C8051T620/2-DK

C8051T620/2 DEVELOPMENT KIT USER’SGUIDE

1. Kit Contents

The C8051T620 and C8051T622 Development Kits contain the following items:

C8051T62x Motherboard

C8051T62x Emulation Daughter Board with C8051F34A installed

Socket Daughter Board (one of the following):

C8051T620DK: C8051T62x QFN 32-pin

C8051T622DK: C8051T622 QFN 24-pin

Device samples (one of the following):

C8051T620DK: C8051T620-GM (Qty: 10) and C8051T626-B-GM (Qty: 10)

C8051T622DK: C8051T622-GM (Qty: 10)

C8051Txxx Development Kit Quick-Start Guide

Quick Start Guide includes steps to download the following development software and documentation (these

instructions can also be found in this document. See “4. Software Installation” on page 3.):

• Silicon Laboratories Integrated Development Environment (IDE)

• Evaluation version of 8051 development tools (macro assembler, linker, C compiler)

• Source code examples and register definition files

• Documentation

AC-to-DC universal power adapter

Two USB cables

2. About the Daughter Boards

The C8051T620 and C8051T622 Development Kits include an Emulation Daughter Board (EDB) and a QFN

Socket Daughter Board (QFN-DB). The EDB has an installed C8051F34A device, which is a Flash-based device

that can be used for the majority of C8051T62x/32x code development. The QFN-DB is intended to allow both

programming and system-level debugging of C8051T62x/32x devices directly.

A C8051T62x/32x device cannot be erased once it has been programmed; so, it is advisable to use the

C8051F34A for the majority of code development. Refer to “AN368: Differences between the C8051F34A and the

C8051T62x and C8051T32x Device Families” for more details on how the C8051F34A can be used to develop

code for the C8051T62x/32x device families. Application notes can be found on the Silicon Labs web site:

www.silabs.com/appnotes

Not Recommended for New Designs

C8051T620/2-DK

2 Rev. 0.5

3. Hardware Setup

See Figure 1 for a diagram of the hardware configuration.

1. Attach the desired daughter board to the motherboard at connectors P1 and P2.

2. If using the QFN Socket Daughter Board, place the device to be programmed into the socket.

3. Place shorting blocks on J7 and the +3VD-VDD_PWR jumper pair on J6, as shown in Figure 1.

4. Connect the motherboard’s P5 USB connector to a PC running the Silicon Laboratories IDE using the USB

Cable.

5. Connect the ac-to-dc power adapter to connector P3 on the motherboard.

Notes:

1. Use the Reset icon in the IDE to reset the target when connected during a debug session.

2. Remove power from the motherboard and remove the USB cable before removing a daughter board from the

motherboard. Connecting or disconnecting a daughter board when the power adapter or USB cable are connected can

damage the motherboard, the daughter board, or the socketed device.

3. Remove power from the motherboard and remove the USB cable before removing a C8051T62x/32x device from the

socket. Inserting or removing a device from the socket when the power adapter or USB cable are connected can

damage the motherboard, the daughter board, or the socketed device.

4. The above hardware setup instructions configure the development system to be powered through the onboard 3.3 V

regulator. For other power options, see "7.3. Power Supply Headers (J6 and J7)" on page 15.

Figure 1. Hardware Setup (Emulation Daughter Board)

SILICON LABS

www.silabs.com

RESET

J15

USB ACTIVE J5

J14

SW1

J12 J13

DEBUG

PWR

RUN

VDD_PWR

+3VD

VDD_EXT

VDD_DEBUG

VDD_COMM

P1 J2

SW2

USB ACTIVE

LED1

PWR

D10 D11 D12

CP2103 U1

F326

STOP

LED1

J10 P2.2

P0.6

LED2

P2.3

P1.2

SW1

J9 P2.0

P0.1

SW2

P2.1

P1.0

C8051T62x-MB

LED2

VPP

J8 CTS_DEBUG

P1.1 P1.2

RTS_COMM CTS_COMM

RTS_DEBUG

J11 TX_DEBUG

P0.4 P0.5

RX_COMM TX_COMM

RX_DEBUG

J1 AC Adapter

USB Cable

Place shorting blocks on

J7 and J6 as shown.

F34A

VREGIN

VBUS

VDD

SILICON LABS

www.silabs.com

C8051T62x EDB

Not Recommended for New Designs

C8051T620/2-DK

Rev. 0.5 3

4. Software Installation

All the latest software tools and documentation can be downloaded from www.silabs.com/mcudownloads.

