SIGNIFY EA1388 Manuel utilisateur
Reo Turntable Briefcase
AFTER SALES SUPPORT
1300 777 137
Model Number: EA1388
INSTRUCTION MANUAL
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA1388 PRODUCT CODE: 63818 12/2018
02
Welcome
Congratulations on choosing to buy a Signify product.
All products brought to you by Signify are manufactured to the highest standards of performance
and safety, and, as part of our philosophy of customer service and satisfaction, are backed by our
comprehensive 1 Year Warranty and customer technical support line.
This comprehensive instruction manual will provide you with a detailed guide on how to operate your
product and will also assist you in troubleshooting any problems that you may encounter.
If you have any queries regarding the use of this product, please feel free to phone our technical
support line for some friendly advice. If you are experiencing difculties or believe that the product
may have a technical fault, we will assist you in rectifying the issue. We can generally solve most
problems simply and quickly over the phone, so please always phone us rst!
We are sure that you will enjoy using this product and you can expect to gain years of service from
this product when it is used and maintained in the correct manner.
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA1388 PRODUCT CODE: 63818 12/2018
03
Contents
Welcome 02
Warranty Details 04
General Information and Safety Instructions 05
Product Overview 08
Getting Started 11
Instructions 12
Handling Vinyl Records 12
Playing Vinyl Records 12
Playing a USB Drive/Micro SD Card 13
Playback Controls 13
Using the Headphone Output 14
Using the Auxiliary Input 14
Using the RCA Audio Output 15
Replacing the Stylus 16
Frequently Asked Questions 18
Repair and Refurbished Goods or Parts Notice 19
Other Useful Information 20
Cleaning and Maintenance 20
Storage 20
Responsible Disposal 21
Specication Table 21
AFTER SALES SUPPORT
1300 777 137
04
service@unclebills.com.au
MODEL: EA1388 PRODUCT CODE: 63818 12/2018
The product is guaranteed to be free from defects in workmanship and parts for a period of 12
months from the date of purchase. Defects that occur within this warranty period, under normal
use and care, will be repaired, replaced or refunded at our discretion. The benets conferred by this
warranty are in addition to all rights and remedies in respect of the product that the consumer has
under the Competition and Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Retro Turntable Briefcase
Warranty Details
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA1388 PRODUCT CODE: 63818 12/2018
05
RETAIN FOR FUTURE USE
Read this manual thoroughly before rst use, even if you are familiar with this type of product. The
safety precautions enclosed herein reduce the risk of re; electric shock and injury when correctly
adhered to. Please keep this user manual in a safe place along with your purchase receipt, warranty
card and carton for future reference. If applicable, pass these instructions and packaging on to the
next owner of the product. Always follow basic safety precautions and accident prevention measures
when using an electrical product.
1. Read all instructions before using the Turntable Briefcase.
2. Never allow children to play with electrical equipment.
3. Do not use the Turntable Briefcase for anything other than its intended use.
4. Before turning on, ensure the electrical voltage and frequency of the circuit corresponds to those
indicated on the rating label of the power adaptor.
5. Do not allow the Turntable Briefcase, its power adaptor, cord or plug to come into contact with
water or any other liquid.
6. The Turntable Briefcase is not intended to be operated by means of an external timer or any type
of separate remote control system.
7. The use of attachments not recommended or sold by the manufacturer is dangerous and may
cause re, electric shock or injury.
8. This Turntable Briefcase is intended to be used indoors, for household use only. Do not use the
Turntable Briefcase outdoors.
9. Keep the Turntable Briefcase, its power adaptor, cord and plug out of direct sunlight.
10. Do not use an extension cord with this Turntable Briefcase unless completely necessary. If an
extension cord is used please ensure that it has a rating equal or exceeding the rating of the
power adaptor.
11. Do not pull or carry by the power cord, use the cord as a handle, close a door on the cord, or pull
the cord around sharp edges or corners. Keep the cord away from heated surfaces.
12. Do not bend or damage the power cord.
13. Always unplug the Turntable Briefcase when not in use. To disconnect from the power supply,
rst ensure the power switch is turned off, then grip the plug and pull from the power socket.
Never pull by the cord. The power plug must be removed from the power socket before cleaning,
servicing, or maintenance.
14. Unplug the Turntable Briefcase in cases of electrical storms to protect against the possibility of
power surges damaging the Turntable.
15. Never force the plug into an outlet.
General Information and
Safety Instructions
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA1388 PRODUCT CODE: 63818 12/2018
06
16. Ensure that power sockets are not overloaded by operating several electrical products that
exceed the power supply of the socket. Review the rating label of each electrical product being
operated to ensure that they do not exceed the capacity of the power socket. Always turn off and
unplug any electrical product that is not being used.
17. Never operate the Turntable Briefcase with wet hands, submerge under water or spill liquids into
the unit.
18. Always turn the Turntable Briefcase off and disconnect from the power source before cleaning.
Never use liquid cleaners, use a soft dry (or slightly damp) cloth to wipe over.
19. Do not place the Turntable Briefcase near a hot burner (gas or electric), heat sources or open
ames.
20. Improper installation may result in the risk of re, electric shock and/or injury to persons.
21. If the power adaptor or its cord or plug is damaged, do not use the Turntable Briefcase. Please
contact the After Sales Support Line for assistance.
22. Always ensure that the power adaptor and cord are placed in a safe location to ensure that they
cannot be stepped on or cannot pose as a tripping hazard. Do not place any items on or against
the power adaptor and cord.
23. The manufacturer and retailer are not responsible for any eventual damages caused by improper
or faulty use.
24. The Turntable Briefcase and its power adaptor have no user serviceable parts contained within
(with the exception of the stylus). Do not attempt to repair, disassemble or modify the Turntable
Briefcase or its power adaptor.
NOTE: See page 16 for further details on how to replace the stylus.
25. This Turntable Briefcase is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the Turntable Briefcase by a person
responsible for their safety. Children should be supervised to ensure they do not play with the
Turntable Briefcase.
26. Ensure that all packaging and plastic bags that were included in the Turntable Briefcase gift box
are kept out of reach from children to avoid potential danger of suffocation.
27. Do not use the Turntable Briefcase on an unstable surface.
28. The Turntable Briefcase must ONLY be powered by the power adaptor that is supplied with
the product. Do not use any other power adaptor. If you experience difculties with the power
adaptor supplied, please contact the After Sales Support Line for assistance.
29. Be extremely careful when unpacking or relocating the Turntable Briefcase and its power adaptor.
Ensure that the Turntable Briefcase and power adaptor are not dropped, bumped or have
excessive force applied to it. Impacts such as these can damage the product and its internal
components.
General Information and Safety
Instructions (cont.)
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA1388 PRODUCT CODE: 63818 12/2018
07
30. We recommend that, where possible, to avoid moving the unit unnecessarily once placed.
31. For the protection of the Turntable Briefcase, we recommend that it is placed on a protected
surface to prevent any damage.
32. If the Turntable Briefcase has been exposed to strong uctuations in temperature (for example,
after transport), do not switch it on immediately. Moisture and condensation could damage the
equipment. Do not switch on the equipment until it has reached room temperature.
33. The Turntable Briefcase should always be repacked in its original packaging whenever
transporting to prevent any possible damage to the device.
34. Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable.
General Information and Safety
Instructions (cont.)
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA1388 PRODUCT CODE: 63818 12/2018
08
Front View
1. Lock Latch
2. Dust Cover
3. Turntable
4. Speakers
5. Handle
6. Control Panel (for USB drive/Micro SD card playback)
Product Overview
2
6
3
1
4
5
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA1388 PRODUCT CODE: 63818 12/2018
09
Product Overview (cont.)
Turntable
1. Spindle
2. 45 RPM Adaptor
3. Cue Lever
4. Control Panel (for USB drive/Micro SD card
playback)
5. Speed Selection Switch (33, 45, 78 RPM)
6. Headphone Output
7. Auto Stop Switch
8. Power Indicator Light
9. Power/Volume Dial
10. Auxiliary Input
11. Stylus
12. Tone Arm Lock
13. Tone Arm
1
5
6
4
7
8
9
10
11
1213
2 3
AFTER SALES SUPPORT
1300 777 137
service@unclebills.com.au
MODEL: EA1388 PRODUCT CODE: 63818 12/2018
10
Product Overview (cont.)
Front and Rear Control Panels
1. Micro SD Input
2. USB Input
3. Button
4. Button
5. Button
6. RCA Audio Output
7. DC Power Input
Included (not pictured):
1x Power Adaptor, 1x Instruction Manual and 1x Warranty Card.
6
7
1
2
3 4 5
