Silvercrest Z31370A Manuel utilisateur

WIRELESS DOORBELL

Operation and Safety Notes TRÅDLØS DØRKLOKKE

Betjenings- og sikkerhetshenvisninger

FUNKTÜRKLINGEL

Bedienungs- und Sicherheitshinweise

WIRELESS DOORBELL

IAN 273554

SONNETTE SANS FIL

Instructions d‘utilisation et

consignes de sécurité

DRAADLOZE DEURBEL

Bedienings- en veiligheidsinstructies

GB/IE Operation and Safety Notes Page 5

DK Brugs- og sikkerhedsanvisninger Side 18

FR/BE Instructions d‘utilisation et consignes de sécurité Page 30

NL/BE Bedienings- en veiligheidsinstructies Pagina 44

DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 58

You need

Du skal bruge

Il vous faut

U hebt nodig

Sie benötigen:

Z31370A Z31370B

ø 6mm

910

13 11 12

16 17

GB/IE 5

Introduction

Intended use........................................................................................... Page 6

Technical data........................................................................................ Page 6

Included items ........................................................................................ Page 7

Parts and features.................................................................................. Page 7

Safety.................................................................................................... Page 8

General safety information................................................................... Page 9

Safety instructions for batteries ............................................................ Page 9

Assembly............................................................................................ Pag e 11

Preparing for use

Inserting/replacing the batteries......................................................... Pa g e 11

Operation

Synchronising transmitter/ receiver ..................................................... Page 12

Setting the signal type........................................................................... Page 13

Setting the volume ................................................................................. Page 13

Selecting the chime................................................................................ Page 14

Troubleshooting...................................................................................... Page 14

Cleaning and maintenance............................................... Page 14

Disposal............................................................................................... Page 15

Information

Declaration of conformity..................................................................... Page 16

Warranty............................................................................................ Page 16

Table of contents

GB/IE6

Introduction

Wireless Doorbell

Introduction

Keep these instructions in a safe place. If you pass the product

on to anyone else, please ensure that you also pass on all

the documentation.

Intended use

This product is intended for the wireless transmission of the doorbell

chime. The product is not intended for commercial use.

Technical data

Range: 100m (unobstructed area)

Transmission frequency: 433MHz

Battery types: Receiver: 2 x 1.5V (type AA/LR6),

Transmitter: 1x 3 V (type CR2032)

Receiver: Audible signal volume (at maximum volume

setting): min. 73dB (at a distance of 1 m

from the device)

Transmitter: IP rating: IP44

GB/IE 7

Introduction

Included items

1 Transmitter

1 Receiver

2 Batteries 1.5V , type AA (receiver)

1 Batteries 3V , type CR2032 (transmitter)

4 Screws (for transmitter and for mounting the receiver on a wall)

3 Dowels

5 Exchangeable name plates (for the doorbell)

1 Doorbell cover

1 Operating instructions

Parts and features

Receiver (Figs. A/B):

1Signal indicator

2Synchronisation button

3Volume button

4Melody selection button

5Signal type selector button (optical, acoustic, optical and acoustic

signal)

6Speaker

7Stand

8Hanger

9Battery compartment cover

10 Battery compartment

GB/IE8

Introduction/Safety

Transmitter (Figs. C/D):

11 Signal indicator

12 Name plate

13 Chime button

14 Battery compartment

15 Holder (for wall mounting)

Mounting (Figs. E/ F):

16 Screw

17 Dowel

18 Screw (for transmitter)

Safety

Read all safety information and instructions. Failure

to comply with the safety information and instructions may cause ﬁre

and/ or serious injury.

YOU SHOULD STORE ALL SAFETY INFORMATION AND INSTRUC-

TIONS IN A SAFE PLACE IN CASE YOU NEED TO REFER TO THEM

AGAIN IN THE FUTURE!
