Sharp UP-5300 Manuel utilisateur

CODE: 00ZUP5300USME

POS TERMINAL

MODEL UP-5300

("U" & "A" version)

CHAPTER 1. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

CHAPTER 2. OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

CHAPTER 3. SERVICE PRECAUTION . . . . . . . . . . . . . . . . . . . . . 3-1

CHAPTER 4. UP-5300 DIAGNOSTICS SPECIFICATIONS . . . . . . 4-1

CHAPTER 5. CIRCUIT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . 5-1

CHAPTER 6. BIOS SETUP UTILITY . . . . . . . . . . . . . . . . . . . . . . . . 6-1

CHAPTER 7. ABOUT UTILITY SOFTWARE AND OTHERS . . . . . 7-1

CHAPTER 8. CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 8-1

CHAPTER 9. PWB LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

PARTS GUIDE

CONTENTS

SHARP CORPORATION

Parts marked with "!" is important for maintaining the safety of the set. Be sure to replace these parts with specified

ones for maintaining the safety and performance of the set.

This document has been published to be used

for after sales service only.

The contents are subject to change without notice.

BATTERY DISPOSAL

Contains Nickel Metal Hydride Battery. Must be Disposed of Properly.

Contact Local Environmental Officials for Disposal Instructions.

CHAPTER 1. SPECIFICATIONS

1. Appearance

AC cord

Plug your POS terminal into a wall outlet before using.

Power switch

Set the power switch to the ON ( I ) position after plugging your POS

terminal.

2. Rating

ITEM SPECIFICATIONS

External dimensions 11.6 (W) ×16.3 (D) ×12.6 (H) in.

approximately (295 (W) ×414.5 (D) ×

320 (H) mm)

Weight Approximately 13.9 lb. (5.9 kg)

Power source 120V AC ±10%, 60 Hz

Power consumption Operating : 63W

Working temperature

and humidity 32 to 104°F (0 to 40°C)

10 to 90%

3. Hardware

3-1. Display

ITEM SPECIFICATIONS NOTE

Type DSTN color LCD with back

light With 256 colors

Screen size 10.4" Full screen

Dot format 640 (W) ×480 (H) dots

Dot size 0.33 ×0.33 mm

Control VGA

3-2. Keyboard

ITEM SPECIFICATIONS NOTE

Type Touch key

(Analog touch panel)

Number of key

positions 4096 (W) ×4096 (H)

positions

Control Mouse emulation

3-3. PC system

ITEM SPECIFICATIONS NOTE

CPU Pentium processor

Chip set FireStar Plus:

82C700U3.2

Graphic controller VGAC : MN89305

Main memory

(for executing MS-DOS,

Application software)

Standard : 8

Mbytes EDO type

Max. : 40 Mbytes adding S.O.DIMM

Video RAM 1 Mbytes EDO type

BIOS ROM 512 Kbytes Flash ROM

OS (MS-DOS) ROM 4 Mbytes Mask ROM

ROM disk memory

(for stored Application

software)

Standard : 2

Mbytes Flash ROM

Max. : 6 Mbytes adding UP-F04RB

RAM disk memory

(for POS data) Standard : 1

Mbytes PS-RAM

Max. : 3 Mbytes adding UP-P02MB

Keyboard controller M38802M270

Super I/O M5113 A2

POS system controller PSC2 : LZ9AM22

3-4. Serial port

D-SUB 9-pin connector COM1 and COM2 are equipped.

In order to supply +5V power, CI signal and +5V power supply of

COM1 and COM2 can be switched.

2 channels of RJ45 Connector COM port are equipped.

COM3 and COM4 or original I/O address (COM5 and COM6) can be

selected as the 2 channels of RJ45 COM port.

