Shure Sound Isolating Manuel utilisateur

Sound Isolating™ Earphones

Shure Sound Isolating™ Earphones, built

with balanced armature speakers, deliver

a detailed soundstage free from outside

noise. The powerful and stylish Shure SE

earphones come with a detachable cable,

adapters, a durable carrying case, and in-

terchangeable Sound Isolating sleeves for a

comfortable and personalized fit.

27C21352 (Rev. 1) Printed in China

new drawing.

english

Over the ear in back

Wearing the Earphones

The following are some suggested ways of wearing the earphones.

Wear the cable over the ear and secure it behind the head to help keep the

earphones in place during physical activity.

Tighten the cable and take up slack by raising the cable cinch.

Detachable Cable

You may need to detach the cable from the earphones to attach optional components

or to replace the cable if it becomes damaged. To prevent accidental separation, the

connector has a snug fit. Take special care to prevent damage to the earphone and

connector.

• Do not use pliers or other tools.

• Grasp the connector and the earphone as close as possible to where they join.

• Pull straight apart—do not twist. Cable is a snap fit, not threaded.

Note: If you pull at an angle, the connector will not detach.

• Do not pull on the cable or put any pressure on the earphone nozzle.

• Listen for a click when connecting.

• When reattaching the cable, match the "L" and "R" markings. For clear cables and

earphones, match the color dots (Red=Right, Blue=Left).

Audible click when properly connected

english

Changing Sleeves

Twist and pull to remove the sleeve from the nozzle.

Slide on a new sleeve so that it completely covers

the barb and the nozzle.

Caution: If the barb or any of the nozzle is exposed, the sleeve is not properly installed.

Replace sleeves if they do not tightly grip the nozzle. To ensure proper fit and perfor-

mance, use only sleeves supplied by Shure (unless using custom molded sleeves).

Inserting the Earphones

Insert the earphones so they form

a tight seal. The fit of the earphone

can greatly affect sound quality.

Important: If there seems to

be a lack of low frequency

response (bass), this means

that the earphone sleeve

is not forming a tight seal.

Gently push the earphone

deeper into the ear canal or

try a different sleeve.

Warning: Do not push the earphone sleeve beyond the ear canal opening.

english

Choosing a Sleeve

Select an earphone sleeve that provides the best fit and sound isolation. It

should be easy to insert, fit comfortably, and easy to remove.

Soft Flex Sleeves: In small, medium, and

large sizes. Made from pliable rubber.

Soft Foam Sleeves: Compress the foam

sleeve between your fingers and insert

into the ear canal. Hold in place for about

ten seconds while the foam expands.

Triple-Flange Sleeves: If desired, use

scissors to trim the stem on the sleeve.

Removing the Earphones

Grasp the body of earphone and gently twist to remove.

Note: Do not pull on cable to remove earphone.

english

10 11

Maintenance and Cleaning

Careful maintenance ensures a tight seal between the sleeve and nozzle, im-

proving sound quality and product safety.

• Keep the earphones and sleeves as clean and dry as possible.

• To clean sleeves, remove them from earphones, gently rinse in warm

water and air dry. Foam sleeves require a longer drying time. Inspect for

damage and replace if necessary. Ear sleeves must be completely dry

before reusing.

• Wipe the earphones and sleeves with mild antiseptic to avoid infections.

Do not use alcohol-based disinfectants.

• Do not expose earphones to extreme temperatures.

• Replace sleeves if they do not fit properly.

• Do not attempt to modify this product. Doing so will void the warranty and

could result in personal injury and/or product failure.

Cleaning the Earphone Nozzle

If you notice a change in sound quality, remove the sleeve and check the nozzle of your ear-

phone. If nozzle is blocked, clear obstruction by using wire loop end of cleaning tool.

If no obstruction is found or if sound quality does not improve, replace the sleeve with a new

sleeve.

Cleaning

Tool

Wire Loop

Caution: When cleaning, do not force any object through the earphone nozzle! This

will damage the earphone sound filter.

Warning: The cleaning tool is only to be used to clean the earphones. Any other

use, such as using the tool to clean ears or foam sleeve, could result in injury.

The cable connectors to the earphones may collect debris or other deposits that can

affect audio quality. If this happens, disconnect the cables and clean them using a

dry cotton swab.

english

12 13

Included Accessories

• Fit Kit with assorted sleeves

• Nozzle cleaning tool

• Water resistant, crush proof road case

• Soft zippered carrying pouch

• 60-inch and 46-inch detachable cables

• Airline adapter

• ¼ inch adapter

• Inline attenuator

For optional accessories, visit www.shure.com.

WARNING: This product contains a chemical known to the State of California to cause

cancer and birth defects or other reproductive harm.

Technical Specifications

SE535LTD – Red

Transducer type Triple balanced-armature drivers

Sensitivity (at 1khz) 119 dB SPL/mW

Impedance (at 1kHz) 36 W

Frequency Range 18 Hz - 19.5 kHz

Input connector 3.5mm (1/8 in.) gold-plated stereo plug

Net weight 30 g (1 oz.)

Operational

temperature

-18° C to 57° C (0° F to 135° F)

Storage temperature -29° C to 74° C (-20° F to 165° F)

CERTIFICATION

Eligible to bear CE Marking. Conforms to EMC Directive 2004/108/EC. Meets applicable

tests and performance criteria in European Standard EN55103 (1996) parts 1 and 2, for

residential (E1) and light industrial (E2) environments. The Declaration of Conformity can

be obtained from the address below.

Shure Europe GmbH

Authorized European representative:

Shure Europe GmbH

Headquarters Europe, Middle East & Africa

Department: EMEA Approval

Jakob-Dieffenbacher-Str. 12,

75031 Eppingen, Germany

Phone: +49-7262-92490

Fax: +49-7262-9249114

Email: [email protected]

高遮音性イヤホン

バランスド・アーマチュア型ドライバーを搭

載したShure Sound Isolating™イヤホンは、

周囲のノイズの侵入のない音本来のディテー

ルを再現できます。パワフルでスタイリッ

シュな外観のShure SEイヤホンには、取り

外し式ケーブル、アダプター、耐久性を備え

たキャリングポーチ、及び快適性とフィット

性の高い交換式のサウンド分離イヤパッドが

付属しています。

27C21352 (Rev. 1) Printed in China

new drawing.
