Silver Cross Classic Chassis Manuel utilisateur

Classic Chassis

Instructions

IMPORTANT: KEEP FOR FUTURE REFERENCE

Please read these instructions carefully before using your new pram

Keep them in a safe place so that you may use them in the future

CONTENTS

These instructions are important.

Please read carefully and retain for future reference.

Your Classic chassis is a high quality Silver Cross product. It meets current safety

standards and regular light maintenance will ensure long service.

If somebody unfamiliar is using your Classic chassis always ensure that they read

these instructions carefully so that understand how the chassis works best.

Although these instructions clearly outline the correct use of the Classic chassis they

do not relate to the seat unit. To operate the seat unit you must refer to the separate

instructions packed with your chosen seat unit. Remember, the safety of your child is

your responsibility.

The Classic chassis (SX104) is designed and tested to work with the following

Silver Cross seat units

Sleepover (SX301)

Freeway (SX302)

Preparationforuse............................................4

Usingthebrake..............................................7

Heightadjustablehandle .......................................8

Foldingthechassis............................................9

Openingthechassis..........................................11

Using your Classic chassis with the Ventura car seat. . . . . . . . . . . . . . . . . . . .12

Safetynotes................................................13

Description Page No.

CLASSIC CHASSIS - INSTRUCTIONS

First check that all your parts have been

supplied. Your complete chassis includes:

A. Chassis C. Wheels x 4

B. Basket x 1

Providing everything is present you are

ready to continue.

1. PREPARATION FOR USE

Gently press down on the handle ensuring

both sides click and lock into place.

Open the chassis by sliding the

folding catches (E) towards you.

This disengages the automatic chassis lock

and allows the handle to rise into the upright

position

A B

Header

1. PREPARATION FOR USE (CONT.)

Your Classic chassis has a multi-position

adjustable handle. Press both adjuster buttons

and rotate the handle to the

mid-position.Release buttons to lock

Now attach your wheels by first removing any

axle packing protection. Present the wheels to

the axle and slide into position. Release the

wheel locking clip (F) by pulling gently and

slide the wheel to the stop position. Release

the clip and check that the wheel has firmly

attached. Repeat on all four wheels.

Carefully position the basket within the

chassis frame with the lower end towards the

brake. Push down on each locking clip to

firmly secure in place.

1. PREPARATION FOR USE (CONT.)

Your Classic chassis is now ready for use.

We will now proceed to the

features and folding of your Classic chassis

Your Classic chassis is fitted with hard

wearing EVA tyres for convenience and a

puncture free ride.

Header

2. USING THE BRAKE

To engage the brake simply press down on the brake pedal

where ON is marked.

Always check your brake is fully engaged by

gently rocking your chassis.

To disengage the brake simply press on the pedal

in the OFF position.

Header

3. HEIGHT ADJUSTABLE HANDLE

Your handle has various different positions

and should always lock firmly into place.

To adjust the handle simply press both the

adjuster buttons and rotate to the desired

height. Release buttons to lock.

The handle is fully adjustable to accommodate

users of varying heights

giving added comfort and allowing for

compact storage

Header

4. FOLDING THE CHASSIS

Slide the folding catches (E) towards you until

the locking catches disengage on both sides.

Note: The secondary safety catch will lock at

this stage.

To disengage the secondary safety lock (G),

slightly press down on the handle allowing

the secondary lock (G) to swing freely.

Lift upwards allowing the handle to move

forward, freely.

Rotate the handle until it is parallel to the

wheels and press down on both sides until

you hear a click on both sides.

G G

‘click’

4. FOLDING THE CHASSIS (CONT.)

The wheels are removable by lifting the

wheel

catch (F - see point 5) towards you and

pulling the wheel away from the axle.

For the most compact fold, adjust the handle

and rotate it towards the floor, then lock.

Your Classic chassis has an automatic

locking catch which secures your chassis

for easy transportation and storage

Header

5. OPENING THE CHASSIS

Slide the folding catches (E) towards you to

release the automatic chassis lock

Lift the handle and rotate into the locked

position. Press firmly to ensure both locks

engage

Adjust your handle to the desired height

position.

Your chassis is now ready for use.