COM1 & COM2: D-sub 9 pin

Pin No. Signal Function I/O

1 CD Data Carrier Detect I

2 RD Receive Data I

3 SD Send Data O

4 ER Data Terminal Ready O

5 SG Signal Ground —

6 DR Data set Ready I

7 RS Request to Send O

8 CS Clear to Send I

9 CI/+5V Ring Indicate / +5V I/–

COM3 or COM5: Modular jack RJ45 8 pin

Pin No. Signal Function I/O

1 RS Request to Send O

2 ER Data terminal Ready I

3 SD Send Data O

4 SG/(+5V) Signal Ground/(+5V) —

5 SG Signal Ground –

6 RD Receive Data I

7 DR Data set Ready I

8 CS Clear to Send I

1 – 1

COM4 or COM6: Modular jack RJ45 8 pin

Pin No. Signal Function I/O

1 RS Request to Send O

2 ER Data terminal Ready I

3 SD Send Data O

4 SG Signal Ground —

5 SG Signal Ground –

6 RD Receive Data I

7 DR Data set Ready I

8 CS Clear to Send I

3-5. Expansion slot

ITEM SPECIFICATIONS NOTE

Type ISA bus Half size PC board

Number of slots 2 slots

Power consumption +5V/max. 1.0A

+12V/max. 0.05A

3-6. Shutdown switch

The shutdown switch is used when the OS or application programs

are straying and the system can not return to the normal state.

You must not use this shutdown switch when the UP-5300 is running

normally. Use this switch only when the main power source is not cut

off even if the main unit power switch is set to OFF position. UP-5300

is turned OFF and the hardware is reset by turning the main power

switch OFF and then pressing the shutdown switch.

[Out line]

The shutdown switch is single shot type. (Normally OFF position)

Push ON: This position is used to reset stand-by mode for power

supply unit when software hang up.

Release OFF: Usually the shutdown switch needs to be set to this

position when the UP-5300 is operated.

[Operating method]

The shutdown switch is a push switch. If it is pushed to ON, the

UP-5300 stops supplying the power when the power switch is set into

stand-by mode.

NOTE: The shutdown operation will be ignored when te power

switch is set into power-on position.

3-7. System switch

The system switches are used to preset various system configura-

tions.

[Out line]

The system switches consists of DIP switches.

[DIP switch]

The PSC2 simply reads the switched signals from the DIP switch as

hardware. The meaning of the switche settings are shown on the next

page.

12345678

Shutdow n sw itch

12345678

stem sw itch

1 – 2

: Default setting

DSW-8

Function OFF

(value=1) ON(value=0)

Serial 3 & 4

decode mode COM3 &

COM4 COM5 &

COM6

DSW-7

Function OFF

(value=1) ON(value=0)

COM3 &

COM4 IRQ

assign

(Serial 3 & 4)

COM3 =

IRQ11

COM4 =

IRQ10

COM3 =

IRQ4

COM4 =

IRQ3

DSW-6

Function OFF

(value=1) ON(value=0)

CMOS

Initialize Not Initialize Initialize

DSW-5

DSW-4

Drive C:, D: & E: Setting

Drive

C: Drive

D: Drive

E: DSW-4 DSW-5

HDD — — ON

(value=0) ON

(value=0)

HDD PS

RAM Flash

ROM ON

(value=0) OFF

(value=1)

RAM Flash

ROM HDD OFF

(value=1) ON

(value=0)

Flash

ROM PS

RAM HDD OFF

(value=1) OFF

(value=1)

DSW-3

Function OFF

(value=1) ON(value=0)

Boot Drive Drive A: Drive C:

DSW-2

Function OFF

(value=1) ON(value=0)

Drive A:

Device Mask ROM FDD

DSW-1

Function OFF

(value=1) ON(value=0)

Floppy Disk

Controller Not Exit Exit

3-8. Power switch

[Out line]

The power switch has the positions ON and OFF (Stand-by)

ON position: Usually the power switch needs to be set to this posi-

tion when the POS-terminal is operated.

OFF position: This position is used to turn the stand-by mode. When

the power switch is set to this position, the power

supply stops automatically. But if the software pro-

gram controls the power supply to hold, even if the

power switch is set into this position, power is supplied

until an software program allows power supply no to

hold.

[Operating method]

The power switch is a see-saw switch, and it can be tipped toward

the ON or OFF.

4. Software

4-1. Software Structure

The basic system software mainly consists of the following 3

modules.

(1) MS-DOS Version 6.22

The operating system (MS-DOS Version 6.22) is stored in a MROM

disk.

