MX-M264N

MX-M314N

MX-M354N

TechnicalHandyGuide

Capricorn

Version

1.a

May 2012

Handy Guide

2DocumentSolutionsAfterSalesService

Information contained within this guide is subject to change without prior notice.

This Handy Guide is not a substitute for the official Sharp Service Manuals. It is for

use by Sharp qualified service technicians with the intention of improving the

efficiency of Sharp MFP Devices.

All the latest fault finding information, firmware and printer drivers can be found on

the SHARP Support Website.

SHARP ELECTRONICS (UK) LTD

Document Solutions Post Sales Service

4 Furzeground Way

Stockley Park

Uxbridge

Middlesex

UB11 1EZ

www.sharp.co.uk

Useful Technical Links;

Technical Website www.tradenet.sharp.co.uk/tech

Product Key Registration https://dse-pub.sharp.co.jp/key/

User Name: keyuser

Password: key000323

Handy Guide

3DocumentSolutionsAfterSalesService

Page

1 Machine Specification 4

2 Machine Options 5

3 Consumables 7

4 Initial Set-up 8

5 Maintenance 10

6 Coin Vend Interface 12

7 Product Key Registration 14

8 Firmware Upgrade Procedure

9 Test Simulations 18

10 Trouble Codes 25

11 Sensors & Switches 27

12 Jam Cause Codes 28

13 Notes 29

Machine Specifications

4DocumentSolutionsAfterSalesService

General MX-M264N / MX-M314N / MX-M354N

Type Desktop

Original / Printed paper

size Max. A3 / Max. A3 – Min. A6R

Standard paper capacity 1,100 (500-sheet x 2 + 100-sheet multi bypass)

Maximum paper capacity 2,100 (500-sheet x 4 + 100-sheet multi bypass)

Paper weight Tray: 56 - 105 g/m2Bypass: 56 - 200 g/m2

Output capacity A4 size: 500 sheet (Face down)

Warm-up time 20 sec. or less

Resolution 600x600dpi,

1,200x600dpi (printer only)

Memory/ HDD SD card: 8GB, ICU: 2GB

HDD: 160GB (Opt)

Duplex Std. (60 - 105 g/m2)

LCD Colour 7.0 inch

Max power consumption 1.84kW

Dimensions (W-D-H) 625 x 645 x 799 mm (including operational panel and RSPF)

Weight Approx. 52.1 kg

MCV (max) 75k

MCBF / MCBJ / Life 80k/10k/800k or 5 years

Copier Std.

Copy speed (A4) 26 cpm / 31 cpm / 35 cpm

E-sort Yes

First copy time (26 cpm) 4.9 sec. Platen 7.9 sec. RSPF

(31 cpm) 4.4 sec. Platen 7.1 sec. RSPF

(35 cpm) 4.0 sec. Platen 6.7 sec RSPF

Continuous copy Max. 999

Zoom range Platen: 25 – 400% RSPF: 25 – 200%

Document Feeder Std. RSPF

Original capacity 100 sheet (80 g/m2)

Scan speed (copy/ fax/

scan) 50 opm

Finishing Opt. Job separator Opt. Inner finisher

Output capacity Upper: 100 sheet

Lower: 500 sheet 500 (A4)

250 (A3)

Functionality -

Max 50 sheet one-position staple

(A4: 50 sheet / A3: 30 sheet)

Off-set shifting

Printer Std.

Print speed (A4) 26 ppm / 31 ppm / 35 ppm

PDL (Emulation) Std.: PCL6 Opt.: PostScript3

Interface USB2.0, 10Base-T / 100Base-TX / 1000Base-T

Supported OS Win XP, Server 2003, Vista, Server 2008, Server 2008R2, Windows

Mac OS X 10.4.11, 10.5 – 10.5.8, 10.6 – 10.6.8., 10.7-10.7.2

Document Filing Opt.

Scan Std.

Resolution 100 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi

Duplex Yes

Destination Desktop (Sharpdesk),

FTP, folder (SMB server), USB memory, E-

mail, i-Fax

(

)

Bundled utilit

software

Network Scanner Tool, Shar

desk 3.3

Fax Opt.

Communication formula

Super G3, Max. 33,600 bps

Document size Max. A3-

Min. A5

Compression MH, MR, MMR, JBIG

Transmission time 2 sec. (Super G3 /JBIG) 6 sec. (G3 ECM)

Dial re

istration

1000 dials

Broadcast transmission

Max 500

PC-Fax Yes

(

For Windows onl

Inbound faxin

Yes

Machine Options

5DocumentSolutionsAfterSalesService

escr

M264N/MX

M314N/MX-

M354N

emar

DE17

500

-s

eet

rawer

DE18

500

-s

eet

rawer

DS16

tan

DS17

High S

tan

MX-TE10 Exit tray unit Opt.

nner

requ

(Cannot install with MX-

R11

)

FN23

nner

annot

nsta

h MX

TR11

arator

annot

nsta

h MX

FN23

HD12

HDD

ans

KB14

oar

PK11

PS3

ans

PF10

arco

ont

SU1

tam

p ki

FX11

acs

ans

FWX1

nternet-

ans

HDD i

MX-AMX1

cat

ntegrat

module Opt. HDD is required.