The Silicon Labs 8-bit Development Tools download package available on that web page includes the Silicon

Laboratories Integrated Development Environment (IDE), 8051 evaluation toolset, Virtual COM Port drivers for the

CP210x USB to UART Bridge, and additional documentation. Download the package and install the components

by following the on-screen instructions.

4.1. System Requirements

The following are the system requirements necessary to run the debug and programming tools:

Pentium-class host PC running Microsoft Windows 2000 or newer.

One available USB port.

4.2. Development Tools Installation

To install the IDE, utilities, and code examples, perform the following steps:

1. Run the Silicon Labs 8-bit Development Tools installer downloaded from www.silabs.com/mcudownloads.

2. In the screen titled “Select Installation Packages”, the Silicon Labs IDE, 8051 Evaluation Toolset and CP210x

Virtual COM Port drivers will be checked by default. The programs necessary to download and debug on the

MCU are the Silicon Labs IDE and the 8051 Evaluation Toolset. The CP210x Drivers are necessary to use the

UART capabilities of the target board. See “4.3. CP210x USB to UART VCP Driver Installation” for more

information about installing the CP210x drivers. See “5. Software Overview” for an overview of all applicable

software included in the web download.

3. Installers selected in Step 3 will execute in sequence, prompting the user as they install programs,

documentation, and drivers.

4.3. CP210x USB to UART VCP Driver Installation

The C8051T62x Motherboard includes a Silicon Laboratories CP2103 USB-to-UART Bridge Controller. Device

drivers for the CP2103 need to be installed before PC software, such as HyperTerminal, can communicate with the

board over the USB connection. If the “Install CP210x Drivers” option was selected during installation, this will

launch a driver “unpacker” utility.

1. Follow the steps to copy the driver files to the desired location. The default directory is C:\SiLabs\MCU\CP210x.

2. The final window of this installer will provide an option to install the driver on the target system. Select the

“Launch the CP210x VCP Driver Installer” option in that window if you are ready to install the driver. You do not

need to have the motherboard's USB connector plugged into the PC's USB port for this step.

3. If selected, the driver installer will now launch, providing an option to specify the driver installation location. After

pressing the “Install” button, the installer will search your system for copies of previously installed CP210x

Virtual COM Port drivers. It will let you know when your system is up-to-date. The driver files included in this

installation have been certified by Microsoft.

4. If the “Launch the CP210x VCP Driver Installer” option was not selected in Step 3, the installer can be found in

the location specified in Step 2 (by default, C:\SiLabs\MCU\CP210x\Windows). At this location, run

CP210xVCPInstaller.exe.

5. To complete the installation process, connect the included USB cable between the host computer and the

COMM USB connector (P4) on the C8051T62x Motherboard. Windows will automatically finish the driver

installation. Information windows will pop up from the taskbar to show the installation progress.

6. If needed, the driver files can be uninstalled by selecting the “Silicon Laboratories CP210x USB to UART Bridge

(Driver Removal)” option in the “Add or Remove Programs” window.

Not Recommended for New Designs

C8051T620/2-DK

4 Rev. 0.5

5. Software Overview

The following software is necessary to build a project, download code to, and communicate with the target

microcontroller.

8051 Evaluation Toolset

Silicon Labs Integrated Development Environment (IDE)

Other useful software included in the Silicon Labs 8-bit Development Tools package from the Silicon Labs

Downloads web site ( www.silabs.com/mcudownloads) includes:

Configuration Wizard 2

Keil µVision2, µVision3, and µVision4 Drivers

MCU Production Programmer and Flash Programming Utilities

5.1. 8051 Evaluation Toolset

The Silicon Labs IDE has native support for many third-party 8051 toolsets. Included with this kit is an 8051

evaluation assembler, compiler, and linker. For further information on the tools, including limitations, see the

corresponding application note. Application notes can be found on the Silicon Labs web site (http://

www.silabs.com/appnotes). See Table 1 for a list of supported toolsets and associated application notes.

5.2. Silicon Labs IDE

The Silicon Labs IDE integrates a source-code editor, source-level debugger, and in-system programmer. The

following sections discuss how to open an example project in the IDE, build the source code, and download it to the

target device.

5.2.1. Running the T620_Blinky or T622_Blinky example program

The T620_Blinky or T622_Blinky example program blinks an LED on the target board.

