SilverStone AD120-DC Manuel utilisateur

AD120-DC / AD60-DC

120 / 60W DC to DC board and 120 / 60W AC to DC adapter combo kit

Maximum Output of 120W / 60W

120 / 60W DC-DC power board with 120 / 60W 12V efficiency level VIAC-DC Power Adapter & power cord

Mylar insulation design, easy to install

Black wire design

Built-in multiple protection circuitry for maximum protection during operation

SPECIFICATION

Adapter Series

SST-AD60-DC

SST-AD120-DC

60W / 120W WATTS SWITCHING POWER SUPPLY

with AC adapter

1.1 VOLTAGE

1.2 CURRENT

AD60-DC

12Vdc / 6.0A max

AD120-DC

12Vdc / 12.0A max

1.3 POWER EFFICIENCY

90% at full load (LOAD REGULATION TEST TABLE LOAD 1、2)

1.0 INPUT:

MINIMUM NOMINAL MAXIMUM UNITS

11.4 12 12.6 Vdc

A. DC Board

AD60-DC

AD120-DC

＊1 When input voltage 11.4~11.8V regulation +5,-10

﹪

of +12Vdc

output.

＊2 The continuous total output power is 60W max.

•Total combined +12V output load not exceed 5.0A

＊3 Add 0.1uF and 10uF capacitors across output terminal during

ripple & noise test.

＊4 LOAD REGULATION TEST TABLE:

2.0 OUTPUT:

Voltage +5V +3.3V +12V -12V +5Vsb

＊

Max load 7.0A 7.0A 5.0A 0.1A 2.0A

＊

Regulation

+5,-5

﹪﹪

+5,-5

﹪﹪

+5,-5

﹪﹪

+10,-10

﹪﹪

+5,-5

﹪﹪

＊

Ripple&Noise 50mV 50mV 120mV 120mV 50mV

+5V +3.3V +12V -12V +5Vsb

LOAD1 (100

﹪

) 3.49A 3.49A 2.18A 0.04A 0.87A

LOAD2 (50

﹪

) 1.32A 1.32A 1.5A 0.0A 0.2A

LOAD3 1.50A 1.5A 1.0A 0.1A 2.0A

LOAD4 7.0A 2.5A 1.0A 0.1A 0.5A

LOAD5 3.0A 7.0A 1.5A 0.1A 0.5A

LOAD 6 0.0A 0.0A 5.0A 0.0A 0.0A

Voltage +5V +3.3V +12V -12V +5Vsb

＊

Max load 12.0A 12.0A 10.0A 0.15A 3.0A

＊

Regulation +5,-5

﹪

+5,-5

﹪

+5,-5

﹪

+10,-10

﹪

+5,-5

﹪

＊

Ripple&Noise 50mV 50mV 120mV 120mV 50mV

＊1 When input voltage 11.4~11.8V regulation +5,-10

﹪

of +12Vdc

output.

＊2 The continuous total output power is 60W max.

•Total combined +12V output load not exceed 5.0A

＊3 Add 0.1uF and 10uF capacitors across output terminal during

ripple & noise test.

＊4 LOAD REGULATION TEST TABLE:

TTL High/PS-OFF; TTL Low/PS-ON

VIL=0.8Vmax, IIL=-1.6mAmax @Vin=0.4V

VIH=2.0Vmin @Iin=-200uA, VIH=5.25Vmax @open ckt.

2.1 REMOTE ON/OFF

100-500 msec.

2.2 POWER GOOD DELAY

2000 msec max.At Nominal Line Full Load.

2.3 TURN-ON DELAY TIME

+/- 10% max with 20% load change on all outputs are 50% of the rated.

Load slew rated 1.0A/uS and capacitive load as below :

2.4 TRANSIENT OVERSHOOT

+5V +3.3V +12V -12V +5Vsb

LOAD1(100

﹪

) 5.0A 5.0A 5.8A 0.1A 1.5A

LOAD2(20

﹪

) 1.0A 1.0A 1.1A 0.0A 0.5A

LOAD3 12.0A 1.0A 0.1A 0.1A 3.0A

LOAD4 12.0A 2.5A 2.0A 0.1A 1.5A

LOAD5 3.0A 12.0A 5.0A 0.1A 1.0A

LOAD6 0.0A 0.0A 10.0A 0.0A 0.0A

+5V +3.3V +12V -12V +5Vsb

10000uF 10000uF 10000uF 330uF 10000uF

20ms max at full load.

2.5 RISE TIME

Output voltage regulation +10,-10﹪

When OVP or short protection is triggered, the main outputs

will be latched off. The main outputs can be reset by cycling

the DC remote on/off.