(2) Drivers

There are following types of drivers

•POS Device Drivers (for Clerk, Buzzer, Drawer, Timer, MCR, Line

Display, Serial Port) POS device drivers adopt the same control

method as previous (ER-A850/A880/UP-5700) softwares.

•Touch Panel Driver

(3) POS Device Middleware

The middleware has been developed to improve the performance of

applications.

(4) Software Structure

OFF

1234567 8

Power switch :

Application

POS Utillty

POS Device

Mifddle Wsre

MS-DOS Version 6.22

Touch

Panel

Driver POS Devlce Driver

BIOS

Provided from SHARP Corporation

Hardware

Standard PC

Device Driver

(Local production)

SCSI

Ethernet

.......etc

1 – 3

4-2. Basic system software list

ITEM CONTENTS for UP-5300 for PC

BIOS (FROM) •AT compatible system BIOS

F—

•VGA BIOS for MN89305 VGA LSI

•Standard SETUP program

•Flash Disk/MROM Disk/PSRAM Disk built-in control program

•Memory size/HDD type auto detect function

•No APM/PnP support

OS (MROM disk) MS-DOS Version 6.22 (Subset)

Install program (MROM disk) •System Install program

•APL Install program (for MS-DOS/Windows 95/98/NT) — F

POS device driver •POS device driver F—

•Touch panel driver (mouse emulation I/F only) F—

Middleware software and

application development tools •POS device MiddleWare F—

•Printer Logo image loading utility program (MS-DOS/Windows 95) FF

•Touch panel calibration utility program (MS-DOS) F—

... These software are provided with FD from SHARP corporation.

Please copy contents of FD provided from department to development PC. Install to UP-5300 by using APL Install Program from PC.

4-3. Memory map

0000000h

0800000h

1000000h

1800000h

2800000h

STD. 8MB

+8MB

(16MB)

+8MB

(24MB)

+32MB

(40MB)

00000h

9F4000h

A0000h

C0000h

C8000h

E8000h

100000h

MS-DOS

(25K)

Sharp Driver

(32K)

Free

Conventional

(580K)

EBDA : 3K

VRAM

128K

VGA BIOS(32K)

UMB

(124K)

System BIOS

(96k)

HMA

64K

POS Device 20K

Touch Key 12k

(External BIOS

Data Area)

Middleware Not used

00000h

9F4000h

A0000h

C0000h

C8000h

E8000h

100000h

MS-DOS

(25K)

Sharp Driver

(32K)

Free

Conventional

(565K)

EBDA:3K

VRAM

128K

VGA BIOS(32K)

UMB

(124K)

System BIOS

(96k)

HMA

64K

POS Device 20K

Touch Key 12k

(External BIOS

Data Area)

Middleware is used

Middleware

(15K)

Memory is expandable up to

40MB max. using EMM386 in DOS

1 – 4

CHAPTER 2. OPTIONS

1. System configuration

AT Keyboard

Incorporated in Main Unit RS-232 Communication Connection

max.2 (RS-232)

Drawer

ER-03DW/

04W/05DW

(In Europe only)

Customer

Poll Display

UP-P20DP

Additional

RAM Memory

UP-P02MB

Additional

ROM Memory

UP-F04RB

Additional DRAM

Memory

Magnetic

Card Reader

UP-E12MR

HDD Unit

RS232 Board

ER-A8RS

Ethernet Board

In-line Communication

Connection

UP-5300

Centronics Printer

Remote Printer

<Option> ER-01PU

Kitchen video monitor

(For North America only)

CAT/FET

TM-T80/85/295

ER-FBT40

Hand Scanner

ER-A6HS1

UP-5300

Built-in,

customer-side

display

UP-I20DP

(NEW)

Built-in printer

UP-T80BP

(Standard4channels)

(Additional 2 channels)

Host PC

Scale

Coin dispenser

(For North America only)

Drink dispenser

(For Europe only)