1. Open the Silicon Labs IDE from the Start menu.

2. Select ProjectOpen Project to open an existing project.

3. Browse to the C:\SiLabs\MCU\Examples\C8051T620_1_6_7_T320_3\Blinky or SiLabs\MCU\Exam-

ples\C8051T622_3_T326_7\Blinky directory (default) and select the T620_Blinky_C.wsp or

T622_Blinky_C.wsp project file. Click Open.

4. Once the project is open, build the project by clicking on the Build/Make Project button in the toolbar or

selecting ProjectBuild/Make Project from the menu.

Note: After the project has been built the first time, the Build/Make Project command will only build the

files that have been changed since the previous build. To rebuild all files and project dependencies, click

on the Rebuild All button in the toolbar or select ProjectRebuild All from the menu.

5. Before connecting to the target device, several connection options may need to be set. Open the Connec-

tion Options window by selecting OptionsConnection Options... in the IDE menu. First, select the

“USB Debug Adapter” option. Next, the correct “Debug Interface” must be selected. C8051T62x/32x

devices use Silicon Labs “C2” 2-wire debug interface. Once all the selections are made, click the OK but-

ton to close the window.

Table 1. Supported Third Party 8051 Toolsets

Toolset Application Note

Keil “AN104: Integrating Keil 8051 Tools into the Silicon Labs IDE”

Raisonance “AN125: Integrating Raisonance 8051 Tools into the Silicon Labs IDE”

Tasking “AN126: Integrating Tasking 8051 Tools into the Silicon Labs IDE”

HI-TECH “AN140: Integrating Hi-TECH 8051 Tools into the Silicon Labs IDE”

SDCC “AN198: Integrating SDCC 8051 Tools into the Silicon Labs IDE”

IAR “AN236: Integrating IAR 8051 Tools into the Silicon Labs IDE”

Not Recommended for New Designs

C8051T620/2-DK

Rev. 0.5 5

6. Click the Connect button in the toolbar or select DebugConnect from the menu to connect to the

device.

7. Download the project to the target by clicking the Download Code button in the toolbar.

Note: To enable automatic downloading if the program build is successful, select Enable Automatic Con-

nect/Download after Build in the ProjectTarget Build Configuration dialog. If errors occur during the

build process, the IDE will not attempt the download.

8. Click on the Go button (green circle) in the toolbar or by selecting DebugGo from the menu to start run-

ning the firmware. The LED on the target board will start blinking.

5.2.2. Creating a New Project

Use the following steps to create a new project. Once steps 1–5 in this section are complete, continue with Step 3

from Section 5.2.1.

1. Select ProjectNew Project to open a new project and reset all configuration settings to default.

2. Select FileNew File to open an editor window. Create your source file(s) and save the file(s) with a rec-

ognized extension, such as .c, .h, or .asm, to enable color syntax highlighting.

3. Right-click on “New Project” in the Project Window. Select Add files to project. Select files in the file

browser and click Open. Continue adding files until all project files have been added.

4. For each of the files in the Project Window that you want assembled, compiled, and linked into the target

build, right-click on the file name and select Add file to build. Each file will be assembled or compiled as

appropriate (based on file extension) and linked into the build of the absolute object file.

Note: If a project contains a large number of files, the “Group” feature of the IDE can be used to organize.

Right-click on “New Project” in the Project Window. Select Add Groups to project. Add predefined groups

or add customized groups. Right-click on the group name and choose Add file to group. Select files to be

added. Continue adding files until all project files have been added.

5. Save the project when finished with the debug session to preserve the current target build configuration,

editor settings, and the location of all open debug views. To save the project, select ProjectSave Proj-

ect As... from the menu. Create a new name for the project and click on Save.

Not Recommended for New Designs

C8051T620/2-DK

6 Rev. 0.5

5.3. Configuration Wizard 2

Configuration Wizard 2 is a code generation tool for all Silicon Laboratories devices. Code is generated through the

use of dialog boxes for each device peripheral as shown in Figure 2.

Figure 2. Configuration Wizard 2 Utility

The Configuration Wizard utility helps accelerate development by automatically generating initialization source

code to configure and enable the on-chip resources needed by most design projects. In just a few steps, the wizard

creates complete startup code for a specific Silicon Laboratories MCU. The program is configurable to provide the

output in C or assembly language.

