Please remove all packaging and put the air cleaner on a dry, stable, horizontal surface.
Before using this air cleaner, please install the filters correctly as per instructions.
!!Important!!
Please remove all the plastic packaging from all of
the filters in the machine before using the air
cleaner, according to the below instructions:
1. Using one hand, hold the top of the machine;
and gently pull the filter cover sideways.
(as shown in arrow direction)
2. Remove all the filters from inside the machine.
3. Remove all packaging from each filter.
4. Install all the NRP50 filters in correct order;
1
st
TiO² Photocatalyst Filter
(Honeycomb Type)
2
nd Activated Carbon Filter
(Black)
3
rd
HEPA13 Filter
(White)
4
th Pre-Filter
(Fine Fabric)
TiO² Carbon HEPA13 Pre-Filter
5. Carefully close the Filter Panel.
Align and insert it into the fixed grooves,
then gently push it closed.
6. Place the air cleaner on a dry, stable,
horizontal surface. Allow min. 50cm of open space
for sufficient airflow at the Filter Panel.
7. Plug in the machine to the power socket and
press the on/off power button to turn on the machine.
Allow 45 minutes for the sensors to calibrate.
8. (Optional) Set the device up for Wi-Fi Control.
Checklist:
1. Have a Smartphone or Tablet with access to the Google Play or Apple App Store
2. Your Smartphone or Tablet to use the device is connected to the same 2.4G WiFi
Internet network you wish to use.
3. (it is recommended the Customer / Building Manager purchase a dedicated device
to leave on site for control of multiple units)
4. You have the correct WiFi Password to hand.
5. Your Router is MAC-open.
1. Register an account.
2. If you already have an account, Log In.
3. Ensure all filter packaging is removed, and power is connected to the Air Cleaner.
4. Enter the App, Tap “+” on the upper right of the page to enter the connection page.
5. There are 2 Connection Methods; ‘Manual’, and ‘Auto Scan’, Select ‘Manual’.
6. Select ‘Small Home Appliances’ from sections, and select ‘Air Purifier (Wi-Fi)’
7. Select the network you wish to use and enter the network password. (Note: WiFi
Network must be 2.4GHz)
8. After entering password select ‘Next’ to enter the pairing connection page.
9. Power on the unit using the On/Off button, then quickly press and hold the ‘MODE’
button for approximately 5 seconds, until the WiFi Light starts blinking fast.
10. Ensure the WiFi Light is still rapidly flashing, and select ‘Confirm the indicator is
blinking rapidly’ and ‘Next’
11. Air Purifier will display as found on the app. Select this device.
12. (Optional) Name your device accordingly
(example: Reception, Open Plan 1, Canteen, Accounts Office, Johns Office, etc)
13. This device is now connected. Repeat steps if you have other devices and name
them accordingly to identify each one.
