SmartCD Programming Device

State of : Dezember 2007

SmartCD Programming Device

Content

1.0 Safety notes _________________________________________3

2.0 Introduction _________________________________________3

3.0 Connecting to a PC/laptop _____________________________4

3.1 Charging the batteries ____________________________________ 4

4.0 Configuring the Bluetooth connection____________________5

4.1 First-time installation _____________________________________ 5

4.2 Changing the connection__________________________________ 5

5.0 Configuring the USB connection ________________________5

6.0 Start-up _____________________________________________6

7.0 Programming with the SmartCD . . . ______________________6

7.1 . . . in connection with a PC/laptop __________________________ 6

7.2 . . . in connection with a PDA_______________________________ 6

8.0 Antenna orientation ___________________________________7

9.0 Replacement of the batteries ___________________________8

10.0 Meaning of LED’s _____________________________________9

11.0 Items supplied _______________________________________9

12.0 Specifications_______________________________________10

SmartCD Programming Device

Page 3

1.0 Safety notes

•Avoid exposure to direct sunlight.

•Keep unit away from sources of magnetic interference.

•Make sure the unit does not drop onto the floor or receive severe shocks of any

kind.

•If misused, the lithium batteries installed in the programming unit can pose a risk

of fire or burning. Do not open, burn or heat to over 70°C.

•Replace the batteries only with storage batteries approved by SimonsVoss

(currently BMZ Li-Ion manganese type US14500V).

•The integrated batteries must be charged for at least 3 hours before first use.

•Dispose of exhausted or non-functioning batteries without delay in accordance

with applicable regulations far away from children’s reach.

•Faultless programming in conjunction with a Windows Mobile 5.x PDA can only be

guaranteed with units approved by SimonsVoss.

•The manufacturer reserves the right to make technical amendments at any time.

•In cases of dispute, the original German manual shall take precedence.

2.0 Introduction

The SmartCD is a programming unit specially designed to be used with a PC/laptop

or a Windows Mobile 5.x PDA (Personal Digital Assistant). It allows you to program

and retrieve all digital components in the SimonsVoss 3060 system very easily. You

can also compare personal data (such as addresses, calendars, etc.) with the PDA.

SmartCD Programming Device

Page 4

3.0 Connecting to a PC/laptop

Using the cable supplied, you can connect the SmartCD directly to a PC or laptop via

a free USB interface.

All digital components in the SimonsVoss 3060 system can be programmed using a

PC/laptop and a SmartCD.

Note: When carrying out programming with a PDA and SmartCD, you must remove

the connecting cable from the SmartCD to the PC/laptop. Bluetooth communication

between the SmartCD and the PC/laptop is not possible.

Please note: Before connecting the SmartCD to the USB port, ensure that the

Bluetooth port is not active. The Bluetooth function will switch off automatically after

approx. 15 minutes. It can also be manually deactivated by pressing the button on the

programming device. Otherwise communication via the USB port will not be possible.

Transponders can only be programmed when the SmartCD is directly connected to a

PC/laptop (by USB cable) and the software program Locking Data Base (LDB) 1.50

or higher or Locking System Management (LSM) 2.2 or higher is installed.

3.1 Charging the batteries

To charge the installed batteries, connect the SmartCD to the PC/laptop using the

USB cable. The batteries in the SmartCD are then charged via the USB interface.

Note: The integrated batteries must be charged for at least 3 hours before first use.

Note: In the case of laptops, the USB interface may be deactivated when the laptop is

switched off.

Tip: If you do not intend to use the SmartCD for a long period, connect the SmartCD

to the USB interface. This will prevent the batteries from running down, and the unit

may be used at any time.

Using several devices via a passive external USB hub (without its own power supply)

can be problematic. This is because the USB interface cannot supply sufficient

power. For this reason, connect the SmartCD directly to a free USB interface on the

PC/laptop for charging or use an active USB hub (with its own power supply).

SmartCD Programming Device

Page 5

4.0 Configuring the Bluetooth connection

4.1 First-time installation

When coupling the SmartCD and the PDA, ensure that both units are:

•switched on and can be recognised by Bluetooth.

•placed close to one another.

