the

samemechanical andmounting requirementsas standardrotating drives—makingZeus

SSDs easy-to-install, drop-in replacements for standard IDE/ATA-compliant hard disk

drives (HDDs).

AttheheartoftheZeusSSDistheZeuscontrollerIC—providingtheATAinterfacetothe

host,andtheIDEinterfacetothe drive’slocal flashstoragemedia.TheZeus controller’s

integrated DMA controller interfaces with system memory to facilitate the seamless

transfer of data between the host and the SSD.

Product Description Overview

2Zeus Ultra DMA Solid State Drives

Standard Zeus SSDs are available with unformatted memory capacities ranging from 4

to128GB.Designedtooperateinharshenvironments,ZeusSSDs excelinruggedness,

reliability, compatibility and portability, and are ideal for applications that require high

reliability and high tolerance to shock, vibration, humidity, altitude and temperature. And

since there are no moving parts, Zeus SSDs are completely maintenance-free.

ZeusSSDs canoperate atsustaineddatatransferratesofupto60MBpersecond.With

powerconsumptionkepttoa minimum, Zeus SSDscanbepowered from a single 5volt

source. The drive’s solid state design eliminates electromechanical noise and delay

inherent in traditional magnetic rotating media. Utilizing SimpleTech’s patent-pending

wear-leveling and bad-block mapping algorithms, Zeus SSDs ensure the consistency,

accuracy, and integrity of user data. Superior data reliability is achieved through

embedded error detection and correction code (EDC/ECC). The non-recoverable error

rate of Zeus SSDs is less than 1 error per 1014 bits read.

Zeus SSDs offer powerful user-customizable data sanitization (purge) features.

Supportingbothsanitizederase/fillandnon-recoverablesanitizationoptions,ZeusSSDs

can be configured to remove data from the drive, freeing storage space for later reuse,

or to remove data and destroy the storage media—making the SSD unusable and data

retrieval impossible. The drives’s data security features comply with Department of

Defense (DoD) and US military data security standards, including AFSSI 5020, AR 380-

19, NAVSO P-5239-26, NISPOM DoD 5220.22-M and NSA 130-2.

1.1.1 Compatibility

ZeusSSDscanbeinstalledinanymachinerunninganoperatingsystemsupportingATA

(IDE) bus specification standards.

1.1.2 Compliance and Conformity

The Zeus SSDs comply, in whole or in part, with the following standards:

Commercial AS/NZS3548Class B, BSMICNS13438 ClassB,CAN/CSA-V3/

2001.04(VCCI),CE(Conformite Europenne),CISPR22ClassB,

EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, FCC Part 15

Class B, UL(Underwriter’s Laboratory), NEBS Level 3, IEC

61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC

61000-4-6, IEC61000-4-8, IEC 61000-4-11

Military DoD5220.22-M,MIL-STD-810F,NSA 130-2, AR 380-19,AFSSI

5020, Navso-P5239, NEBSLevel 3

Standard Features Product Description

Zeus Ultra DMA Solid State Drives 3

1.2 STANDARD FEATURES

ATA/IDE Interface

•Conforms to ATA-5 Specification Standard

Performance

•Fast initialization

•Supports PIO modes 0 through 4

•Supports Ultra DMA modes 0 through 4

•Burst read/write performance up to 66 MB/sec

•Sustained read/write performance up to 60 MB/sec

•Field upgradeable firmware

Reliability

•Solid state design

•10-year data retention

•Manual and automatic self-diagnostic tests

•Embedded EDC/ECC (Error Detection and Error Correction)

•SMART (Self-Monitoring, Analysis and Reporting Technology) endurance and

reliability monitoring

•Dependable operation under unstable power conditions

•ATA bus connectors rated for over 10,000 insertions

•Rugged, impact-resistant casing

•7 year warranty

Product Description Optional Features

4Zeus Ultra DMA Solid State Drives

Endurance

•Supports 2,000,000 write/erase cycles

•Supports unlimited read cycles

•Patent-pending wear-leveling algorithms

•Bad-block mapping algorithms

Physical

•2GB to 128GB storage capacities available (unformatted)

•Industry standard 2.5-inch and 3.5-inch HDD form factors

•Compact design — only 9.5 mm thick (all models/capacities)

Environmental

•Meets or exceeds commercial and industrial temperature, humidity and altitude

requirements

•Complies with MIL-STD 810F requirements for shock and vibration

Compliance

•Meets NEBS Level 3 requirements for telco electrical environments

•Meets U.S. Army, Navy, Air Force and DoD security erase and sanitization (purge)

guidelines

1.3 OPTIONALFEATURES

•SMART status monitoring (see “SMART (Self-Monitoring, Analysis and Reporting

Technology)” on page23)

•Sanitization (see “Sanitize Erase/Fill” on page25)

Table des matières

Autres manuels SimpleTech Stockage

SimpleTech

SimpleTech SP-U35/250 Manuel utilisateur

SimpleTech

SimpleTech SimleDrivePS Manuel utilisateur

SimpleTech

SimpleTech SimpleDrive SP-U25/160 Manuel utilisateur

SimpleTech

SimpleTech SimpleShare STI-NAS/160 Manuel utilisateur

SimpleTech

SimpleTech Signature Mini FS-U25/160BB Manuel utilisateur

SimpleTech

SimpleTech SimpleDrivePortable HSD1000 Manuel utilisateur

SimpleTech

SimpleTech Duo Pro Drive FP-UFE2/1.5TB Manuel utilisateur

SimpleTech

SimpleTech NAPSTER Manuel utilisateur

SimpleTech

SimpleTech BONZAI STI-USB2SD/1GB Manuel utilisateur

SimpleTech

SimpleTech Pro Drive PRO1000Q Manuel utilisateur

SimpleTech

SimpleTech BONZAI XPRESS STI-UFDBXA/128 Manuel utilisateur

SimpleTech

SimpleTech SimpleShare STI-NAS/160 Manuel utilisateur

SimpleTech

SimpleTech ZeusIOPS Manuel utilisateur

SimpleTech

SimpleTech USB FLASH DRIVE Manuel utilisateur

SimpleTech

SimpleTech SimpleDrive SP-U25/120 Manuel utilisateur

SimpleTech

SimpleTech Pro Drive FP-UFE/1TB Manuel utilisateur

SimpleTech

SimpleTech STI-105HD Manuel utilisateur

SimpleTech

SimpleTech DELUXE Manuel utilisateur

SimpleTech

SimpleTech SIMPLEDRIVE MINI GTW-USB10/4 Manuel utilisateur

SimpleTech

SimpleTech Signature Mini FS-U25/500E Manuel utilisateur

SimpleTech

SimpleTech STI-U2F36/160 Manuel utilisateur

SimpleTech

SimpleTech Pro Drive PRO1000Q Manuel utilisateur

SimpleTech

SimpleTech NAPSTER Manuel utilisateur

SimpleTech

SimpleTech SimpleDrive Deluxe Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
