1: Introduction

The Sierra Wireless EM7355 Embedded Module is an M.2 modem

that provides LTE, DC-HSPA+, HSPA+, HSDPA, HSUPA, WCDMA,

GSM, GPRS, EDGE, CDMA, and GNSS connectivity for notebook,

ultrabook, and tablet computers over several radio frequency bands.

The device also supports 2G/3G roaming.

Accessories

A hardware development kit is available for AirPrime M.2 modules.

The kit contains hardware components for evaluating and developing

with the module, including:

•Development board

•Cables

•Antennas

•Other accessories

For over-the-air LTE testing, ensure that suitable antennas are used.

Required connectors

Table 1-1 describes the connectors used to integrate the EM7355

Embedded Module into your host device.

Table 1-1: Required host-module connectors

Connector type Description

RF cables •Mate with M.2-spec connectors

•Three connector jacks

EDGE (67 pin) •Slot B compatible—Per the M.2 standard (PCI Express NGFF

(M.2) Electromechanical Specification Revision 0.7), a generic

75 pin position EDGE connector on the motherboard uses a

mechanical key to mate with the 67 pin notched module

connector.

•Manufacturers include LOTES (part #APCI0018-P001A01),

Kyocera, JAE, Tyco, and Longwell.

SIM •Industry-standard connector.

Hardware Integration Guide

8 Proprietary and Confidential - Contents subject to change 4112880

Rev 2 Feb.13 Proprietary and Confidential - Contents subject to change 9

2: Power

Power supply

The host provides power to the EM7355 through multiple power and

ground pins. The host must provide safe and continuous power (via

battery or a regulated power supply) at all times; the module does not

have an independent power supply, or protection circuits to guard

against electrical issues.

For detailed pinout and voltage/current requirements of this module,

see the AirPrime EM7355 Product Technical Specification &

Customer Design Guidelines.

Module power states

The module has five power states, as described in Ta b l e 2-1.

Table 2-1: Module power states

State Details

Host is powered

Module is powered

USB interface active

RF enabled

Normal

(Default

state)

•Module is active

•Default state. Occurs when VCC is first applied, Full_Card_Power_Off# is

deasserted (pulled high), and W_DISABLE#1 is deasserted

•Module is capable of placing/receiving calls, or establishing data connections on the

wireless network

•Current consumption is affected by several factors, including:

•Radio band being used

•Transmit power

•Receive gain settings

•Data rate

   

Low power

(‘Airplane

mode’)

•Module is active

•Module enters this state:

•Under host interface control:

·Host issues AT+CFUN=0 ([1] AT Command Set for User Equipment (UE)

(Release 6) (Doc# 3GPP TS 27.007))), or

·Host asserts W_DISABLE#1, after AT!PCOFFEN=0 has been issued.

•Automatically, when critical temperature or voltage trigger limits have been

reached))

   

Hardware Integration Guide

10 Proprietary and Confidential - Contents subject to change 4112880

Sleep •Normal state of module between calls or data connections

•Module cycles between wake (polling the network) and sleep, at network provider-

determined interval.

   

Off •Host keeps module powered off by asserting Full_Card_Power_Off# (signal pulled

low or left floating)

•Module draws minimal current

  

Disconnected •Host power source is disconnected from the module and all voltages associated with

the module are at 0 V.    

Table 2-1: Module power states (Continued)

State Details

Host is powered

Module is powered

USB interface active

RF enabled

Autres manuels pour AirPrime EM7355

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Sierra Wireless Unité de contrôle

Sierra Wireless

Sierra Wireless AirPrime HL8518 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPrime AR7594 Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime SL6087 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPrime WP8548 Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime HL7519 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPrime XS1110 Manuel d'utilisation

Sierra Wireless

Sierra Wireless AirPrime series Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime AR7584 Guide de configuration rapide

Sierra Wireless

Sierra Wireless MC Series Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime EM7690 Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime AR7582-1 Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime EM7565 Guide de configuration rapide

Sierra Wireless

Sierra Wireless MC5720 Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime MC7330 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPrime SL8080 Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime HL77 Series Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPrime WP7504 Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime EM7511 Guide de configuration rapide

Sierra Wireless

Sierra Wireless AirPrime SL808 Series Manuel utilisateur

Sierra Wireless

Sierra Wireless mangOH Green DV4 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPrime XA1110 Manuel utilisateur

Sierra Wireless

Sierra Wireless AirPrime WS Series Manuel d'installation

Sierra Wireless

Sierra Wireless AirPrime WP75 Series Manuel d'installation

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
