SIIG JU-EX0011-S1 Manuel utilisateur
1
Introducing the USB Extender
The USB Extender extends the distance to your USB
device up to 50 meters.
Features and Benefits
•Plug and Play, no driver installation needed
•PoweredthroughtheUSBbus,notadditionalpower
adapter needed
•Extends USB distance up to 50 meters via CAT5
cable
•Transparent to user and software
•USB 1.1 and 2.0 compliant
System Requirements
•An available USB 1.1 or 2.0 port
PackageContents
•USB Extender (1-local, 1-remote)
•USB 2.0 cable (Type A to B, 1.5M)
•Quick Installation Guide
04-0481A
USB Extender
QuickInstallationGuide
2
Layout
Figure 1: USB Extender Layout
•Type B USB port: connects to an available USB port
on your computer
•Type A USB port: plug your USB device into this
port
•RJ-45: plug your your CAT5 cable into this port, up
to 50 meters
Hardware Installation
General instructions for installing the card are provided
below.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer case for a few
seconds.
1. Connect your CAT5 cable to theRJ-45 port of each
extender.
2. Plug the USB cable into the Type B USB port, then
plug the other end into your computer
3. Plug your USB device into the Type A USB port.
Type B USB port
Type A USB port
RJ-45
RJ-45
3
Technical Support and Warranty
QUESTIONS? SIIG’sOnline Support has answers! Simplyvisitour
web site at www.siig.com and click Support. Our online support
database is updated daily with new drivers and solutions. Answers
toyour questionscouldbe justafew clicksaway. Youcan alsosubmit
questions online and a technical support analysts will promptly
respond.
SIIGoffers a2-year manufacturerwarrantywith thisproduct. Please
see our web site for more warranty details. If you encounter any
problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the
product to the store where you purchased from.
B) Ifyour purchasehas passed thestore's return policyperiod, please
follow these steps to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective, an RMA number will be issued.
Step 2: After obtaining an RMA number, ship the product.
•Properly pack the product for shipping. All software, cable(s)
and any other accessories that came with the original package
must be included.
•Clearly write your RMA number on the top of the returned
package. SIIG will refuse to accept any shipping package, and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•You are responsible for the cost of shipping. Ship the product
to the following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
•SIIG will ship the repaired or replaced product via Ground
in the U.S. and International Economy outside of the U.S. at
no cost to the customer.
USBExtenderisatrademarkofSIIG,Inc. SIIGandtheSIIGlogoareregisteredtrademarksofSIIG,Inc.
Other names used in this publication are for identification only and may be trademarks of their
respectivecompanies.
July, 2008 Copyright © 2008 by SIIG, Inc. All rights reserved.
About SIIG, Inc.
Foundedin1985,SIIG,Inc.isaleadingcomputerupgrademanufacturer
of I/O connectivity products, including PCIe, PCI & ISA serial and
parallel ports, USB, Serial ATA & UltraATA controllers, FireWire
(1394a/b),networking,sound cards,andotheraccessories. SIIGis the
premier one-stop source of upgrades.
SIIGproductsoffer comprehensive usermanuals,manyuser-friendly
features, and are backed by an extensive manufacturer warranty.
High-quality control standards are evident by the overall ease of
installation and compatibility of our products, as well as one of the
lowest defective return rates in the industry. SIIG products can be
found in computer retail stores, mail order catalogs, through major
distributors, system integrators, and VARs in the Americas and the
UK, and through e-commerce sites.
PRODUCT NAME
USB Extender
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS
B OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCCCOMPLIANCESTATEMENT:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