2. Options

No. NAME MODEL NAME DESCRRIPTION

1 Expansion RAM disk board UP-P02MB 2 Mbytes RAM board

2 Expansion ROM disk board UP-F04RB 4 Mbytes ROM board

3 Customer display UP-I20DP 2 line 20 digits dot display

4 Customer pole display UP-P20DP 2 line 20 digits dot display

5 MCR (Magnetic Card Reader) UP-E12MR2 for ISO 1 & 2 stripe card

6 Remote drawer ER-03DW 7B/5C

ER-04DW 5B/5C

7 Receipt/Journal printer ER-01PU 2 station (R/J) thermal printer 45mm width

8 Built-in printer UP-T80BP 1 station thermal printer 80mm width

9 RS232 & CENTRO I/F board ER-A8RS RS232 9 pins connector:2 ports

Centronics 25 pins connector : 1 port

10 Hand scanner ER-A6HS1 for reading bar code

11 FDD unit HZ-H14FD 3.5" Floppy Disk Drive (Newtronics D353M3)

2 – 1

3. Locally supplied options

No. NAME MODEL NAME DESCRIPTION

1 S.O.DIMM Small Outline DIMM Max. 32Mbyte *1

2 HDD (by FUJITSU) MHD2021AT 2.5 inch, 2.1Gbyte *2

3 PC keyboard PS/2 type PC keyboard

4 Application software

5 Additional device drivers

*1 EXTENSION RAM MODULE (Provided through SHARP Electronics Corporation)

[Outline] UP-5300 has a socket as Small Outline DIMM.

It is necessary to satisfy with S.O.DIMM memory specification as follows.

[Specification]

144pin S.O.DIMM

8 Mbytes 16 Mbytes 32 Mbytes

TYPE EDO type

ACCESS TIME 60 nsec. (less than)

POWER 3.3 V

REFRESH CYCLE 1024/16 msec. 2048/32 msec. 4096/64 msec.

REFRESH TYPE CBR

POWER CONSUMPTION 700 mA (less than)

OTHER 4 chip ×16 Mbits

(1 Mwords ×16 bits) 8 chip ×16 Mbits

(2 Mwords ×8 bits) 4 chip ×64 Mbits

(4 Mwords ×16 bits)

*2 HARD DISK DRIVE (Local purchase)

[Outline] UP-5300 may be connected to the Hard Disk Drive.

It is necessary to satisfy the 2.5 inch Hard Disk Drive specification as follows.

[Specification]

2.5 inch type Hard Disk Drive

MAKER FUJITSU

MODEL MHD2021AT

PARTS No.

REVISION No. 1) Part No.: CA01640-B040

Rev. No.: A4

CAPACITY 2.16 Gbytes

INTERFACE ATA-3

4. Service options

No. NAME PARTS CODE PRICE DESCRIPTION

1 Connector cable for Dongle (LPT-1) QCNW-7858BHZZ BL Relay line from Terminal to Dongle

2 HDD mounting kit DKIT-8671RCZZ — Bracked assembly for mounting

5. Service tools

No. NAME PARTS CODE PRICE DESCRIPTION

1 Service tool kit DKIT-8656BHZZ CW ISA checker

ISA relay board

2 Printer connector signal loop back connector UKOG-6717RCZZ BR for ER-A8RS CENTRONICS connector

3 MCR test card UKOG-6718RCZZ BE for UP-E12MR

4 RS232 loop back connector UKOG-6705RCZZ BC for RS232 connector

5 CPU/VGA PWB relay PWB CKOG-6728BHZZ CQ

6 BIOS loading board CKOG-6727BHZZ CS for overwriting BIOS

7 RS232 modular jack loop back connector UKOG-6729BHZZ AZ for RJ45 connector

8 BIOS MASTER ROM VHI27040RBQ1A (P) EP-ROM for overwriting BIOS

9 TOUCH PEN CPENP1004PCN5 AG

2 – 2

4-1. Service tool kit: DKIT-8656BHZZ

1) ISA checker

Used to repair or check the operation of the optional I/F.

•External view

•Plain view

•Connection diagram

2) ISA relay board

Connected to the ISA checker for installation of the optional I/F

horizontally and for repairing and checking the operation .

•External view

•Plain view

RAM1A

LED circuit: Not used currently.

Test pins: Used to check the ISA bus signal.

ISA bus connectors:

Used to connect with the I/F PWB of ER-A8RS etc.

Connected to the UP-5300 ISA bus connectors.

UP-5300

ISA bus connector

ER-A8RS

ISA checker

ISA bus connector:

Used to check the ER-A8RS solder side.