2.6 DYNAMIC TEST

+5V output : 28A max.

+3.3V output : 28A max.

+12V output : 10A max.

3.1 OVER CURRENT PROTECTION

AD60-DC

+3.3V output 2.4 Vmax.

+5.0V output 3.7 Vmax.

+12.0V output 9.5 Vmax.

AD120-DC

+3.3V output 2.0 Vmax.

+5.0V output 3.3 Vmax.

+12.0V output 8.5 Vmax.

+3.3V output 4.1 Vmax.

+5.0V output 6.5 Vmax.

+12.0V output 14.4 Vmax.

3.2 UNDER VOLTAGE PROTECTION

3.3 OVER VOLTAGE PROTECTION

All output to GND.

3.4 SHORT PROTECTION

3.0 PROTECTION:

4.1 OPERATING TEMP. 0 °C to +40 °C

4.2 STORAGE TEMP. -20 °C to +70 °C

4.3 OPERATING HUMIDITY 20% to 90%,non-condensing

4.4 STORAGE HUMIDITY 5% to 95%, non-condensing

4.5 OPERATING ALTITUDE 0 to 10,000feet

4.6 STORAGE ALTITUDE 0 to 50,000 feet

100K hrs minimum

AD60-DC

DC board dimension: WxLxH=148.5x30x25mm

AD120-DC

DC board dimension: WxLxH=160x45x25mm

5.0 MTBF at 25°C(demonstrated)

6.0 DIMENSIONS

4.0 ENVIRONMENT:

60W

The total output power, under steady state conditions, shall not

exceed 60 W.

2.0 Output requirement

Output power

Output voltage and current

Table 2 - Output Voltage and Current

Under any combination of line and load variation and

environmental conditions, all outputs shall remain within

tolerance as defined in Table 2. Output voltage(s) shall be

measured at the load side of output connector.

Output

Voltage

Voltage Range Current Range

Lower

Limit Upper

Limit Minimum

Load Full rated

load PK Load

+12.0V 11.40V 12.60V 0.0A 5.0A --

Power supply shall operate within specification from 90 to 264Vrms or provide automatic

switching in two ranges. The table below shows common input voltage range.

Maximum steady state input current shall not exceed 1.7 A for any line voltage specified

in Input voltage range define.

1.0 Input voltage range

Input current

B. AC adapter

Input Range Minimum Nominal Maximum Unit

90 100 -240 264 Vac, rms

3.0 Ptotection

The power supply shall provide with over voltage protection such

that under any single component failure.

The power supply provides output over voltage protected in latch

off by zener diode, and no damage to customer device.

60W

The power supply shall be protected when operating any output in

overload condition. The power supply shall be shut down and no

any damage when the over current condition occurs on the output,

and It will be auto-recovered when the failure is removed.

Over voltage protection

Over current protection

120W

Unit total output power, under steady state conditions, shall not

exceed 120 W .

Output power

Under any combination of line and load variation and

environmental conditions, all outputs shall remain within

tolerance defined in Table 2. Output voltage(s) shall be

measured at the load side of output connector.

Output voltage and current

Table 2 - Output Voltage and Current

Output

Voltage

Voltage Range Current Range

Lower

Limit Upper

Limit Minimum

Load

Full

rated

load Peak Load

1 +12V 11.4V 12.6V 0A 10A 13A@10s

(115/230VAC)

Short circuit protection

4.0 AC adapter external dimension

Power supply shall have self-limiting protection to protect against

short circuit or overload conditions. No damage to the supply

shall result from a continuous or intermittent short circuit condition.

60W

Dimension without cable: 116mmX52.4mmX31.3mm

Cable length:1200mm±20mm

120W

Dimension without cable: 168mmX71mmX37.5mm

Cable length:1200mm±20mm

60W

During turn on or turn off, the output overshoot shall not exceed

nominal output voltage by more than 5% , and output shall not

change its polarity with respect to its return line.

120W

During turn on, turn off condition, the output overshoot shall not

exceed nominal voltage by more than 10% , and output shall not

change its polarity with respect to its return line.

120W

Over current protection shall be operated within specify

14.5A (min) ~ 20A (Max) , defined in section 2.3.1 at 100~240Vac

line input or temperature conditions.

Overshoot and undershoot

Table 4 –Over current protection

Output

Voltage

Over current protection Test condition

Lower Limit Upper Limit Input

voltage:100Vac

60Hz or 240Vac

50Hz.

+12.0V 5.80A 9.00A
