OPERATION MANUAL
MODEL: SHIVA-NRP50
Before plugging in the product, please read this manual
carefully, and strictly follow the initial setup steps as per
instructions. Please keep this manual in a safe place after
reading for future reference.
Designed and Manufactured for Shiva Air Conditioning Limited
Unit 8, Ballymount Cross Business Park, Ballymount Road Lower,
Dublin 24, D24 PYK2, Republic of Ireland
Web: www.shiva.ie Email: info@shiva.ie Tel: +353 14539118
SHIVA-NRP50 Air Purifier
Operation Manual
1 Safety Notice 3
2 Product Introduction 5
Control panel 6
Main screen 6
Vice screen 6
3 Before First Use 7
7
7
8
10
Opening and closing method of the back cover
Placement sites of Air Purifier
Installation of filters
Connecting Wi-Fi to Tablet or Smartphone
Filters and functions 11
4 Cleaning and Maintenance 13
13
13
14
14
Cleaning air purifier
Cleaning air quality sensors
Cleaning pre-filter
Unused for a period / storage
Time for replacement of filters 14
5 Troubleshooting 15
16
16
Ordering parts or accessories
Replacement parts
Warranty and service 16
6 Additional Information 16
16
16
Product Specification
Electrical Diagram
Recycling 16
7 Warranty 17
8 Warranty Card 18
SHIVA-NRP50 Air Purifier
Operation Manual
1 Safety Notice
In order to avoid possible damage to you, or others, or critical damage to the product, please
be sure to pay attention to the following safety precautions:
Don’t touch the power plug or
the device with wet hands.
Before cleaning appliance, please
make sure to have the power off.
Otherwise it may cause electric shock.
It is prohibited to use power below or
beyond the specified value.
Only 220V power allowed.
Do not connect to other devices such as DC
inverters, etc.
Using universal sockets or exceeding the
specified value of the equipment may cause
overheating and increase risk of fire.
Damage to the power line or plug.
Should damage occur to the cable or plug
during the lifetime use of the machine, please
have a qualified technician replace the cord
and/or plug.
Don't bind, tape, or use connectors on the
wires. Using a broken wire increases risk of
electric shock, short circuit, and fire hazard.
Never use the device if you feel the cable is
faulty or the plug is loose.
Prohibit unauthorised repair,
taking apart, or modifying the air
purifier.
It may cause electric shock, failure, or a fire
accident. Use a qualified technician.
Warranty is voided if item is compromised
by unauthorised personnel
Pull The
Plug!
Otherwise air purifier may run suddenly,
causing an accident, or risk an electric shock.
Before starting the air purifier, please
insure all packaging is removed from
the internal filters.
Failure to remove the packaging on filters
prevents airflow through the machine, increasing
risk of critical failure, electric shock, overheating,
or fire.
Also remove packaging from power cord.
Please clean power plug regularly.
Accumulation of dust on the power plug and
moisture can damage the insulation of the
plug part, resulting in increased risk of fire
Pull out the power plug, then wipe with dry
cloth (do not use a wet cloth!).
Remember to pull the power plug if device
will not be in use for a long time.
Do not poke a pen, clip, or other
metals into the outlet or inlets. Do
not block the outlet or inlets.
It may affect the internal parts and cause
electric shock or damage.
Warning
If the machine's power supply cord or plug is damaged upon unboxing, you must contact the distributor /
store you purchased the product from immediately, who will appoint a qualified technician to change it
for you, do not attempt to plug in the product to reduce the risk of any danger.
SHIVA-NRP50 Air Purifier
Operation Manual
Prohibit use of any solvent such
as benzene or thinner to clean
the air purifier, avoid touching
after insecticide spraying.
Otherwise air purifier can rupture and
cause damage, short circuit, cause
To pull out the power plug,
hold the plug, instead of
pulling the cable.
Otherwise it may cause short circuit,
break internal wire, increasing the risk
of electric shock or a fire accident.
electric shock, or fire.
Do not operate in high humid
temperature, damp, or wet
body sites using this air
Do not operate this air purifier
intentionally to remove grease/
fat particles from the air.
The air purifier should not be used for
Do Not Use
in Wet Areas
purifier, such as the bathroom.
Air purifier may build up condensation
prone to leakage, increasing the risk of
electric shock or a fire accident.
ventilation or extraction equipment.
Such as inside a kitchen, this will
drastically reduce the service life of air
purifier and all filters.
Do not use the air purifier
indoors with fumigation type
pesticides. (Bug Killer, etc.)
Chemical residue could accumulate
inside the machine, and then released
from the outlet to harm health.
After using pesticides or aerosols,
please thoroughly ventilate the room,
before using the air purifier.
Do not allow the air purifier
to get wet.
It may cause electric shock and
increase risk of a fire accident due to
short circuit.
Keep Away
From Fire!
Use Shiva
Products
Only
Do not operate around volatile
substances or combustible
materials, such as tobacco or
candles close to the machine.