Please refer to the ‘SmartLSM’ software manual (and the user manual of the PDA

manufacturer as necessary) for more information on coupling the SmartCD and PDA.

Select ‘SV [serial number of your unit]’ as the SimonsVoss unit.

When coupling the PDA and SmartCD for the first time, it is important that the

reception range does not contain several different SmartCDs with activated Bluetooth.

4.2 Changing the connection

It is possible to change the established Bluetooth connection at any time (in order to

perform programming with another SmartCD, for example).

Please refer to the ‘SmartLSM’ software manual for details of the procedure.

5.0 Configuring the USB connection

When you connect the SmartCD to the PC/laptop using a USB cable for the first time,

the Windows operating system will detect new USB hardware. Following the

instructions in the installation menu, install the driver contained on the supplied CD

onto your desktop computer (selecting the directory ‘SmartCD_USB’).

If you are working with LDB 1.40a or earlier (or LSM 2.1 or earlier), please note that

the new hardware will be installed onto one of the COM interfaces 1-4.

SmartCD Programming Device

Page 6

6.0 Start-up

The installed batteries are pre-charged. The unit is therefore ready for immediate use.

(Before using the SmartCD for this first time, we recommend charging the unit on a

USB port for around 3-4 hours.) To use the programming unit, please perform the

following steps:

•Connect the SmartCD to the PC/laptop via USB.

•Install the USB driver for the SmartCD onto the PC/laptop (see supplied CD).

To use the SmartCD with a PDA, perform the following steps in addition:

•Install the SmartLSM locking plan software on the PDA via ActiveSync.

•Couple the SmartCD and PDA using Bluetooth (performed through SmartLSM).

•Set the COM port on the PDA for the SmartCD (performed through SmartLSM)

7.0 Programming with the SmartCD . . .

When programming, note that the minimum distance between the SmartCD and the

lock should be 10 cm (30 cm to a Smart Relay and 70 cm to a block lock).

7.1 . . . in connection with a PC/laptop

The latest version of the Locking Data Base (LDB) 1.50a or later, or locking-system-

management (LSM) 2.2 or later) software must be installed on the PC/laptop. A

programming unit must be connected to the PC/laptop for new installations or

software updates.

Note: You will need administrator rights to install the software on Windows

NT/2000/XP.

Always carry out a backup before performing an update.

7.2 . . . in connection with a PDA

The latest version of LDB must be installed on the PC/laptop. The PDA desktop

software must also be set up on the PC/laptop. You must carry out an ActiveSync

when installing on the PDA for the first time.

The latest version of SmartLSM must be installed on the PDA using ActiveSync.

You can now transfer a locking plan compiled on the PC/laptop to the PDA by means

of ActiveSync. For more details, please refer to the PDA user manual.

SmartCD Programming Device

Page 7

8.0 Antenna orientation

The antenna orientation for selected components is shown below to guarantee

faultless programming. To ensure the largest possible range when programming, the

antennas of the SmartCD and the lock should be aligned parallel to one another.

To prevent over-modulation, however, the distance between the antennas should

always be at least 10 cm.

All antennas are aligned parallel to one another in this example.

Antenna

SmartCD Cylinder Smart Relay

SmartCD Programming Device

Page 8

9.0 Replacement of the batteries

Please proceed as follows when you need to change the batteries:

•Remove the belt clip carefully (if you use a small Phillips screwdriver, you do not

need to remove the belt clip).

•Remove the screw on the back of the unit.

•Detach the bottom half of the housing.

•Take out the old batteries and insert the new batteries with the positive pole

pointing upwards as shown in the diagram. Observe correct polarity and make

sure you are using the correct battery type.

•Replace the bottom half of the housing and fasten the screw finger-tight.

•Attach the belt clip.

Antenna

+ +

- -

Batteries

SmartCD Programming Device

Page 9

10.0 Meaning of LED’s

First LED (green) on ÆUnit ready for operation

First LED (green) flashing ÆStandby

Second LED (yellow) on ÆBatteries are charging

Second LED (yellow) off ÆBatteries are charged

Third LED (green) flashing rapidly ÆUnit is communicating

with a SimonsVoss lock

Third LED (green) flashing slowly ÆNo connection to lock

Fourth LED (blue) on ÆBluetooth active

The first LED (green) lights when the unit is connected via

USB to a PC/laptop, or when the SmartCD is switched on

without a USB connection by pressing the button. To save

energy, you can switch off the unit by pressing the button again.