MX-AMX2

cat

commun

cat

module Opt. HDD is required.

AMX3

xterna

account

HDD i

MX-FR37U

ata

secur

Commercial ver (non-CC

ver.

)

Opt. HDD is required.

USX1/USX5

arp

ver

1/5

license kit

Opt.

US10/US50

arp

ver

0/50

license kit

Opt.

MX-USA0

arp

ver

3 100

license kit

Opt.

UN01A/05A*1

OSA

NST

1/5

cense

Kit Opt. MX-AMX2 is required

UN10A/50A*1

OSA

NST

10/50

cense

Kit Opt. MX-AMX2 is required

MX-UN1HA*1

OSA

NST

100

cense

Kit Opt. MX-AMX2 is required

Machine Options

6DocumentSolutionsAfterSalesService

Consumables

7DocumentSolutionsAfterSalesService

Model

name Contents Qty Life Min.

Order Qty

Remark

MX-312GT

Toner cartridge (IC

Chip: Yes)

(Toner stirring

mechanism: Yes)

x1 25k 10 A4 6% Coverage

MX-312GV Developer

(26 cpm: 75k , 31/35

cpm: 100k) x1 75k

100k 10

MX-312GR Drum

(26 cpm: 75k, 31/35

cpm: 100k) x1 75k

100k 10 The drum is supplied with

the machine

AR-310UH Upper heat roller kit x1 150k 5

MX-311LH Lower heat roller kit x1 300k 5

MX-311KA 150k maintenance kit x1 150k 5

MX-311MC Main charger unit

(26 cpm: 75k, 31/35

cpm: 100k) x10 75k x 10

100k x 10

MX-311CB Cleaning blade

(26 cpm: 75k, 31/35

cpm: 100k) x10 75k x 10

100k x 10

MX-311DU Drum frame unit

(26 cpm: 225k, 31/35

cpm: 300k) x1 225k

300k 5

MX-311TX Transfer roller unit x1 150k 5

MX-SCX1 Staple cartridge x3 5k x 3 20 For MX-FN**

AR-SV1 Stamp cartridge x2 - 20

Initial Setup

8DocumentSolutionsAfterSalesService

DEVELOPER INSTALLATION

Sim 25-02 Auto Developer Adjustment

Note: Toner Cartridge Must Be Installed after

Auto Developer Adjustment

INITIAL SETTINGS

Sim 26-06 Machine Destination Set

Sim 26-01 Job Separator Installed

Yes/No.

Sim 21-01 Maintenance Cycle Setting

Set to 4=50k

PAPER FEED TRAY SETUP

[SYSTEM SETTINGS]

[Paper Tray Settings]

Settings specify the paper type, paper size, and functions for each paper

tray. When the [Tray Settings] key is touched, a list appears showing the

trays and the current settings.

IMAGE WRITING DISTORTION

Sim 64-012 Image Writing

Adjustment

Select 1 = Grid Pattern

PRINT IMAGE OFF CENTRE

Sim 50-10 Image Off Centre.

Initial Setup

9DocumentSolutionsAfterSalesService

RSPF IMAGE POSITION & VOID

Sim 48-05 RSPF Magnification.

Sim 53-08 RSPF Scan position.

FAX OPTION (MX-FX11)

Sim 66-02 Fax SW Setting (Destination)

Sim 66-10 Fax Memory Clear (For Standard Extended

Memory)

PRODUCT ACTIVATION & FIRMWARE

Sim 22-05 Check Firmware version – Upgrade to latest

version.

COPY IMAGE POSITION & VOID

Sim 50-01 Lead/Rear Edge, Image Loss & Void Adjustment

Sim 50-12 OC & RSPF Off Centre Adjustment

IMAGE DENSITY

Sim 46-02 Copy Exposure Adjustment.

COPY MAGNIFICATION

Sim 48-01 OC Magnification Adjustment

Maintenance

10DocumentSolutionsAfterSalesService

Consumable Schedule

MX-M264N 75k

150k

225k

300k 375k 450k

MX-312GV Developer

MX-312GR OPC Drum

MX-311DU Drum frame unit X X

MX-311CB Drum cleaner

blade

MX-311MC Main charge unit

MX-311KA 150k Maintenance

kit XXX

AR-310UH Upper heat roller

kit XXX

MX-311LH Lower heat roller

kit XXXXX

MX-311TX Transfer roller kit X

MX-M314N/354N 100k

150k

200k

300k 400k 450k

MX-312GV Developer

MX-312GR OPC Drum

MX-311DU Drum frame unit X X X

MX-311CB Drum cleaner

blade XX

MX-311MC Main charge unit

MX-311KA 150k Maintenance

kit XXX

AR-310UH Upper heat roller

kit XXX

MX-311LH Lower heat roller

kit XXXXX

MX-311TX Transfer roller kit X