Connected to the ISA bus connector of ISA checker.

ISA bus connector:

Used to check the ER-A8RS parts side.

2 – 3

•Connection diagram

4-2. Printer connector signal loop check cable:

UKOG-6717RCZZ

Connected to the centronics connector (25 pin) of the ER-A8RS, and

is used to check loop signals when executing diagnostics.

•External view

•Plan view and connection diagram

•Connection diagram

4-3. MCR test card: UKOG-6718RCZZ

•Used when executing the diagnostics of the UP-E12MR2.

•External view

ER-A8RS solder side

ISA relay board

ER-A8RS parts side

ISA PWB

ISA checker

150±8

Signal name Pin No.

1STROBE- 2DB0 3DB1 4DB2 5DB3 6DB4 7DB5 8DB6 9DB7 10ACK- 11BUSY 12PE 13SLCT 14AUTOFD- 15ERROR- 16INIT- 17SLCTIN- 18~25PE

Signal namePin No.

1 STROBE-

2 DB0

3 DB1

4 DB2

5 DB3

6 DB4

7 DB5

8 DB6

9 DB7

10 ACK-

11 BUSY

12 PE

13 SLCT

14 AUTOFD-

15 ERROR-

16 INIT-

17 SLCTIN-

18~25 PE

ER-A8RS

2 – 4

Autres manuels pour UP-5300

Table des matières

Autres manuels Sharp Terminal tactile

Sharp

Sharp ER-A750 Manuel utilisateur

Sharp

Sharp RZ-X650 Manuel utilisateur

Sharp

Sharp UP-X300 Manuel utilisateur

Sharp

Sharp ER-A850 Manuel utilisateur

Sharp

Sharp UP-X500 Manuel utilisateur

Sharp

Sharp ER-A770 Manuel utilisateur

Sharp

Sharp UP-5700 Manuel utilisateur

Sharp

Sharp RZ-X650 Manuel utilisateur

Sharp

Sharp UP-3301 Manuel utilisateur

Sharp

Sharp UP-3500 Manuel utilisateur

Sharp

Sharp ER-A750 Manuel du propriétaire

Sharp

Sharp UP-X300CF256 Manuel utilisateur

Sharp

Sharp ER-A770 Manuel utilisateur

Sharp

Sharp UP-X300 Manuel utilisateur

Sharp

Sharp UP-600 Manuel du propriétaire

Sharp

Sharp UP-3300 Manuel utilisateur

Sharp

Sharp UP-820F Manuel utilisateur

Sharp

Sharp UP-820F Manuel utilisateur

Sharp

Sharp UP-600D Guide de configuration

Sharp

Sharp ZQ-5000 Manuel utilisateur

Sharp

Sharp UP-3500 Manuel utilisateur

Sharp

Sharp ER-A771 Manuel utilisateur

Sharp

Sharp UP-600 Manuel utilisateur

Sharp

Sharp UP-5300 Manuel utilisateur

Manuels Terminal tactile populaires d'autres marques

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Manuel utilisateur

Ingenico

Ingenico AXIUM EX4000 Manuel utilisateur

Heisei Electronics

Heisei Electronics Q-POS 815 Manuel utilisateur

Amano

Amano MTX-15 Manuel utilisateur

FLOWBIRD

FLOWBIRD CWT Compact Touch Manuel utilisateur

Demco

Demco SP7 Manuel utilisateur

Lathem

Lathem PC600 Series Manuel utilisateur

Partner

Partner MF-2352 Manuel utilisateur

NCR

NCR RealPOS 7460-2 Manuel

Simrad

Simrad MS50 Instructions de montage

Unitech

Unitech MR350 MKII Guide de démarrage rapide

Jungheinrich

Jungheinrich WMT 210 Manuel utilisateur

Motorola

Motorola MTP850 Manuel utilisateur

YASKAWA

YASKAWA 62H-MDC0 Manuel utilisateur

MVG industries

MVG industries NeptuLink Manuel utilisateur

Price Industries Limited

Price Industries Limited FDC Manuel d'instructions

Honeywell

Honeywell TemaKey Manuel utilisateur

EBN

EBN BPC65-B-A16G Manuel utilisateur