The second LED (yellow) only lights when the SmartCD is connected to the computer

by USB for charging purposes and at least one of the batteries requires charging.

The third LED (green) only lights when radio communication is established between

the SmartCD and a relevant lock (e.g. for programming, retrieval).

The fourth LED (blue) lights when using the Bluetooth interface; it remains lit for the

duration of the programming, retrieval or reset procedure and goes out again

afterwards.

11.0 Items supplied

SmartCD

Two batteries of type US14500V (installed)

Cable for connecting to a USB interface

CD-ROM containing USB drivers

SimonsVoss LDB software (or SmartLSM for mobile on-site programming) is also

needed to use the SmartCD. These are not supplied; they must be purchased

separately.

Before start-up, please read the PDA manufacturer manual.

SmartCD Programming Device

Page 10

12.0 Specifications

Housing dimensions H x W x D

112 x 63 x 22 mm

Weight (including batteries)

95 g

Housing material

Plastic

Housing colour

Grey

Number of LED’s

Battery type

Li-Ion manganese storage batteries (rechargeable)

Voltage

4.2 V

Manufacturer

BMZ

Type

US14500V

Number of batteries

Protective system

IP20

Working temperature range

–5°C to +40°C

Storage temperature range

–20°C to +60°C

Bluetooth connection

Class 2 transmitting power: 2.5 mW

Profiles supported

SPP Serial Port Profile, serial data transfer

Table des matières

Autres manuels Simons Voss Technologies Verrouillage

Simons Voss Technologies

Simons Voss Technologies PinCode-Tastatur Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies PegaSys 2.1 Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies SI SmartLocker AX Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies LockNode MP Z4 Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies Cylinder AX Z5 LockNode Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies Cylinder AX Modularity Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies SmartLocker AX Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies ALLEGION 3061 Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies SmartLocker AX Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies LockNode Z4 Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies SmartHandle WP Manuel

Simons Voss Technologies

Simons Voss Technologies LockNode Z4 Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies MK.Z4.PL Manuel

Simons Voss Technologies

Simons Voss Technologies WaveNet Lock-Node SH 3062 Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies SmartLocker AX Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies Cylinder AX Z5 LockNode Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies SmartHandle Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies Z4.PL Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies WaveNet LockNode SH AX Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies SmartHandle 3062 Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies SmartLocker AX SmartIntego Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies Cylinder AX Modularity Manuel utilisateur

Simons Voss Technologies

Simons Voss Technologies Smart Handle WP Manuel

Simons Voss Technologies

Simons Voss Technologies ALLEGION 3060 Series Manuel utilisateur

Manuels Verrouillage populaires d'autres marques

Magic

Magic 105 Manuel utilisateur

Gantner

Gantner GAT NET.Lock 7020 System Guide rapide

Wittkopp

Wittkopp Insys 7202 Manuel utilisateur

Dorma

Dorma Studio Classic Manuel utilisateur

Securam

Securam ECSL-601 Manuel utilisateur

Sudhaus

Sudhaus 3003 Manuel utilisateur

Safety 1st

Safety 1st 48517 Manuel utilisateur

Pado

Pado FDS-10 Manuel utilisateur

Esco

Esco systeQ Series Manuel utilisateur

COMPX

COMPX National D8951 Manuel utilisateur

secureo

secureo Key Box Manuel utilisateur

Stock Loks

Stock Loks C8713 Manuel utilisateur

COMPX

COMPX 1T-058 Manuel du propriétaire

Auslock

Auslock T11 Manuel utilisateur

ELCOM

ELCOM 7205 Manuel utilisateur

Stealth SAFES

Stealth SAFES ShadowVault Manuel utilisateur

Knox

Knox KeySecure 5 Manuel utilisateur

Kwikset

Kwikset 48334/01 Manuel utilisateur