For more information, refer to the Configuration Wizard 2 help available under the Help menu in Configuration

Wizard 2 or refer to the Configuration Wizard 2 documentation. Documentation and software are available from the

downloads webpage: www.silabs.com/mcudownloads.

5.4. Keil uVision2, uVision3, and uVision4 Silicon Laboratories Drivers

As an alternative to the Silicon Laboratories IDE, the µVision debug driver allows the Keil µVision2, µVision3, and

µVision4 IDEs to communicate with Silicon Laboratories’ on-chip debug logic. In-system Flash memory

programming integrated into the driver allows for rapid updating of target code. The µVision2, µVision3, and

µVision4 IDEs can be used to start and stop program execution, set breakpoints, check variables, inspect and

modify memory contents, and single-step through programs running on the actual target hardware.

For more information, refer to the µVision driver documentation. The documentation and software are available

from the downloads webpage: www.silabs.com/mcudownloads.

Not Recommended for New Designs

C8051T620/2-DK

Rev. 0.5 7

5.5. Programming Utilities

The Silicon Labs IDE is the primary tool for downloading firmware to the MCU during development. There are two

software programming tools that are intended for use during prototyping or in the field: the MCU Production

Programmer and the Flash Programming Utilities. The MCU Production Programmer is installed with the IDE to the

directory, C:\Silabs\MCU\Utilities\Production Programmer\ (default). The Flash Programming Utilities can be

optionally installed from the web installer, and are installed to C:\Silabs\MCU\Utilities\FLASH Programming\

(default).

5.6. ToolStick Terminal

The onboard debug circuitry provides both an in-system programming and debugging interface and a

communications interface to the target microcontroller's UART. The ToolStick Terminal software can access the

debug hardware's communications path and provides a terminal-like interface on the PC. Note that for concurrent

debugging and UART communications, the CP2103 USB-to-UART bridge is also included onboard.

In addition to the standard terminal functions (Send File, Receive File, Change Baud Rate), two GPIO pins on the

target microcontroller can be controlled using the terminal for either RTS/CTS handshaking or software-

configurable purposes. The ToolStick Terminal software is available on the downloads webpage: www.silabs.com/

mcudownloads.

Not Recommended for New Designs

C8051T620/2-DK

8 Rev. 0.5

6. Example Source Code

Example source code and register definition files are provided by default in the

SiLabs\MCU\Examples\C8051T620_1_6_7_T320_3 or SiLabs\MCU\Examples\C8051T622_3_T326_7 directory

during IDE installation. These files may be used as a template for code development.

6.1. Register Definition Files

compiler_defs.h define all SFR registers and bit-addressable control/status bits. They are installed by default into

the SiLabs\MCU\Examples\C8051T620_1_6_7_T320_3 or SiLabs\MCU\Examples\C8051T622_3_T326_7

directory during IDE installation. The register and bit names are identical to those used in the C8051T620-21-26-

27_T320-3 or C8051T622-23_T326-27 data sheet.

6.2. Blinking LED Example

The example source files T620_Blinky.asm and T620_Blinky.c or T622_Blinky.asm and T622_Blinky.c show

examples of several basic C8051T62x functions. These include disabling the watchdog timer (WDT), configuring

the Port I/O crossbar, configuring a timer for an interrupt routine, initializing the system clock, and configuring a

GPIO port. When compiled/assembled and linked, these programs flash the green LED on the C8051T62x

Motherboard about five times a second using the interrupt handler with a timer.

Not Recommended for New Designs

C8051T620/2-DK

Rev. 0.5 9

7. Development Boards

The C8051T620/2 Development Kit includes a motherboard that interfaces to various daughter boards. The

C8051T62x Emulation Daughter Board contains a C8051F34A device to be used for preliminary software

development. The C8051T620 Socket Daughter Board and C8051T622 Socket Daughter Board allow

programming and evaluation of the actual C8051T62x devices. Numerous input/output (I/O) connections are

provided on the motherboard to facilitate prototyping. Figure 3 shows the C8051T62x Motherboard and indicates

locations for various I/O connectors. Figure 4 shows the factory default shorting block positions. Figures 5, 6, and 7

show the available C8051T62x daughter boards. Figures 8, 9, 10, and 11 show the available C8051T32x daughter

boards.