Keep away from any type of fire!
Otherwise it may cause a fire accident.
Intentionally blowing tobacco smoke at
the machine will give sensors false
readings of the room’s overall
environment.
Do not use aftermarket/counterfeit
products with this machine.
Ensure you source spare parts from
genuine registered Shiva Distributors.
Using counterfeited products will
immediately void warranty.
Counterfeited machines / replacement
products may appear similar in appearance;
however they will not have had the testing
and certification this product has had, and
as such, may cause a danger.
Attention
Attention
Ifany situation below occurs, please
disconnect the power tothe machine:
A switch does not work.
A circuit breaker or fuse burned.
The power cord or plug abnormally hot.
Burning odour, abnormal sound, or
vibration.
Any other anomalies or failure.
Attention
This appliance contains a UV-C emitter.
Do not stare at the UV-C light source.
Unintended use of the appliance or damage to the housing may result in
the escape of dangerous UV-C radiation.
UV-C radiation may, even in little doses, cause harm to the eyes and skin.
Appliances that are obviously damaged must not be operated.
The replacement of the UV-C emitter by the end user is not allowed.
Read the maintenance instructions before opening the appliance.
The appliance must be disconnected from the supply before replacing the
UV-C emitter. A suitably qualified tradesperson should do this task.
Precautions are to be taken when replacing UV-C emitters and starters.
4
SHIVA-NRP50 Air Purifier
Operation Manual
Red (PM2.5 = 150 ~ )
Bad
Control Panel
Air Quality Indicator
Reset
Button
(press for
3 seconds)
Fan
Speed
Main Screen
PM2.5 display icon
VOC display icon
Filter expiry reminder
Temperature and humidity
display value
Auto mode display icon
Silent mode display icon
PM2.5 color display light band
WIFI connection display
(When connecting the light twinkles;
when connected , the light stays on)
Environmental status display value
Temperature and humidity display value
UV light display icon
Fan speed display icon
Anion Ionisation display icon
Photosensitive area
Vice Screen
PM2.5 / VOC display icon
Temperature display value
Humidity display value
Filter Clean/Change Reminder:
According to the actual usage of the filter, the machine
automatically calculates the expiration time of the filter. After the
filter usage time has expired, the filter indicator will flicker,
reminding you to clean/change the filter
Attention
Please turn off the power and pull out the
power plug before replacing any filter.
Blue (PM2.5 = 0 ~ 50)
Perfect
Green (PM2.5 = 50 ~ 100) Good
Purple (PM2.5 = 100 ~ 150) Normal
Countdown
Timer
Anion Ioniser
UV Steriliser
or Both
Power On/Off
Button
Mode: Auto / Manual
(For WiFi Setup: press and hold Mode Button
within 5 secs of turning on device)
6
SHIVA-NRP50 Air Purifier
Operation Manual
3 Before First Use
Placement Sites of Air Purifier
1 Opening Method of the Filter Cover
Gently hold the machine, hold the back cover with one
hand, and gently pull the cover open backwards horizontally.
(as indicated by the arrow direction below)
2 Closing Method of the Filter Cover
Gently hold the machine, confirm the filter order; and gently
close the back cover horizontally (as indicated by the arrow)
In order to maximise your room air circulation, ensure
the gap between the air inlet (filter panel side) and
the wall is at least 50cm, and the air sensors are at
least 10cm away from the wall (as shown below).
Please keep 1 meter away from television, radio, etc.
Please do not put the power plug together with any
television, radio, and other electrical power plug
inserted into the same socket, (otherwise it may cause
screen jitter and electrical noise generation.)
The long-term placement in the same position
may dirty the sites walls and floors. Ensure to
regularly clean and vacuum this area.
To ensure the machine has adequate circulation,
ventilation, and maximum efficiency, don't interfere
with the air outlet or air inlet by blocking them.
Attention
Open the package, take out the foam lining, remove all the
built-in accessories and materials, take Air Purifier out of the
box, remove the plastic bag, open the filter cover, and remove
the plastic from the filters. Re-insert the filters in correct order.
Opening and Closing Method of the Back Cover:
7
SHIVA-NRP50 Air Purifier
Operation Manual
Attention
Please do not touch the UV-C Lamps even when
powered off.
Please do not operate the air purifier without the filters.
Please remove the package of each filter before using.
Tips
You can place the purifier on a table to enhance
the access when removing or installing the filters.
Installation of Filters
Important!
Please remove all the plastic packaging from all
of the filters in the machine before using the air
purifier, according to the below instructions.
Steps
Before using this air purifier, please install the filters
correctly as per instructions.
Please remove all packaging and put the air purifier
on dry, stable, horizontal ground.
1 Using one hand, hold the top of the machine;
and gently pull the filter cover sideways.
(as shown in arrow direction)
2 Remove all the filters from inside the machine.
3 Remove all packaging from each filter.
8
Autres manuels pour SHIVANRP50
1
Table des matières
Autres manuels shiva Purificateur d'air
