Lamp replacement

screw

Lamp unit cover

Top cover

Mounting screws

Cable

connector

Tabs

Lens cover

Cable connector

Installation Manual

AN-PH10EX

AN-PH20EZ

AN-PH30EZ

AN-PH40EZ

AN-PH50EZ

AN-PH60EZ

WARNING:This installation manual is for use by

service personnel. Please be aware that the

manufacturer cannot be responsible for breakage

or damage incurred due to improper installation of

this lens or use of the projector.

When replacing the lens, please have the lens replaced by

the store of purchase or a Sharp Engineering certified

service workshop.The inside of the projector contains high-

voltage parts that can be extremely dangerous.Never

attempt to replace the lens by yourself.

Always make sure to turn off the main power and unplug

the power cord before replacing the lens.

Be careful not to allow any screws to drop inside the projector

while working.This can cause a fire, electrical shock or

malfunction.

Do not attempt to replace the lens while the projector is

suspended from the ceiling.The lens may fall out of the projector

resulting in injury.

Before replacing the lens, return the lens shift to the position

shown below. (The lens shift is adjusted to the position shown

below when shipped from the factory.)

•V (vertical) shift: Uppermost position

•H (horizontal) shift: Middle position

When replacing the lens, use a commercially available

screwdriver that satisfies all of the conditions indicated below.

•Type 2 Philips head screwdriver

•Length of protruding section: min.180 mm (10")

•Magnetized

345 6

Loosen the lamp replacement

screw (11

1) that fastens the lamp

unit cover, and remove the lamp

unit cover by sliding in the direc-

tion shown by the arrow (22

2).

Remove the mounting screws of

the top cover.

Unplug the cable connector (11

and remove the top cover (22

2). Releasethetabswhilepullingup

on the lens cover, and then pull

it out towards you.

(When the lens being removed is the AN-

PH30EZ (XG-PH50X standard lens))

Remove the lens ring by turning

in the direction shown by the ar-

row.

Unplug the cable connector.

Printed in China

TINS-B760WJZZ

05P01-CH-NM

Lens mounting screws

Positioning pin

Lens cap (back)

Motor section

Lens mount

Positioning pin

Guide

hole

Cable connector

Ribs

Lens cover

Tabs

1211

13 14

Positioning pin

amark

Remove the lens mounting

screws.

Rotate the replacement lens 90

degrees in the direction shown

by the arrow (11

1), align the posi-

tioning pin with the guide hole

(22

2), tighten the lens mounting

screws and then connect the

cable connector (33

3).

Pulloutthelenstowardsyouand

then take out the lens (22

2) by ro-

tating it 90 degrees (11

1) in the di-

rection shown by the arrow.

(When the lens being attached is the AN-

PH30EZ (XG-PH50X standard lens))

Attach the lens ring.

•Align the amark on the lens ring with the

positioning pin on the lens (silver pin), in-

sert the lens ring all the way to the back

and then rotate in the direction of the ar-

row.

Remove the lens cap (on the

back) from the replacement lens.

•This explanation uses the example of the

AN-PH10EX.

Attach the lens cover.

•Insertthelens coverwhilespreading apart

theringsection(made of rubber),and then

attach the tabs to the ribs.

Insert the replacement lens into

the lens mount with the motor

section facing up.

Connect the cable connector by

following steps 1 through 3,and

then attach the top cover and

lamp unit cover.

•The power of the projector will not come

on unless the lamp unit cover is securely

attached.