P1, P2 Daughter board connection

P3 Power connector that accepts input from 7.5 to 15 V dc unregulated power adapter

P4 USB connector for UART to USB communications interface

P5 USB Debug interface connector

J1 Analog I/O terminal block

J2 Port 0 header

J3 Port 1 header

J4 Port 2 header

J5 Port 3 header with access to VDD and GND

J6 Power supply selection header (See "7.3. Power Supply Headers (J6 and J7)" on page 15)

J7 Power supply enable header that connects power source selected on J6 to the board's main

power supply net

J8 Communications interface control signal header

J9 Connects port pins to the switches labeled “SW1” and “SW2”

J10 Connects port pins to the LEDs labeled “LED1” and “LED2”

J11 Communications interface data signal header

J12 Connects potentiometer to the port pin, P2.5

J13 Additional connections to ground

J14 Connects an external VREF from J1 to P0.7

J15 VPP supply connection used when programming EPROM devices

Not Recommended for New Designs

C8051T620/2-DK

10 Rev. 0.5

Figure 3. C8051T62x Motherboard

Figure 4. C8051T62x Motherboard Default Shorting Block Positions

SILICON LABS

www.silabs.com

RESET

J15

USB ACTIVE J5

J14

SW1

J12 J13

DEBUG

PWR

RUN

VDD_PWR

+3VD

VDD_EXT

VDD_DEBUG

VDD_COMM

P1 J2

SW2

USB ACTIVE

LED1

PWR

D10 D11 D12

CP2103 U1

F326

STOP

LED1

J10 P2.2

P0.6

LED2

P2.3

P1.2

SW1

J9 P2.0

P0.1

SW2

P2.1

P1.0

C8051T62x-MB

LED2

VPP

J8 CTS_DEBUG

P1.1 P1.2

RTS_COMM CTS_COMM

RTS_DEBUG

J11 TX_DEBUG

P0.4 P0.5

RX_COMM TX_COMM

RX_DEBUG

SILICON LABS

www.silabs.com

RESET

J15

USB ACTIVE J5

J14

SW1

J12 J13

DEBUG

PWR

RUN

VDD_PWR

+3VD

VDD_EXT

VDD_DEBUG

VDD_COMM

P1 J2

SW2

USB ACTIVE

LED1

PWR

D10 D11 D12

CP2103 U1

F326

STOP

LED1

J10 P2.2

P0.6

LED2

P2.3

P1.2

SW1

J9 P2.0

P0.1

SW2

P2.1

P1.0

C8051T62x-MB

LED2

VPP

J8 CTS_DEBUG

P1.1 P1.2

RTS_COMM CTS_COMM

RTS_DEBUG

J11 TX_DEBUG

P0.4 P0.5

RX_COMM TX_COMM

RX_DEBUG

Not Recommended for New Designs

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Silicon Laboratories Microcontrôleur

Silicon Laboratories

Silicon Laboratories C8051F34 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories CP250 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories Wireless M-Bus-EK Manuel utilisateur

Silicon Laboratories

Silicon Laboratories EFM8BB3-SLSTK2022A Manuel utilisateur

Silicon Laboratories

Silicon Laboratories WF200 Manuel utilisateur

Silicon Laboratories

Silicon Laboratories EFM32 Instructions d'installation et d'utilisation

Silicon Laboratories

Silicon Laboratories UG464 Manuel utilisateur

Silicon Laboratories

Silicon Laboratories C8051F58 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories C8051F33 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories Si106 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories Telegesis ETRX357DVK Manuel utilisateur

Silicon Laboratories

Silicon Laboratories C8051F41 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories EFM32 Mode d’emploi

Silicon Laboratories

Silicon Laboratories C8051F326/7 Manuel utilisateur

Silicon Laboratories

Silicon Laboratories C8051F912 Manuel utilisateur

Silicon Laboratories

Silicon Laboratories C8051F91 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories CP2501DK Manuel utilisateur

Silicon Laboratories

Silicon Laboratories Z-Wave 800 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories C8051F38 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories EM35 Series Manuel utilisateur

Silicon Laboratories

Silicon Laboratories EFM8UB1-SLSTK2000A Manuel utilisateur

Silicon Laboratories

Silicon Laboratories Z-Wave 700 Guide de configuration rapide

Silicon Laboratories

Silicon Laboratories Z-Wave 700 Mode d'emploi

Silicon Laboratories

Silicon Laboratories EFM32JG1 Manuel utilisateur

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur
