CSC-1326 Gateway Manual
- 1 -
Chapter 1 Technical Specifications of the Equipment
1. General Information
1.1. Applicability
CSC-1326 *DWHZD\（hereinafter referred to as embedded slave system or system）is
a communication product based upon 32-bit micro processor chip with advanced
embedded operating system and flexible module design. The system is applicable to
1000kV and below electric power plant and substation. It is distributed, quasi real
time system, which can realize secondary equipments’ real time/non real time
operation, configuration and faultinformation collection, transferring and data
analysis functions in station. Forsubstation, system can access and manage intelligent
equipments, which are produced in different manufacturers and of different types
and with different communication protocols. In the meanwhile, it can collect data
from these equipments and process them respectively. Then, on this basis, a unified
data format is formed and these will be sent to the master system to make further data
analysis and processing through data network communication.
Each model of the CSC-1326 series equipments can be configured differently
depending on the requirement of application. Detailed configuring method refers to
section 3.2 Overview functional module of the equipment, and configuration coding
principle refers to the figures and tables in chapter 13. According to the number of
modules and the requirement of practical use, half length case (19/2 inches) and full
length case (19 inches) are optional, represented by “/1” and “/2” in model.
The detailed model, name and applicability included in CSC-1326 series
equipments refer to table 1.
Table 1 CSC-1326 series model, name and applicability
Model Structure Name Applicability
CSC-1326/1 Half length case
CSC-1326/2 Full length case
Embedded
slave
system
Access and manage intelligent equipments,
collect data of them, process these data and
send to the master system
1.2. General Characteristics
The characteristics of the equipment are as follows:
a) Module structure, rear modules, a single equipment supports twelve modules at
most, in other words, except the necessary master module and power module, ten
more modules can be configured. The width of every module is the same, actually
realizing flexible configuration. Every module can be installed in any slot (for
